Audio, Visual, Navigation System (Base Audio): Removal & Installation Nissan Pathfinder III рестайлинг

Entertainment Systems 9 illustrations ~293 words

REMOVAL

  1. Disconnect the battery negative terminal.
  2. Remove the cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S20460961332012122900000) ".
  3. Remove the audio unit screws, using power tool.
  4. Remove the audio unit and disconnect audio unit connectors.
  5. Remove the audio unit brackets screws and remove the audio unit brackets.

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONUse a suitable tool to prevent damage to the front tweeter speaker grille trim and the instrument panel. Remove the front tweeter grille. Remove the front tweeter screws (A). Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Scheme 181

Scheme 181
Scheme 181

Installation is in the reverse order of removal.

  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
  2. Remove the front door speaker screws (A).
  3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Scheme 182

Scheme 182
Scheme 182

Installation is in the reverse order of removal.

  1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
  2. Remove the rear door speaker screws (A).
  3. Disconnect the rear door speaker connector (B) and remove rear door speaker (1).

Scheme 183

Scheme 183
Scheme 183

Installation is in the reverse order of removal.

Scheme 184

Scheme 184: Location of Antenna
Scheme 184: Location of Antenna

Scheme 185

Scheme 185: ELEMENT CHECK
Scheme 185: ELEMENT CHECK

Scheme 186

Scheme 186
Scheme 186

Scheme 187

Scheme 187
Scheme 187
  1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continuity, wrap tin foil around the top of probe. Then, press the foil against the wire with your finger.
  2. If an element is broken, no continuity will exist.
  3. To locate a break, move probe along element. Tester indication will change abruptly when probe passes the broken point.

Scheme 188

Scheme 188
Scheme 188
  1. Remove the luggage side upper and lower RH finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S32750843902012122900000) ".
  2. Detach the antenna amp. harness clip (D), disconnect the antenna amp. connector (A), harness connector (B), then remove the antenna amp. screw (C) and remove the antenna amp. (1).

Scheme 189

Scheme 189
Scheme 189

Installation is in the reverse order of removal.
