CONFIRMATION/ADJUSTMENT MODE
- Start the diagnosis function and select "Confirmation/Adjustment". The confirmation/adjustment mode indicates where each item can be checked or adjusted.
- Select each item on the "Confirmation/Adjustment" mode screen to display the relevant trouble diagnosis screen. Touch "BACK" on the display unit or press the "BACK" switch to return to the initial Confirmation/Adjustment Mode screen.
Scheme 207
Display Diagnosis
Scheme 208
Vehicle Signals
A comparison check can be made of each actual vehicle signal and the signals recognized by the system.
Scheme 209
| Diagnosis item | Display | Vehicle status | Remarks |
|---|---|---|---|
| Vehicle speed | ON | Vehicle speed > 0 km/h | Changes in indication may be delayed by approximately 1.5 seconds. This is normal. |
| OFF | Vehicle speed = 0 km/h | ||
| Ignition switch in ACC position | |||
| Parking brake | ON | Parking brake is applied. | |
| OFF | Parking brake is released. | ||
| Lights | ON | Light switch ON | Block the light beam from the auto light optical sensor. |
| OFF | Light switch OFF | ||
| Ignition | ON | Ignition switch ON | |
| OFF | Ignition switch in ACC position | ||
| Reverse | ON | Selector lever in R position | Changes in indication may be delayed by approximately 1.5 seconds. This is normal. |
| OFF | Selector lever in any position other than R | ||
| Ignition switch in ACC position |
Speaker Test
Select "Speaker Test" to display the speaker diagnosis screen. Press "Start" to generate a test tone in speakers. Press "End" to stop the test tones.
Scheme 210
Error History
The self-diagnosis results are judged depending on whether any error occurs from when "Self-diagnosis" is selected until the self-diagnosis results are displayed.
Scheme 211
However, the diagnosis results are judged normal if an error has occurred before the ignition SW is turned ON and then no error has occurred until the self-diagnosis start. Check the "Error History" to detect any error that may have occurred before the self-diagnosis start because of this situation.
Count up method A
- The counter resets to 0 if an error occurs when IGN switch is turned ON. The counter increases by 1 if the condition is normal at a next IGN ON cycle.
- The counter upper limit is 39. Any counts exceeding 39 are ignored. The counter can be reset (no error record display) with the "Delete log" switch or CONSULT.
Count up method B
- The counter increases by 1 if an error occurs when IGN switch is ON. The counter will not decrease even if the condition is normal at the next IGN ON cycle.
- The counter upper limit is 50. Any counts exceeding 50 are ignored. The counter can be reset (no error record display) with the "Delete log" switch or CONSULT. Display method of occurrence frequency Error history display item Count up method A CAN communication line, control unit (CAN), AV communication line, control unit (AV communication) Count up method B Other than above
Vehicle CAN Diagnosis
- CAN communication status and error counter is displayed.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if reset.
Scheme 212
AV COMM Diagnosis
- AV communication status and error counter is displayed.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if reset.
Scheme 213
Delete Unit Connection Log
Deletes any unit connection records and error records from the AV control unit memory. (Clear the records of the unit that has been removed)
Scheme 214
Initialize Settings
Initializes the AV control unit memory.
