REMOVAL
Note. If unable to use the tool because of power socket location or access to the harness connector, then further removal of interior components may be required. Refer to " REMOVAL AND INSTALLATION ".
Scheme 105
Scheme 106
- Insert one side of Tool (A) into one of the square holes inside the power socket. Tool number: - (J-42059)
- Lift up the handle of the Tool as shown (<==) until the other side snaps into the other square hole in the power socket.
- Pull the power socket straight out with the Tool.
- Disconnect the harness connector from the power socket.
- Remove the ring from the power socket while pressing the pawls with a suitable tool.
INSTALLATION
Installation is in the reverse order of removal.
Note. Make sure to align the tabs with the square notched areas as shown (<==) during installation.
