Audio, Visual, Navigation System (Bose Audio Without Navigation): Removal & Installation Nissan Pathfinder III рестайлинг

REMOVAL

1. Disconnect the battery negative terminal.
2. Remove the cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S20460961332012122900000) ".
3. Remove the AV control unit screws, using a power tool.
4. Remove the AV control unit.
5. Remove the A/C and AV switch assembly screws, then remove the A/C and AV switch assemblies as necessary.

INSTALLATION

Installation is in the reverse order of removal.

Scheme 311

1. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S20460961332012122900000) ".
2. Remove the display unit screws (A).
3. Pull out the display unit (1), then disconnect the display unit connectors and remove the display unit (1).
4. Remove the A/C auto amp.screws (A), remove the (C103) fasteners (B) from the display unit assembly brackets and remove the A/C auto amp. (1).
5. Remove the display unit bracket unit screws (C) and remove the display unit brackets (2).

Scheme 312

Installation is in reverse order of removal.

1. Remove the front tweeter grille.
2. Remove the front tweeter screws (A).
3. Pull out the front tweeter speaker (1) and disconnect front tweeter connector, then remove the front tweeter speaker (1).

Scheme 313

Installation is in the reverse order of removal.

1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
2. Remove the front door speaker screws (A).
3. Pull out the front door speaker (1), and disconnect the front door speaker connector and remove the front door speaker (1).

Scheme 314

Installation is in the reverse order of removal.

1. Remove the rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
2. Remove the rear door speaker screws (A).
3. Disconnect the rear door speaker connector (B) and remove rear door speaker (1).

Scheme 315

Installation is in the reverse order of removal.

1. Remove rear door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S41327535822012122900000) ".
2. Remove the rear tweeter screws (A) and remove the rear tweeter (1).

Scheme 316

Installation is in the reverse order of removal.

Scheme 317

1. Remove the driver air bag module. Refer to " «REMOVAL AND INSTALLATION»(ref-519772-S06994129762012122900000) ".
2. Remove the steering wheel audio control switch assembly screws.
3. Disconnect the steering wheel audio control switches connector.
4. Remove the steering wheel audio control switches by pulling on steering wheel audio control switches to release the pawls.

Scheme 318

Installation is in the reverse order of removal.

1. Remove the front roof console finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S39057959832012122900000) ".
2. Detach the microphone (1) from the front console finisher tabs (A).
3. Disconnect the microphone connector (B) and remove the microphone (1).

Scheme 319

Installation is in the reverse order of removal.

Scheme 320

1. Remove the RH front seat. Refer to " «REMOVAL AND INSTALLATION»(ref-519825-S16703712102012122900000) ".
2. Disconnect the Bluetooth control unit connectors.
3. Remove the Bluetooth control unit bracket screws and remove the Bluetooth control unit assembly.
4. Remove the Bluetooth control unit screws.
5. Transfer the Bluetooth antenna to the new Bluetooth control unit.

Installation is in the reverse order of removal.

Note. Do not remove the LH front seat from the vehicle.

1. Remove LH front seat bolts, disconnect the LH front seat electrical harness connector. Refer to " «REMOVAL AND INSTALLATION»(ref-519825-S16703712102012122900000) ".
2. Tilt the LH front seat back to access the BOSE speaker amp. (1), then remove the BOSE speaker amp. screws (B).
3. Disconnect the Bose speaker amp. connectors (A) and remove Bose speaker amp. (1) from the bracket (2).
4. Then remove the BOSE speaker amp. bracket screws (C) and remove bracket (2).

Scheme 321

Installation is in the reverse order of removal.

Scheme 322

Removal

1. Remove the luggage side lower finisher LH. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S32750843902012122900000) ".
2. Remove subwoofer bolts and nuts.
3. Disconnect the subwoofer connector and remove the subwoofer.

Installation

Installation is in the reverse order of removal.

1. Remove the center console assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S11228058962012122900000) ".
2. Disconnect the DVD player connector (A).
3. Remove the DVD player screws (B), then remove the DVD player (1).
4. Remove the DVD player bracket screws and then remove DVD player brackets.

Scheme 323

Installation is in reverse order of removal.

1. Release the clips and remove the video monitor finisher from headlining.
2. Press the release tabs and remove the cover.
3. Remove the video monitor screws.
4. Gently lower the assembly and disconnect the connector, then remove the video monitor from the headlining.

Scheme 324

Installation is in reverse order of removal.

Scheme 325

Scheme 326

Scheme 327

Scheme 328

1. Attach probe circuit tester (ohm setting) to antenna terminal on each side. When measuring continuity, wrap tin foil around the top of probe. Then, press the foil against the wire with your finger .
2. If an element is broken, no continuity will exist.
3. To locate a break, move probe along element. Tester indication will change abruptly when probe passes the broken point.

Scheme 329

1. Remove the A/T finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519812-S07978010502012122900000) ".
2. Remove the auxiliary input jack.

Installation is in the reverse order of removal.

1. Remove the luggage side upper and lower RH finishers. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S32750843902012122900000) ".
2. Detach the antenna amp. harness clip (D), disconnect the antenna amp. connector (A), harness connector (B), then remove the antenna amp. screw (C) and remove the antenna amp. (1).

Scheme 330

Installation is in the reverse order of removal.

1. Remove the front roof console finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519822-S39057959832012122900000) ".
2. Disconnect the satellite antenna connector.
3. Remove the satellite antenna nut.
4. Remove the satellite antenna.

Scheme 331

Installation is in the reverse order of removal.

1. Disconnect the battery negative terminal.
2. Disconnect the satellite radio tuner connectors.
3. Remove satellite radio tuner screws (A), and remove satellite radio tuner from above the parking brake pedal.

Scheme 332

Installation is in the reverse order of removal.

Scheme 333

1. Remove the license lamp finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-519780-S09787452012012122900000) ".
2. Disconnect the rear view camera connector.
3. Detach the rear view camera harness clip.
4. Detach the rear view camera to release, then pull out to remove the rear view camera while feeding the rear view camera harness and connector through the back door.

Installation is in the reverse order of removal.
