Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS article of this Service Information.
| WARNING | To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in the event of a collision which would result in air bag inflation, all maintenance must be performed by an authorized NISSAN/INFINITI dealer. Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag Module, see the SRS AIRBAG . Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this Service Information. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness connectors. |
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
| WARNING | When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Ignition ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing serious injury. When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the battery and wait at least three minutes before performing any service. |
Precaution for Work
- When removing or disassembling each component, be careful not to damage or deform it. If a component may be subject to interference, be sure to protect it with a shop cloth.
- When removing (disengaging) components with a screwdriver or similar tool, be sure to wrap the component with a shop cloth or vinyl tape to protect it.
- Protect the removed parts with a shop cloth and prevent them from being dropped.
- Replace a deformed or damaged clip.
- If a part is specified as a non-reusable part, always replace it with a new one.
- Be sure to tighten bolts and nuts securely to the specified torque.
- After installation is complete, be sure to check that each part works properly.
- Follow the steps below to clean components: Water soluble dirt
- Dip a soft cloth into lukewarm water, wring the water out of the cloth and wipe the dirty area.
- Then rub with a soft, dry cloth. Oily dirt
- Dip a soft cloth into lukewarm water with mild detergent (concentration: within 2 to 3%) and wipe the dirty area.
- Then dip a cloth into fresh water, wring the water out of the cloth and wipe the detergent off.
- Then rub with a soft, dry cloth. Do not use organic solvent such as thinner, benzene, alcohol or gasoline. For genuine leather seats, use a genuine leather seat cleaner.
Special Service Tool
The actual shape of the tools may differ from those illustrated here.
Tool number (TechMate No.) Tool name Description - (J-46534) Trim Tool Set Removing trim components
Scheme 13
Commercial Service Tools
(TechMate No.) Tool name Description (-) Power tool Loosening nuts, screws and bolts
Scheme 14
| No. | Component parts | Function |
|---|---|---|
| 1. | Front power window switch | Refer to " POWER WINDOW SWITCH ". |
| 2. | BCM | Supplies power supply to power window relay. Controls retained power. Refer to " BODY CONTROL SYSTEM: COMPONENT PARTS LOCATION " for detailed installation location. |
| 3. | Main power window and door lock/unlock switch | Refer to " POWER WINDOW MAIN SWITCH ". |
| 4. | Front door switch LH (RH similar) | Inputs door open/close condition to BCM. Refer to " FRONT DOOR SWITCH ". |
| 5. | Rear power window switch LH (RH similar) | Refer to " POWER WINDOW SWITCH ". |
| 6. | Power window relay | Operates the power window system with the control signal from the BCM. |
| 7. | Front power window motor LH (RH similar) | Refer to " POWER WINDOW MOTOR ". |
| 8. | Rear power window motor LH (RH similar) | Refer to " POWER WINDOW MOTOR ". |
Scheme 15
- Main power window and door lock/unlock switch controls all power windows.
- Main power window and door lock/unlock switch integrates UP/DOWN switch, power window lock switch, and door lock/unlock switch.
- Main power window and door lock/unlock switch controls power window lock function, AUTO UP/DOWN function, and anti-pinch function.
Scheme 16
- Each power window switch transmits UP/DOWN signal to each motor.
- Each power window switch transmits UP/DOWN signal from power window main switch to each motor.
Scheme 17
- Integrates the encoder and power window motor (front driver side).
- Starts operation according to signals from main power window and door lock/unlock switch.
- Transmits front power window motor (driver side) rotation as a pulse signal to power window main switch.
- Excepting power window motor for driver door, starts operation according to signals from main power window and door lock/unlock switch or each power window switches.
Scheme 18
RETAINED POWER CANCEL CONDITIONS
- Front door CLOSE (door switch OFF) --> OPEN (door switch ON).
- When power switch is ON again.
- When timer time passes (45 seconds).
POWER WINDOW LOCK
Ground circuit inside main power window and door lock/unlock switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the main power window and door lock/unlock switch.
ANTI-PINCH SYSTEM (FRONT DRIVER SIDE)
- Pinch foreign material in the door glass during AUTO-UP operation, and it is the anti-pinch function that lowers the door glass 150 mm (5.9 in.) when detected.
- Encoder continues detecting the movement of front power window motor (driver side) and transmits to main power window and door lock/unlock switch as the encoder pulse signal while front power window motor (driver side) is operating.
- Resistance is applied to the front power window motor (driver side) rotation that changes the frequency of encoder pulse signal if foreign material is trapped in the door glass.
- Main power window and door lock/unlock switch controls to lower the window glass for 150 mm (5.9 in) after it detects encoder pulse signal frequency change.
FAIL-SAFE CONTROL
Switches to fail-safe control when malfunction is detected in encoder signal that detects up/down speed and direction of door glass. Switches to fail-safe control when error beyond regulation value is detected between the fully closed position and the actual position of the glass.
| Error | Error condition |
|---|---|
| Pulse sensor malfunction | When only one side of pulse signal is being detected for more than the specified value. |
| Both pulse sensors malfunction | When both pulse signals have not been detected for more than the specified value during glass open/close operation. |
| Pulse direction malfunction | When the pulse signal that is detected during glass open/close operation detects the opposite condition of power window motor operating direction. |
| Glass recognition position malfunction 1 | When it detects the error between glass fully closed position in power window switch memory and actual fully closed position during glass open/close operation is more than the specified value. |
| Glass recognition position malfunction 2 | When it detects pulse count more than the value of glass full stroke during glass open/close operation. |
It changes to condition before initialization and the following functions do not operate when switched to fail-safe control.
- Auto-up operation
- Anti-pinch function
- Retained power function
Perform initial operation to recover when switched to fail-safe mode. However, it switches back to fail-safe control when malfunction is found in power window switch or in the motor.
DATA MONITOR
| Monitor Item [Unit] | Description |
|---|---|
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
| Monitor Item [Unit] | Description |
|---|---|
| DOOR SW-DR [On/Off] | Indicates condition of front door switch LH. |
| DOOR SW-AS [On/Off] | Indicates condition of front door switch RH. |
List of ECU Reference
| ECU | Reference |
|---|---|
| BCM (with Intelligent Key system) | " REFERENCE VALUE " |
| " FAIL SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " | |
| BCM (without Intelligent Key system) | " REFERENCE VALUE " |
| " FAIL SAFE " | |
| " DTC INSPECTION PRIORITY CHART " | |
| " DTC INDEX " |
Scheme 19
PHYSICAL VALUES
Terminal No. (Wire color) Description Condition Voltage (Approx.) + - Signal name Input/Output 1 (B) Ground Ground - - 0 2 (LA/GR) 16 (LA/SB) Front power window motor RH DOWN signal Output When front RH switch in power window main switch is operated DOWN. Battery voltage 4 (R) 12 (Y) Encoder pulse signal 2 Input When power window motor operates. 5 (W) 12 (Y) Encoder pulse signal 1 Input When power window motor operates. 6 (P) Ground Rear power window motor RH DOWN signal Output When rear RH switch in power window main switch is operated DOWN. Battery voltage 7 (LG) Ground Rear power window motor RH UP signal Output When rear RH switch in power window main switch is operated UP. Battery voltage 8 (LA/Y) Ground Rear power window motor LH DOWN signal Output When rear LH switch in power window main switch is operated DOWN. Battery voltage 9 (LA/W) Ground Rear power window motor LH UP signal Output When rear LH switch in power window main switch is operated UP. Battery voltage 10 (SB) Ground RAP signal Input IGN SW ON Battery voltage Within 45 second after ignition switch is turned to OFF. Battery voltage When driver side or passenger side door is opened during retained power operation. 0 12 (Y) Ground Encoder ground - - 0 14 (G) Ground Encoder power supply Output When ignition switch ON or power window timer operates. 10 16 (LA/SB) 2 (LA/GR) Front power window motor RH UP signal Output When front RH switch in power window main switch is operated UP. Battery voltage 17 (LA/L) 19 (LA/BR) Front power window motor LH UP signal Output When front LH switch in power window main switch is operated UP. Battery voltage 18 (LA/R) Ground Battery power supply Input - Battery voltage 19 (LA/BR) 17 (LA/L) Front power window motor LH DOWN signal Output When front LH switch in power window main switch is operated DOWN. Battery voltage
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
Scheme 28
Scheme 29
DETAILED FLOW
- OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain as much information as possible about the conditions and environment under which the malfunction occurred. : GO TO 2.
- CONFIRM THE SYMPTOM Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. : GO TO 3.
- IDENTIFY THE MALFUNCTIONING SYSTEM WITH SYMPTOM DIAGNOSIS Use Symptom diagnosis from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. : GO TO 4.
- PERFORM THE COMPONENT DIAGNOSIS OF THE OF THE APPLICABLE SYSTEM Perform the diagnosis with Component diagnosis of the applicable system. : GO TO 5.
- REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. : GO TO 6.
- FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2 . Are the malfunctions corrected? YES: Inspection End. NO: GO TO 3 .
INITIALIZATION PROCEDURE
- Disconnect battery minus terminal or main power and window door lock/unlock switch connector. Reconnect it after a minute or more.
- Turn ignition switch ON.
- Operate power window switch to fully open the window. (This operation is unnecessary if the window is already fully open)
- Continue pulling the power window switch UP (AUTO-UP operation). Even after glass stops at fully closed position, keep pulling the switch for 2 seconds or more.
- Initializing procedure is completely.
- Inspect anti-pinch function.
CHECK ANTI-PINCH FUNCTION
- Fully open the door window.
- Place a piece of wood near fully closed position.
- Close door glass completely with AUTO-UP. Check that glass lowers for approximately 150 mm (5.9 in) without pinching piece of wood and stops. Check that glass does not rise when operating the main power and door lock/unlock switch while lowering.
| CAUTION | Perform initial setting when auto-up operation or anti-pinch function does not operate normally. Check that AUTO-UP operates before inspection when system initialization is performed. Do not check with hands and other body parts because they may be pinched. Do not get pinched. It may switch to fail-safe mode if open/close operation is performed continuously without full close. Perform initial setting in that situation. Refer to " FAIL SAFE " Finish initial setting. Otherwise, next operation cannot be done. Auto-up operation Anti-pinch function |
ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT: Special Repair Requirement
Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT " for initialization procedure and check anti-pinch function.
Component Function Check
- CHECK FRONT POWER WINDOW SWITCH RH FUNCTION Check front power window motor RH operation with front power window switch RH. Is the inspection result normal? YES: Front power window switch RH is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S26518415562014051900000) ".
- CHECK REAR POWER WINDOW SWITCH FUNCTION Check rear power window motor operation with rear power window switch. Is the inspection result normal? YES: Rear power window switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S07100218922014051900000) ".
DRIVER SIDE: Component Function Check
- CHECK FRONT POWER WINDOW MOTOR LH OPERATION Check front power window motor LH operation with main power window and door lock/unlock switch. Is the inspection result normal? YES: Front power window motor LH is OK. NO: Refer to " «DRIVER SIDE: DIAGNOSIS PROCEDURE»(ref-616767-S41263994222014051900000) ".
PASSENGER SIDE: Component Function Check
- CHECK FRONT POWER WINDOW MOTOR RH OPERATION Check front power window motor RH operation with main power window and door lock/unlock switch or front power window switch RH. Is the inspection result normal? YES: Front power window motor RH is OK. NO: Refer to " «PASSENGER SIDE: DIAGNOSIS PROCEDURE»(ref-616767-S39443223742014051900000) ".
REAR LH: Component Function Check
- CHECK REAR POWER WINDOW MOTOR LH OPERATION Check rear power window motor LH operation with main power window and door lock/unlock switch or rear power window switch LH. Is the inspection result normal? YES: Rear power window motor LH is OK. NO: Refer to " «REAR LH: DIAGNOSIS PROCEDURE»(ref-616767-S36125565732014051900000) "
REAR RH: Component Function Check
- CHECK REAR POWER WINDOW MOTOR RH OPERATION Check rear power window motor RH operation with main power window and door lock/unlock switch or rear power window switch RH. Is the inspection result normal? YES: Rear power window motor RH is OK. NO: Refer to " «REAR RH: DIAGNOSIS PROCEDURE»(ref-616767-S16556462602014051900000) ".
- CHECK ENCODER OPERATION Check front driver side door glass perform AUTO open/close operation normally when main power window and door lock/unlock switch. Is the inspection result normal? YES: Encoder operation is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S17833857012014051900000) "
Scheme 30
- CHECK ENCODER OPERATION Turn ignition switch ON. Check signal between main power window and door lock/unlock switch harness connector and ground with oscilloscope. (+) (-) Signal (Reference value) Main power window and door lock/unlock switch Connector Terminal D6 4 Ground Refer to following signal 5 Is the inspection result normal? YES: GO TO 7 . NO: GO TO 2.
- CHECK ENCORDER SIGNAL CIRCUIT Turn ignition switch OFF. Disconnect main power window and door lock/unlock switch connector and front power window motor LH connector. Check continuity between main power window and door lock/unlock switch harness connector and front power window motor LH harness connector. Main power window and door lock/unlock switch Front power window motor LH Continuity Connector Terminal Connector Terminal D6 4 D10 4 Yes 5 5 Check continuity between main power window and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D6 4 No 5 Is the inspection result normal? YES: GO TO 3. NO: Repair or replace harness.
- CHECK ENCORDER POWER SUPPLY CIRCUIT Connect main power window and door lock/unlock switch connector. Turn ignition switch ON. Check voltage between front power window motor LH harness connector and ground. (+) (-) Voltage (Approx.) Front power window motor LH Connector Terminal D10 2 Ground Battery voltage Is the inspection result normal? YES: GO TO 4. NO: GO TO 5 .
- CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between front power window motor LH harness connector and ground. Front power window motor LH Ground Continuity Connector Terminal D10 6 Yes Is the inspection result normal? YES: GO TO 7 . NO: GO TO 6 .
- CHECK HARNESS CONTINUITY 1 Turn ignition switch OFF. Check continuity between main power window and door lock/unlock switch harness connector and front power window motor LH harness connector. Main power window and door lock/unlock switch Front power window motor LH Continuity Connector Terminal Connector Terminal D6 12 D10 6 Yes Check continuity between main power window and door lock/unlock switch harness connector and ground. Main power window and door lock/unlock switch Ground Continuity Connector Terminal D6 12 No Is the inspection result normal? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ". NO: Repair or replace harness.
- CHECK HARNESS CONTINUITY 2 Disconnect main power window and door lock/unlock switch connector. Check continuity between main power window and door lock/unlock switch harness connector and front power window motor LH harness connector. Main power window and door lock/unlock switch Front power window motor LH Continuity Connector Terminal Connector Terminal D6 14 D10 2 Yes Is the inspection result normal? YES: Replace main power window and door lock/unlock switch. Refer to " «REMOVAL AND INSTALLATION»(ref-616767-S22807732752014051900000) ". NO: Repair or replace harness.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616709-S18434043682014051900000) ". : Inspection End.
- CHECK POWER WINDOW RELAY POWER SUPPLY CIRCUIT Check that an operation noise of power window relay [located behind the A/C switch assembly (automatic A/C) or Front air control (manual A/C)] can be heard when turning the main power window and door lock/unlock switch ON. Is the inspection result normal? YES: Power window relay power supply circuit is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-616767-S35750020532014051900000) ".
WITH INTELLIGENT KEY: Component Function Check
- CHECK FUNCTION Select "DOOR LOCK" of "BCM" using CONSULT. Select "DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", in "Data Monitor" mode. Check that the function operates normally according to the following conditions. Monitor item Condition Status DOOR SW-DR Driver side door Open On Closed Off DOOR SW-AS Passenger side door Open On Closed Off DOOR SW-RL Rear door LH Open On Closed Off DOOR SW-RR Rear door RH Open On Closed Off Is the inspection result normal? YES: Door switch is OK. NO: Refer to " «WITH INTELLIGENT KEY: DIAGNOSIS PROCEDURE»(ref-616767-S24547416312014051900000) ".
WITHOUT INTELLIGENT KEY: Component Function Check
- CHECK FUNCTION Select "DOOR LOCK" of BCM using CONSULT. Select "DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", in Data Monitor mode. Check that the function operates normally according to the following conditions. Monitor item Condition Status DOOR SW-DR Driver side door Open On Closed Off DOOR SW-AS Passenger side door Open On Closed Off DOOR SW-RL Rear door LH Open On Closed Off DOOR SW-RR Rear door RH Open On Closed Off Is the inspection result normal? YES: Door switch is OK. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-616773-S22782945112014051900000) ".
