Lan System: Other Nissan Frontier D40

Precautions When Using CONSULT-II

Use CONSULT-II CONVERTER when connecting CONSULT-II to data link connector.

CAN Communication System

1. CAN communication is a multiplex communication system. This enables the system to transmit and receive large quantities of data at high speed by connecting control units with two communication lines (CAN-H and CAN-L).
2. Control units on the CAN network transmit signals using the CAN communication control circuit. They receive only necessary signals from other control units to operate various functions.
3. CAN communication lines adopt twisted-pair line style (two lines twisted) for noise immunity.

CAN Communication System Diagram. Scheme 117

Each control unit passes an electric current to the termination circuits when transmitting CAN communication signal. The termination circuits produce an electrical potential difference between CAN-H and CAN-L. CAN communication system transmits and receives CAN communication signals by the potential difference.

COMPONENTS DESCRIPTION

CAN Communication Control Circuit Diagram. Scheme 118

CAN COMMUNICATION CONTROL CIRCUIT DESCRIPTION

Condition of Error Detection

"U1000" or "U1001" is indicated on SELF-DIAG RESULTS on CONSULT-II if CAN communication signal is not transmitted or received between units for 2 seconds or more.

CAN COMMUNICATION SYSTEM ERROR

1. CAN communication line open (CAN-H, CAN-L, or both)
2. CAN communication line short (ground, between CAN communication lines, other harnesses)
3. Error of CAN communication control circuit of the unit connected to CAN communication line

WHEN INDICATED "U1000" OR "U1001" IS INDICATED EVEN THOUGH CAN COMMUNICATION SYSTEM IS NORMAL

1. CONSULT-II CONVERTER not connected: Error may be detected by the self-diagnosis when not using CONSULT-II CONVERTER (Depending on the control unit which carries out CAN communication).
2. Removal/installation of parts: Error may be detected when removing and installing CAN communication unit and related parts while turning the ignition switch ON. (A DTC except for CAN communication may be detected.)
3. Fuse blown out (removed): CAN communication of the unit may cease.
4. Voltage drop: Error may be detected if voltage drops due to discharged battery when turning the ignition switch ON (Depending on the control unit which carries out CAN communication).
5. Error may be detected if the power supply circuit of the control unit, which carries out CAN communication, malfunctions (Depending on the control unit which carries out CAN communication).
6. Error may be detected if reprogramming is not completed normally.

Note. CAN communication system is normal if "U1000" or "U1001" is indicated on SELF-DIAG RESULTS of CONSULT-II under the above conditions. Erase the memory of the self-diagnosis of each unit.

ERROR EXAMPLE

Note. Each vehicle differs in symptom of each unit under fail-safe mode and CAN communication line wiring. Refer to , " ABBREVIATION LIST " for the unit abbreviation.

Example: TCM branch line open circuit

Diagnosis For TCM Branch Line Open Circuit. Scheme 119

SYMPTOM DESCRIPTION

Example: Data link connector branch line open circuit

Diagnosis For Data Link Connector Branch Line Open Circuit. Scheme 120

SYMPTOM DESCRIPTION

Note. When data link connector branch line is open, transmission and reception of CAN communication signals is not affected. Therefore, no symptoms occur. However, be sure to repair malfunctioning circuit. When data link connector branch line is open, the screen-display of the CONSULT-II "SELECT SYSTEM" screen may be the same as when the CAN communication line has short-circuit. However, symptoms differ depending on the case. See below chart for the differences.

DIFFERENCE OF SYMPTOM

Example: Main Line Between Data Link Connector and ABS Actuator and Electric Unit (Control Unit) Open Circuit

Diagnosis For Main Line Between Data Link Connector And ABS Actuator Circuit. Scheme 121

MAIN LINE BETWEEN DATA LINK CONNECTOR AND ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) OPEN CIRCUIT

Example: CAN-H, CAN-L Harness Short Circuit

Diagnosis For CAN-H, CAN-L Harness Short Circuit. Scheme 122

CAN-H, CAN-L HARNESS SHORT CIRCUIT

Self-Diagnosis

DTC DETECTION CONDITION

MONITOR ITEM (CONSULT-II)

Example: CAN DIAG SUPPORT MNTR indication

CONSULT-II Display - CAN DIAG SUPPORT MNTR Indication. Scheme 123

Without PAST

MONITOR ITEM (CONSULT-II) - WITHOUT PAST

With PAST

MONITOR ITEM (CONSULT-II) - WITH PAST

How to Use CAN Communication Signal Chart

The CAN communication signal chart lists the signals needed for trouble diagnosis. It is useful for detecting the root cause by finding a signal related to the symptom, and by checking transmission and reception unit.

CAN Communication Signal Chart. Scheme 124

Trouble Diagnosis Flow Chart. Scheme 125

INTERVIEW WITH CUSTOMER

Interview with the customer is important to detect the root cause of CAN communication system errors and to understand vehicle condition and symptoms for proper trouble diagnosis.

Points in interview

1. What: Parts name, system name
2. When: Date, Frequency
3. Where: Road condition, Place
4. In what condition: Driving condition/environment
5. Result: Symptom

Note. Check normal units as well as error symptoms. Example: Circuit between ECM and the combination meter is judged normal if the customer indicates tachometer functions normally. When a CAN communication system error is present, multiple control units may malfunction or go into fail-safe mode. Indication of the combination meter is important to detect the root cause because it is the most obvious from the customer, and it performs CAN communication with many units.

Identifying Combination Meter. Scheme 126

CREATE INTERVIEW SHEET

Fill out the symptom described by the customer, vehicle condition, and CAN system type on the interview sheet.

CAN Communication System Diagnosis Interview Sheet. Scheme 127

Create CONSULT-II Data Attachment Sheet

Print out the following CONSULT-II screens, and attach them to the CONSULT-II data attachment sheet.

1. SELECT SYSTEM
2. SELF-DIAG RESULTS
3. CAN DIAG SUPPORT MNTR

Note. Some items may not be needed depending on CAN system type of vehicle.

Display - Data Attachment Sheet. Scheme 128

Check of Received Data

Check the created data sheet for missing information.

1. For abbreviations, refer to , " «ABBREVIATION LIST»(ref-277060-S21943522092008011500000) ".

Display - Data Sheet For Missing Information. Scheme 129

DETECT THE ROOT CAUSE

Identify the root cause using the created diagnosis sheet.

Identifying the root cause

1. Draw a line on the diagnosis sheet to indicate the possible cause. Narrow the search. NOTE: Color-code when drawing lines. Do not draw a line onto a existing line.
2. Drawing a line is not necessary if the circuit is shorted. Refer to , " «PRESENT ERROR - SHORT CIRCUIT»(ref-277060-S34584063212008011500000) ", , " «PAST ERROR - SHORT CIRCUIT»(ref-277060-S39888626512008011500000) ".

Refer to the following for details of the trouble diagnosis procedure.

1. " «PRESENT ERROR- OPEN CIRCUIT»(ref-277060-S15741342602008011500000) "
2. " «PRESENT ERROR - SHORT CIRCUIT»(ref-277060-S34584063212008011500000) "
3. " «PAST ERROR - OPEN CIRCUIT»(ref-277060-S42760651862008011500000) "
4. " «PAST ERROR - SHORT CIRCUIT»(ref-277060-S39888626512008011500000) "

Note. When the root cause appears to be a branch line or short circuit, be sure to check the control unit as well as the communication line.

Present Error - Open Circuit

Identify the error circuit using information from the "SELECT SYSTEM" and "CAN DIAG SUPPORT MNTR" screens.

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. SELECT SYSTEM: Check the items indicated in "SELECT SYSTEM". Draw a line on the diagnosis sheet to indicate the error circuit. NOTE: CAN communication line has no error if units other than Diag on CAN units are indicated. An error may be on the power supply of the control unit, DDL1 line or DDL2 line. "TRANSMISSION" which is Diag on CAN unit, is not indicated on "SELECT SYSTEM" screen. This indicates that DLC is not receiving a signal from TCM. Draw a line to indicate an error between DLC and TCM (line 1-a in (Scheme 130) ). NOTE: Diag on CAN units are not indicated on the "SELECT SYSTEM" screen when the CAN line between Diag on CAN unit and the data link connector is open. For a description of Diag on CAN, refer to, " «DIAG ON CAN»(ref-277060-S07413551312008011500000) ". (Scheme 130): Present Error - Open Circuit Diagram
2. CAN DIAG SUPPORT MNTR: Check each item on "CAN DIAG SUPPORT MNTR". Draw a line on the diagnosis sheet to indicate the error circuit. Reception item of "ENGINE": On "TCM", "UNKWN" is indicated. This means ECM cannot receive the signal from TCM. Draw a line to indicate an error between ECM and TCM (line 2-a in (Scheme 131) ). NOTE: If "UNKWN" is indicated on "TRANSMIT DIAG", then the control unit cannot transmit CAN communication signal to each unit. Draw a line between the control unit and the splice. Reception item of "ADAPTIVE LIGHT": On "TCM", "UNKWN" is indicated. This means AFS cannot receive the signal from TCM. Draw a line to indicate an error between AFS and TCM (line 2-b in (Scheme 131) ). Reception item of "MULTI AV": "UNKWN" is not indicated. This indicates normal communication between AV and its receiving units. Do not draw any line. (Scheme 131): CAN Communication Diagram (1 Of 5) Reception item of "BCM": On "TCM", "UNKWN" is indicated. This means BCM cannot receive the signal from TCM. Draw a line to indicate an error between BCM and TCM (line 2-d in (Scheme 132) ). Reception item of "EPS" and "INTELLIGENT KEY": "UNKWN" is not indicated. This indicates normal communication between EPS and I-KEY and their receiving units. Do not draw any line. NOTE: On CAN DIAG SUPPORT MNTR (without PAST), "UNKWN" is indicated even though the item is not used in the trouble diagnosis. For the details of each item on CAN diagnostic support monitor, refer to, " «CAN DIAGNOSTIC SUPPORT MONITOR»(ref-277060-S36967869402008011500000) ". (Scheme 132): CAN Communication Diagram (2 Of 5) Reception item of "METER": On "TCM", "UNKWN" is indicated. This means M&A cannot receive the signal from TCM. Draw a line to indicate an error between M&A and TCM (line 2-f in (Scheme 133) ). Reception item of "AUTO DRIVE POS.": On "TCM", "UNKWN" is indicated. This means ADP cannot receive the signal from TCM. Draw a line to indicate an error between ADP and TCM (line 2-g in (Scheme 133) ). Reception item of "ABS": "UNKWN" is not indicated. This indicates normal communication between ABS and its receiving units. Do not draw any line. (Scheme 133): CAN Communication Diagram (3 Of 5) Reception item of "IPDM E/R": "UNKWN" is not indicated. This indicates normal communication between IPDM-E and its receiving units. Do not draw any line.
3. Based on information received from "CAN DIAG SUPPORT MNTR", place a check mark on the known good CAN communication line between ECM and IPDM-E. Through the previous procedure, the circuit between ADP splice and TCM has the most amount of lines (shade 3-a in (Scheme 134) ). Place a check mark on the known good lines to establish the error circuit. Reception item of "IPDM E/R": On "ECM", "OK" is indicated. IPDM-E communicates normally with ECM. Put a check mark on the normal circuit between ECM and IPDM-E (check mark 3-b in (Scheme 134) ). (Scheme 134): CAN Communication Diagram (4 Of 5)
4. Through the above procedure, the error is detected in the TCM branch line (shaded in (Scheme 135) ). NOTE: For abbreviations, refer to, " «ABBREVIATION LIST»(ref-277060-S21943522092008011500000) ".
5. Perform the inspection for the detected error circuit. For the inspection procedure, refer to, " «MALFUNCTION AREA CHART»(ref-277060-S31014571732008011500000) ". (Scheme 135): CAN Communication Diagram (5 Of 5)

Present Error - Short Circuit

When the symptoms listed below exist, a short circuit of the CAN communication line is a possible cause.

Received data

DATA DESCRIPTION

Error symptom

1. Most the units connected to the CAN communication system go into fail-safe mode or are deactivated.

Past Error - Open Circuit

Review CAN communication signal chart based on information received from the interview with the customer and on past error information from SELF-DIAG RESULTS and CAN DIAG SUPPORT MNTR.

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. SELF-DIAG RESULTS: Inspect the control units indicating "U1000" or "U1001" on SELF-DIAG RESULTS. (Scheme 136): Past Error - Open Circuit Diagram
2. CAN DIAG SUPPORT MNTR (with PAST): Check the CAN DIAG SUPPORT MNTR (with PAST) of units indicating "U1000" or "U1001" on SELF-DIAG RESULTS. Draw a line on the diagnosis sheet to indicate the possible error circuit. NOTE: For the details of each indication on CAN DIAG SUPPORT MNTR, refer to, " «CAN DIAGNOSTIC SUPPORT MONITOR»(ref-277060-S36967869402008011500000) ". Reception item of "ENGINE": "VDC/TCS/ABS", "3" is indicated in the "PAST". This means ECM could not receive the signal from ABS in the past. Draw a line between ECM and ABS (line 2-a in (Scheme 137) ). Reception item of "METER": "VDC/TCS/ABS", "3" is indicated in the "PAST". This means M&A could not receive the signal from ABS in the past. Draw a line between M&A and ABS (line 2-b in (Scheme 137) ). Reception item of "TRANSMISSION": "VDC/TCS/ABS", "3" is indicated in the "PAST". This means TCM could not receive the signal from ABS in the past. Draw a line between TCM and ABS (line 2-c in (Scheme 137) ). (Scheme 137): CAN Communication Circuit Diagram (1 Of 5)
3. CAN DIAG SUPPORT MNTR (without PAST): Check the CAN DIAG SUPPORT MNTR (without PAST) of units indicating "U1000" or "U1001" on SELF-DIAG RESULTS. Draw a line on the diagnosis sheet to indicate the possible error circuit. NOTE: While an error occurred in the past according to SELF-DIAG RESULTS, it is unclear which signal is not received. Assume that errors were detected from all reception items. Draw a single line among the unit and all reception items. (Work flow differs from CAN DIAG SUPPORT MNTR (with PAST).) Reception item of "EPS": Assume that the unit could not receive the signals from ECM, ABS, and M&A. Draw a line among EPS, ECM, ABS, and M&A (line 3-a in (Scheme 138) ). Reception item of "ABS": Assume that the unit could not receive the signal from ECM. Draw a line between ABS and ECM (line 3-b in (Scheme 138) ). (Scheme 138): CAN Communication Circuit Diagram (2 Of 5)
4. Search for the possible cause using CAN communication signal chart using information from the interview with the customer. NOTE: For the details of CAN communication signal, refer to, " «CAN COMMUNICATION SIGNAL CHART»(ref-277060-S35933427662008011500000) ". ABS warning lamp turned ON and speedometer did not move: This means that "ABS warning lamp signal" and "Vehicle speed signal" could not communicate between M&A and ABS (4-a in (Scheme 139) ). The tachometer moved normally: This means that "Engine speed signal" could communicate normally between ECM and M&A (4-b in (Scheme 139) ). (Scheme 139): CAN Communication Circuit Diagram (3 Of 5)
5. Fill out the diagnosis sheet based on information from step 4. The ABS warning lamp turned ON and speedometer did not move: Assume that a possible cause is no communication between M&A and ABS. Draw a line between M&A and ABS. (Line 5-a in (Scheme 140) ). The tachometer moved normally: Put check marks between ECM and M&A. The circuit between ECM and M&A is functioning properly (check marks 5-b in (Scheme 140) ). (Scheme 140): CAN Communication Circuit Diagram (4 Of 5)
6. The circuit which has the most amount of lines are the possible cause. Error is detected from ABS actuator and electric unit (control unit) branch line (shaded in (Scheme 141) ). NOTE: For abbreviations, refer to, " «ABBREVIATION LIST»(ref-277060-S21943522092008011500000) ".
7. Perform the inspection procedure for the possible cause. Refer to, " «MALFUNCTION AREA CHART»(ref-277060-S31014571732008011500000) ". (Scheme 141): CAN Communication Circuit Diagram (5 Of 5)

Past Error - Short Circuit

When the symptoms listed below exist, a short circuit of the CAN communication line is a possible cause.

COMMUNICATION LINE DESCRIPTION

Past Error - Short Circuit Diagram. Scheme 142

Caution

1. This section describes information peculiar to a vehicle, sheets for trouble diagnosis, and inspection procedures.
2. For trouble diagnosis procedure, refer to , " «TROUBLE DIAGNOSIS PROCEDURE»(ref-277060-S04389005612008011500000) ".

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SUPPLEMENTAL RESTRAINT SYSTEM and SEAT BELTS .

Use CONSULT-II CONVERTER when connecting CONSULT-II to data link connector.

ECM

0: Error at present, 1 - 39: Error in the past (Number means the number of times the ignition switch is turned OFF --> ON)

ECM MONITOR ITEM LIST (CONSULT-II)

TCM

Note. Replace the unit when "NG" is indicated on the "INITIAL DIAG".

TCM MONITOR ITEM LIST (CONSULT-II)

Transfer Control Unit

Note. Replace the unit when "NG" is indicated on the "INITIAL DIAG".

TRANSFER CONTROL UNIT MONITOR ITEM LIST (CONSULT-II)

BCM

Note. Replace the unit when "NG" is indicated on the "INITIAL DIAG".

BCM MONITOR ITEM LIST (CONSULT-II)

Differential Lock Control Unit

Note. Replace the unit when "NG" is indicated on the "INITIAL DIAG".

DIFFERENTIAL LOCK CONTROL UNIT DESCRIPTION

Combination Meter

0: Error at present, 1 - 39: Error in the past (Number means the number of times the ignition switch is turned OFF --> ON)

COMBINATION METER DESCRIPTION

ABS Actuator and Electric Unit (Control Unit) (Models with ABS)

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) (MODELS WITH ABS)

ABS Actuator and Electric Unit (Control Unit) (Models with ABLS/Models with VDC)

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) (MODELS WITH ABLS/MODELS WITH VDC)

IPDM E/R

0: Error at present, 1 - 39: Error in the past (Number means the number of times the ignition switch is turned OFF --> ON)

IPDM E/R

CAN Communication Signal Chart

Refer to , " HOW TO USE CAN COMMUNICATION SIGNAL CHART " for how to use CAN communication signal chart.

TYPE 1/TYPE 3

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 1/TYPE 3. Scheme 143

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 2/TYPE 5

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 2/TYPE 5. Scheme 144

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 4

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 4. Scheme 145

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 6/TYPE 7

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 6/TYPE 7. Scheme 146

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 8

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 8. Scheme 147

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 9/TYPE 10

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 9/TYPE 10. Scheme 148

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 11

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 11. Scheme 149

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 12/TYPE 13

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 12/TYPE 13. Scheme 150

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

TYPE 14/TYPE 15

Note. Refer to , " ABBREVIATION LIST " for the abbreviations of the connecting units.

CAN Communication Signal Chart For TYPE 14/TYPE 15. Scheme 151

Note. CAN data of the air bag diagnosis sensor unit is not used by usual service work, thus it is omitted.

CAN Communication System Schematic Diagram. Scheme 152

MAIN LINE

MAIN LINE MALFUNCTION AREA CHART

BRANCH LINE

BRANCH LINE MALFUNCTION AREA CHART

SHORT CIRCUIT

MALFUNCTION AREA REFERENCE
