CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART)
Determine CAN system type based on vehicle equipment. Then choose the correct diagnosis sheet.
Note. There are two styles for CAN system type specification charts. Depending on the number of available system types, either style A or style B may be used.
CAN System Type Specification Chart (Style A)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
CAN System Type Specification Chart (Style A). Scheme 83
CAN System Type Specification Chart (Style B)
Note. CAN system type is easily checked with the vehicle equipment identification information shown in the chart.
CAN System Type Specification Chart (Style B). Scheme 84
CAN System Specification Chart
Determine CAN system type from the following specification chart. Then choose the correct diagnosis sheet.
Note. Refer to, CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION CHART) " for how to use CAN system specification chart.
| Body type | Truck | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Axle | 2WD | 4WD | |||||||||||||
| Engine | QR25DE | VQ40DE | |||||||||||||
| Transmission | M/T | A/T | M/T | A/T | M/T | A/T | |||||||||
| Brake control | ABS | ABS | ABLS | ABS | ABLS | ABS | ABLS | ABS | ABLS | VDC | |||||
| Electronic locking rear differential | X | X | X | X | |||||||||||
| CAN system type | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 |
| Diagnosis sheet | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET | DIAGNOSIS SHEET |
| CAN communication signal chart | " TYPE 1/TYPE 3 " | " TYPE 2/TYPE 5 " | " TYPE 1/TYPE 3 " | " TYPE 4 " | " TYPE 2/TYPE 5 " | " TYPE 6/TYPE 7 " | " TYPE 8 " | " TYPE 9/TYPE 10 " | " TYPE 11 " | " TYPE 12/TYPE 13 " | " TYPE 14/TYPE 15 " | ||||
| X: Applicable | |||||||||||||||
CAN SYSTEM SPECIFICATION CHART
