Audio, Visual, Navigation System (Mid Audio): Removal & Installation Nissan Pathfinder III рестайлинг

REMOVAL

1. Disconnect the battery negative terminal.
2. Remove the cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S20460961332012122900000) ".
3. Remove the AV control unit screws, using a power tool.
4. Remove the AV control unit.
5. Remove the A/C and AV switch assembly screws, then remove the A/C and AV switch assemblies as necessary.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 445

1. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S20460961332012122900000) ".
2. Remove the display unit screws (A).
3. Pull out the display unit (1), then disconnect the display unit connectors and remove the display unit (1).
4. Remove the A/C auto amp.screws (A), remove the (C103) fasteners (B) from the display unit assembly brackets and remove the A/C auto amp. (1).
5. Remove the display unit bracket unit screws (C) and remove the display unit brackets (2).

Scheme 446

Installation is in reverse order of removal.

1. Remove the front tweeter grille.
2. Remove the front tweeter screws (A).
3. Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Scheme 447

Installation is in the reverse order of removal.

1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
2. Remove the front door speaker screws (A).
3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Scheme 448

Installation is in the reverse order of removal.

1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
2. Remove the rear door speaker screws (A).
3. Disconnect the rear door speaker connector (B) and remove rear door speaker (1).

Scheme 449

Installation is in the reverse order of removal.

Scheme 450

1. Remove the driver air bag module. Refer to " «REMOVAL AND INSTALLATION»(ref-519772-S06994129762012122900000) ".
2. Remove the steering wheel audio control switch assembly screws.
3. Disconnect the steering wheel audio control switches connector.
4. Remove the steering wheel audio control switches by pulling on steering wheel audio control switches to release the pawls.

Scheme 451

Installation is in the reverse order of removal.

Scheme 452

Scheme 453

Scheme 454

Scheme 455

1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continuity, wrap tin foil around the top of probe. Then, press the foil against the wire with your finger .
2. If an element is broken, no continuity will exist.
3. To locate a break, move probe along element. Tester indication will change abruptly when probe passes the broken point.

Scheme 456

1. Remove the A/T finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S07978010502012122900000) ".
2. Remove the auxiliary input jack.

Installation is in the reverse order of removal.

1. Remove the luggage side upper and lower RH finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S32750843902012122900000) ".
2. Detach the antenna amp. harness clip (D), disconnect the antenna amp. connector (A), harness connector (B), then remove the antenna amp. screw (C) and remove the antenna amp. (1).

Scheme 457

Installation is in the reverse order of removal.

Scheme 458

1. Remove the license lamp finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519780-S09787452012012122900000) ".
2. Disconnect the rear view camera connector.
3. Detach the rear view camera harness clip.
4. Detach the rear view camera to release, then pull out to remove the rear view camera while feeding the rear view camera harness and connector through the back door.

Installation is in the reverse order of removal.
