Power Window Control System: Removal & Installation Nissan Rogue II

INSTALLATION

Installation is in the reverse order of removal.

Note. When the main power window and door lock/unlock switch is removed or replaced, it is necessary to perform the initialization procedure. Refer to " WORK FLOW ".

Scheme 5

Scheme 6

1. Remove the front door pull handle bracket (RH). Refer to " «REMOVAL AND INSTALLATION»(ref-616755-S20321696632014051900000) ".
2. Release pawls using a suitable tool (A) and remove front door power window and door lock/unlock switch finisher (RH) (1).
3. Disconnect the harness connector from the front door power window and door lock/unlock switch (RH).
4. Release pawls, then separate front power window and door lock/unlock switch (RH) (1) from switch finisher (2).

Installation is in the reverse order of removal.

Note. When the front power window and door lock/unlock switch (RH) is removed or replaced, it is necessary to perform the initialization procedure. Refer to " WORK FLOW ".

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Remove screw cover (1).
2. Remove screw (A).
3. Release pawls using a suitable tool (A) and remove rear power window switch finisher (1).
4. Disconnect harness connector from rear power window switch.
5. Release the pawls, then separate the rear power window switch (1) from the switch finisher (2).

Installation is in the reverse order of removal.
