Power Control System (Ipdm/er) (Without I-Key): Removal & Installation Nissan Note E12

Body Electrical 2 illustrations

Removal and Installation

CAUTIONIPDM E/R integrated relays are not serviceable and must not be removed from unit.

Scheme 88

Scheme 88: REMOVAL
Scheme 88: REMOVAL

Scheme 89

Scheme 89
Scheme 89
  1. Disconnect the negative battery terminal. Refer to " «REMOVAL AND INSTALLATION (BATTERY)»(ref-675572-S35311355862014120500000) ".
  2. Release pawls on IPDM E/R cover (1) and remove.
  3. Release pawls, then lift IPDM E/R (1) as shown below and position aside.
  4. Disconnect the harness connectors from the IPDM E/R (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.
