Power Supply, Ground & Circuit Elements: Removal & Installation Nissan Note E12

Body Electrical 2 illustrations ~281 words

Removal and Installation (Battery)

CAUTIONTo prevent damage to the parts, disconnect the battery cable from the negative terminal first.

REMOVAL

  1. Remove the air duct inlet. Refer to " «EXPLODED VIEW»(ref-675577-S36907619292014120500000) ".
  2. Disconnect the battery cable from the negative terminal and set aside.
  3. Disconnect the battery cable from the positive terminal and set aside.
  4. Remove the remove the battery wedge bracket.
  5. Remove the battery cover and the battery.

INSTALLATION

Installation is in the reverse order of removal.

CAUTIONReplace the battery if it has been dropped or sustained and impact. To install the battery, carefully read the following instructions: To prevent damage to the parts, connect the battery cable to the positive terminal first. After connecting battery cables, to securely supply battery voltage, ensure that they are tightly clamped to battery terminals for good contact. To securely supply battery voltage, check battery terminal for poor connection caused by corrosion. Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ".

Removal and Installation (Battery Tray)

CAUTIONTo prevent damage to the parts, disconnect the battery cable from the negative terminal first.
  1. Remove the battery. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Remove the battery tray bracket. Refer to " «EXPLODED VIEW»(ref-675572-S00403242272014120500000) ".
  3. Remove the IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-675597-S28632663882014120500000) ".
  4. Disconnect the harness from the TCM and remove the TCM bracket. Refer to " «REMOVAL AND INSTALLATION»(ref-675588-S20352004222014120500000) ".
  5. Disconnect the harness from the battery tray.
  6. Remove the nuts and bolts and remove the battery tray. Refer to " «EXPLODED VIEW»(ref-675572-S00403242272014120500000) ".

Installation is in the reverse order of removal.

CAUTIONReplace electrical components as necessary, if any have been dropped or sustained and impact. To install the battery, carefully read the following instructions: To prevent damage to the parts, connect the battery cable to the positive terminal first. After connecting battery cables, to securely supply battery voltage, ensure that they are tightly clamped to battery terminals for good contact. To securely supply battery voltage, check battery terminal for poor connection caused by corrosion. Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ".

Scheme 1

Scheme 1: Exploded View
Scheme 1: Exploded View

Removal and Installation

CAUTIONTo prevent damage to the parts, disconnect the battery cable from the negative terminal first.
  1. Disconnect the battery cable from the negative terminal and set aside. Refer to " «EXPLODED VIEW»(ref-675572-S00403242272014120500000) ".
  2. Disconnect the battery cable with the fusible link box (battery) from positive terminal.
  3. Open cover of the fusible link box (battery).
  4. Remove harness nut from the fusible link box (battery) and separate the fusible link box (battery) from terminal connector.
  5. Disconnect harness connectors and remove the fusible link box (battery).

Installation is in the reverse order of removal.

CAUTIONReplace the fusible link box (battery) if it has been dropped or sustained and impact. To install the battery, carefully read the following instructions: To prevent damage to the parts, connect the battery cable to the positive terminal first. After connecting battery cables, to securely supply battery voltage, ensure that they are tightly clamped to battery terminals for good contact. To securely supply battery voltage, check battery terminal for poor connection caused by corrosion. Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ".

Scheme 2

Scheme 2: Exploded View
Scheme 2: Exploded View
CAUTIONTo prevent damage to the parts, disconnect the battery cable from the negative terminal first.
  1. Disconnect the battery cable from the negative terminal. Refer to " «EXPLODED VIEW»(ref-675572-S00403242272014120500000) ".
  2. Remove current sensor nut and separate the current sensor from terminal connector.
  3. Disconnect harness connector and remove the current sensor.

Installation is in the reverse order of removal.

CAUTIONReplace the current sensor if it has been dropped or sustained and impact. To install the battery, carefully read the following instructions: To prevent damage to the parts, connect the battery cable to the positive terminal first. After connecting battery cables, to securely supply battery voltage, ensure that they are tightly clamped to battery terminals for good contact. To securely supply battery voltage, check battery terminal for poor connection caused by corrosion. Reset electronic systems as necessary. Refer to " ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL: SPECIAL REPAIR REQUIREMENT ".
