Driver Information System: Diagnosis Nissan Frontier D40

Communication Devices 5 illustrations ~1230 words

SELF-DIAGNOSIS FUNCTION

The following items can be checked during Combination Meter Self-Diagnosis Mode.

  1. Gauge sweep and present gauge values.
  2. Illuminates all odometer/trip meters and A/T indicator segments.
  3. Illuminates all micro controlled lamps/LEDs regardless of switch position.
  4. Displays estimated present battery voltage.
  5. Displays seat belt buckle switch LH status.

HOW TO INITIATE COMBINATION METER SELF-DIAGNOSIS MODE

Note. Once entered, Combination Meter Self-Diagnosis Mode will function with the ignition switch in ON or START. Combination Meter Self-Diagnosis Mode will exit upon turning the ignition switch to OFF or ACC.

To initiate Combination Meter Self-Diagnosis Mode, refer to the following procedure.

  1. Turn the ignition switch ON, while pressing the odometer/trip meter switch for 5-8 seconds. When the diagnosis function is activated the odometer/trip meter will display tESt. NOTE: Check combination meter power supply and ground circuit when self-diagnosis mode of combination meter does not start. Refer to " «POWER SUPPLY AND GROUND CIRCUIT INSPECTION»(ref-272357-S06239046642007111800000) ". Replace combination meter if normal. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ".

COMBINATION METER SELF-DIAGNOSIS MODE FUNCTIONS

To interpret Combination Meter Self-Diagnosis Mode functions, refer to the following table.

EventOdometer DisplayDescription of Test/DataNotes
Odometer/trip meter A/B switch held from 5 to 8 seconds (or until released)TEStInitiating self-diagnosis mode
Next test requestedGAGEPerforms sweep of all gauges, then displays present gauge values. Performs checksum tests on ROM and EE.Gauges sweep within 10 seconds
Next test requested(All segments illuminated)Lights all odometer/trip meter segments.Initiating self-diagnosis mode complete
Next test requestedBulbIlluminates all micro-controlled lamps/LEDs regardless of SW configuration.
Odometer/trip meter A/B switch engaged and released = next test requestedRXXXX, FAILReturn to normal operation of all lamps/LEDs and displays hex ROM rev. If a ROM checksum fault exists, display alternates between "r XXXX" and "FAIL".
Next test requestedNrXXXXDisplays hex ROM rev as stored in NVM.
Next test requestedEE XX, FAILHex EE level. If EE checksum fault exists, display alternates between "EE XX" and "FAIL".
Next test requestedDtXXXXHex coding of final manufacturing test date.
Next test requestedSc1XXDisplays 8-bit software configuration value in Hex format.Bit Coding 7-3 = reserved for future use 2 = TCS/VDC 0 = not present 1 = present 1 = Shift type 0 = Column shift 1 = Floor shift 0 = ICC 0 = not present 1 = present
Next test requestedSc2XXDisplays 8-bit software configuration value in Hex format.Bit coding 7-0 = Reserved for future use
Next test requestedEprXXDisplays 8-bit software configuration value in Hex format.Bit Coding 7-2 = reserved for future use 1 = A/T Oil Temp (gauge) 0 = not present 1 = present 1 = Odo Units 0 = kilometers 1 = miles
Next test requested1nFXXDisplays 8-bit market info value in Hex format.$31 = USA $2A = Canada
Next test requestedCYLXXDisplays 8-bit engine configuration value in Hex format.$08 = 8 cylinder $06 = 6 cylinder
Next test requestedFFXXXXDisplays 16-bit fuel flow constant "Q" in tenths of cc/min in Hex format.$0000 - $FFFF
Next test requestedTFDisplays 16-bit tire factor "A" in hundredths in Hex format.$0000 - $FFFF
Next test requestedOt1XXDisplays oil pressure telltale "on" threshold in A/D counts in Hex format.$00 - $FF
Next test requestedOt0XXDisplays oil pressure telltale "off" threshold in A/D counts in Hex format.$00 - $FF
Next test requestedXXXXXRaw uncompensated english speed value in hundredths of MPH. Speedometer indicates present speed.Will display "-" if message is not received. Will display "99999" if data received is invalid
Next test requestedXXXXXRaw uncompensated metric speed value in hundredths of km/h. Speedometer indicates present speed.Will display "-" if message is not received. Will display "99999" if data received is invalid
Next test requestedTXXXXTachometer value in RPM. Tachometer indicates present RPM.Will display "-" if message is not received.
Next test requestedF1 XXXXPresent ratioed fuel level A/D input 1 in decimal format. Fuel gauge indicates present filtered level.000-009 = Short circuit 010-254 = Normal range 255 = Open circuit - = Missing 5 seconds
Next test requestedXXXCLast temperature gauge input value in degrees C. Temperature gauge indicates present filtered temperature.Will display "-" C if message is not received. Will display "999" if data received is invalid.
Next test requestedBAtXX.XEstimated present battery voltage.
Next test requestedRES-XSeat belt buckle switch LH status.1= Buckled 0 = Unbuckled
Next test requestedPA-XXHex value port A.
Next test requestedPb-XXHex value port B.
Next test requestedPE-XXHex value port E.
Next test requestedPL-XXHex value port L.
Next test requestedP6-XXHex value port K.
Next test requestedPn-XXHex value port M.
Next test requestedPP-XXHex value port P.
Next test requestedPS-XXHex value port S.
Next test requestedPt-XXHex value port T.
Next test requestedPu-XXHex value port U.
Next test requestedP4-XXHex value port V.
Next test requestedPuu-XXHex value port W.
Next test requestedA00XXXA/D port A/D value (nonratioed).0-255
Next test requestedA01XXXA/D port A/D value (nonratioed).0-255
Next test requestedA02XXXA/D port A/D value (nonratioed).0-255
Next test requestedA03XXXA/D port A/D value (nonratioed).0-255
Next test requestedA04XXXA/D port A/D value (nonratioed).0-255
Next test requestedA05XXXA/D port A/D value (nonratioed).0-255
Next test requestedA06XXXA/D port A/D value (nonratioed).0-255
Next test requestedA07XXXA/D port A/D value (nonratioed).0-255
Next test requestedA08XXXA/D port A/D value (nonratioed).0-255
Next test requestedA09XXXA/D port A/D value (nonratioed).0-255
Next test requestedA10XXXA/D port A/D value (nonratioed).0-255
Next test requestedA11XXXA/D port A/D value (nonratioed).0-255
Next test requestedA12XXXA/D port A/D value (nonratioed).0-255
Next test requestedA13XXXA/D port A/D value (nonratioed).0-255
Next test requestedA14XXXA/D port A/D value (nonratioed).0-255
Next test requestedA15XXXA/D port A/D value (nonratioed).0-255
Next test requestedPA0-XXHex value representing state of A/D ports 0-7.
Next test requestedPA1-XXHex value representing state of A/D ports 0-7.
Next test requestedGAGEReturn to beginning of selfdiagnosis.

SELF-DIAGNOSIS MODE FUNCTIONS

How to Proceed With Trouble Diagnosis

  1. Confirm the symptom or customer complaint.
  2. Perform preliminary check. Refer to «PRELIMINARY CHECK»(ref-272357-S28466223472007111800000) .
  3. According to the symptom chart, repair or replace the cause of the symptom.
  4. Does the meter operate normally? If so, go to 5. If not, go to 2 .
  5. Inspection End.

Scheme 5

Scheme 5: Preliminary Check
Scheme 5: Preliminary Check
  1. CHECK WARNING INDICATOR ILLUMINATION Turn ignition switch ON. Make sure warning indicators (such as malfunction indicator lamp and oil pressure warning indicator) illuminate. Do warning indicators illuminate? YES: GO TO 2. NO: Check ignition power supply system of combination meter. Refer to " «POWER SUPPLY AND GROUND CIRCUIT INSPECTION»(ref-272357-S06239046642007111800000) ".
  2. CHECK OPERATION OF SELF-DIAGNOSIS MODE (COMBINATION METER) Perform self-diagnosis mode of combination meter. Refer to. Does self-diagnosis mode operate normally? YES: GO TO 3. NO: Check combination meter power supply and ground circuit. Refer to " «POWER SUPPLY AND GROUND CIRCUIT INSPECTION»(ref-272357-S06239046642007111800000) ".
  3. CHECK ODOMETER OPERATION Check segment display status of odometer. Is the display normal? YES: GO TO 4. NO: Replace the combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ". see scheme 7: Checking Odometer Operation
  4. CHECK COMBINATION METER CIRCUIT Check operation of each meter/gauge in self-diagnosis mode. OK or NG OK: GO TO 5. NG: Replace the combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ".
  5. CHECK SELF-DIAGNOSTIC RESULTS OF METER Select "METER" on CONSULT-II and perform self-diagnosis of meter. Self-diagnostic results content CAN COMM CIRC [U1000]>> Refer to " «DTC [U1000] CAN COMMUNICATION CIRCUIT»(ref-272357-S42267132992007111800000) ". VEHICLE SPEED CIRC [B2205]>> Refer to " «DTC [B2205] VEHICLE SPEED CIRCUIT»(ref-272357-S13725318482007111800000) ".

Symptom Chart

Trouble phenomenonPossible cause
Improper tachometer indication.Refer to " ENGINE SPEED SIGNAL INSPECTION ".
Improper water temperature gauge indication.Refer to " WATER TEMPERATURE SIGNAL INSPECTION ".
Improper speedometer or odometer.Refer to " VEHICLE SPEED SIGNAL INSPECTION ".
Improper fuel gauge indication.Refer to " FUEL LEVEL SENSOR UNIT INSPECTION ".
Fuel warning lamp indication is irregular.
Improper voltage gauge indication.Replace combination meter. Refer to " COMBINATION METER ".
More than one gauge does not give proper indication.
Improper A/T position indication.Refer to " A/T INDICATOR ".
Illumination control does not operate properly.Replace combination meter. Refer to " COMBINATION METER ".

SYMPTOM CHART

Scheme 6

Scheme 6: Power Supply and Ground Circuit Inspection
Scheme 6: Power Supply and Ground Circuit Inspection

Scheme 7

Scheme 7
Scheme 7
  1. CHECK FUSES Check for blown combination meter fuses. COMBINATION METER FUSES Unit Power source Fuse No. Combination meter Battery 19 Ignition switch ON or START 14 Refer to " «WIRING DIAGRAM - METER»(ref-272357-S31073141972007111800000) ". OK or NG OK: GO TO 2. NG: If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to " «POWER SUPPLY ROUTING CIRCUIT»(ref-272337-S41287445542007111800000) ".
  2. CHECK POWER SUPPLY CIRCUIT Disconnect combination meter connector. Check voltage between combination meter harness connector terminals and ground. CONNECTOR TERMINAL VOLTAGE REFERENCE Terminals Ignition switch position (+) (-) OFF ACC ON Connector Terminal M24 3 Ground Battery voltage Battery voltage Battery voltage 16 0V 0V Battery voltage (Scheme 5): Checking Voltage Between Combination Meter Harness Connector Terminals And Ground OK or NG OK: GO TO 3. NG: Check the harness for open between combination meter and fuse.
  3. CHECK GROUND CIRCUIT Turn ignition switch off. Check continuity between combination meter harness connector terminals and ground. CONNECTOR TERMINAL CONTINUITY REFERENCE Terminals Continuity (+) (-) Connector Terminal M24 13 Ground Yes 23 (Scheme 6): Checking Continuity Between Combination Meter Harness Connector Terminals And Ground OK or NG OK: Inspection End. NG: Repair harness or connector.

Vehicle Speed Signal Inspection

  1. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS Refer to " «SELF-DIAGNOSIS»(ref-272358-S37860999422007111800000) " (ABS), " «SELF-DIAGNOSIS»(ref-272358-S40822253462007111800000) " (ABLS/ABS) or " «SELF-DIAGNOSIS»(ref-272358-S16707943252007111800000) " (HDC/HSA/VDC/TCS/ABS). OK or NG OK: Replace the combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ". NG: Perform the "Diagnostic Procedure" for displayed DTC.

Scheme 8

Scheme 8: Engine Oil Pressure Signal Inspection
Scheme 8: Engine Oil Pressure Signal Inspection

Scheme 9

Scheme 9
Scheme 9
  1. CHECK SELF-DIAGNOSTIC RESULTS OF IPDM E/R Select "IPDM E/R" on CONSULT-II, and perform self-diagnosis of IPDM E/R. Refer to " «SELF-DIAGNOSTIC RESULTS»(ref-272337-S40250253152007111800000) ". Self-diagnostic results content No malfunction detected: GO TO 2. Malfunction detected: GO TO " «DISPLAY ITEM LIST»(ref-272337-S26597026372007111800000) ".
  2. CHECK IPDM E/R INPUT SIGNAL Select "IPDM E/R" on CONSULT-II. Operate ignition switch with "OIL P SW" of "DATA MONITOR" and check operation status. When ignition switch is in ON position (Engine stopped): OIL P SW CLOSE When engine running: OIL P SW OPEN OK or NG OK: Replace combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ". NG: GO TO 3. (Scheme 7): CONSULT II DATA MONITOR Screen
  3. CHECK OIL PRESSURE SWITCH CIRCUIT Turn ignition switch OFF. Disconnect IPDM E/R connector E122 and oil pressure switch connector E208. Check continuity between IPDM E/R harness connector E122 (A) terminal 42 and oil pressure switch harness connector F4 (B) terminal 1. Continuity should exist. (Scheme 8): Checking Continuity Between IPDM E/R Harness Connector E122 Terminal 42 And Oil Pressure Switch Harness F4 Terminal 1 OK or NG OK: GO TO 4. NG: Repair harness or connector.
  4. CHECK OIL PRESSURE SWITCH Check oil pressure switch. Refer to " «OIL PRESSURE SWITCH CHECK»(ref-272357-S26655123552007111800000) ". OK or NG OK: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION OF IPDM E/R»(ref-272337-S22727732142007111800000) ". NG: Replace oil pressure switch.

Water Temperature Signal Inspection

  1. CHECK ECM SELF-DIAGNOSIS Perform ECM self-diagnosis. Refer to " «SELF-DIAG RESULTS MODE»(ref-272338-S05054992442007111800000) " (QR25DE) or " «SELF-DIAG RESULTS MODE»(ref-272339-S25830931772007111800000) " (VQ40DE). OK or NG OK: Replace the combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ". NG: Perform "Diagnostic procedure" for displayed DTC.

Engine Speed Signal Inspection

  1. CHECK ECM SELF-DIAGNOSIS Perform ECM self-diagnosis. Refer to " «SELF-DIAG RESULTS MODE»(ref-272338-S05054992442007111800000) " (QR25DE) or " «SELF-DIAG RESULTS MODE»(ref-272339-S25830931772007111800000) " (VQ40DE). OK or NG OK: Replace the combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ". NG: Perform "Diagnostic procedure" for displayed DTC.

DTC [U1000] CAN Communication Circuit

Symptom: Display CAN COMM CIRC [U1000] at the result of self-diagnosis for combination meter.

  1. CHECK CAN COMMUNICATION Select "SELF-DIAG RESULTS" mode for "METER" with CONSULT-II. Print out CONSULT-II screen. : Go to "CAN SYSTEM". Refer to TROUBLE DIAGNOSIS in LAN System article.

DTC [B2205] Vehicle Speed Circuit

Symptom: Display VEHICLE SPEED CIRC [B2205] at the result of self-diagnosis for combination meter.

  1. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) Perform ABS actuator and electric unit (control unit) self-diagnosis. Refer to " «SELF-DIAGNOSIS»(ref-272358-S37860999422007111800000) " (ABS), " «SELF-DIAGNOSIS»(ref-272358-S40822253462007111800000) " (ABLS/ABS) or " «SELF-DIAGNOSIS»(ref-272358-S16707943252007111800000) " (HDC/HSA/VDC/TCS/ABS). Are self-diagnosis result items displayed? YES: After checking and repairing the applicable item, perform the ABS actuator and electric unit (control unit) self-diagnosis again. NO: Replace combination meter. Refer to " «COMBINATION METER»(ref-272364-S06033080672007111800000) ".

INSPECTION/COMPASS AND THERMOMETER

SymptomPossible causesRepair order
No display at all1. 10A fuse.1. Check 10A fuse [No. 14 located in the fuse block (J/B)]. Turn the ignition switch ON and verify that battery positive voltage is at terminal 6 of auto anti-dazzling inside mirror.
2. Power circuit.2. Check power circuit for auto anti-dazzling inside mirror.
3. Ground circuit.3. Check ground circuit for auto anti-dazzling inside mirror.
4. Auto anti-dazzling inside mirror.4. Replace auto anti-dazzling inside mirror.
Forward direction indication slips off the mark or incorrect.1. In manual correction mode (Bar and display vanish).1. Drive the vehicle and turn at an angle of 90°.
2. Zone variation change is not done.2. Perform the zone variation change.
Displays wrong temperature when ambient temperature is between -40°C (-40°F) and 55°C (130°F)1. Check operation.1. Perform preliminary check shown above.
2. Ambient sensor 2 circuit.2. Check harness for open or short between ambient sensor 2 and auto anti-dazzling inside mirror.
3. Ambient sensor 2.3. Replace ambient sensor 2.
4. Auto anti-dazzling inside mirror.4. Replace auto anti-dazzling inside mirror.
Displays SC or OC1. Ambient sensor 2 circuit.1. Check harness for open or short between ambient sensor 2 and auto anti-dazzling inside mirror.
2. Ambient sensor 2.2. Replace ambient sensor 2.
3. Auto anti-dazzling inside mirror.3. Replace auto anti-dazzling inside mirror.

SYMPTOM CHART

  1. Confirm the symptom or customer complaint.
  2. Understand operation description and function description. Refer to " «SYSTEM DESCRIPTION»(ref-272357-S22684372362007111800000) ".
  3. Perform the preliminary check. Refer to " «PRELIMINARY CHECK»(ref-272357-S02438977852007111800000) ".
  4. Check symptom and repair or replace the cause of malfunction.
  5. Does the warning chime operate properly? If so, go to 6. If not, go to 3 .
  6. Inspection End.

INSPECTION FOR POWER SUPPLY AND GROUND CIRCUIT

Refer to " BCM POWER SUPPLY AND GROUND CIRCUIT CHECK ".

DIAGNOSIS PROCEDURE

SymptomPossible causeRepair order
DTE (distance to empty) is not displayed properly.Average fuel consumption display Fuel tank gauge signal circuitMake sure fuel consumption is displayed properly. If NG, check fuel consumption display. Make sure fuel gauge operates properly. If NG, check fuel gauge.
Trip distance is not indicated properly.ABS actuator and electric unit (control unit)Perform ABS actuator and electric unit (control unit) self diagnosis.
Trip time is not indicated properly.Fuse10A fuse [No. 19 located in fuse block (J/B)]. Verify battery voltage is present at combination meter terminal 3.
Average fuel consumption is not displayed properly.Trip distance display Fuel consumption signalPerform ABS actuator and electric unit (control unit) self-diagnosis. Check CAN lines for open or short between ECM and combination meter.
Average vehicle speed is not indicated properly.Trip distance display Trip time displayPerform ABS actuator and electric unit (control unit) self-diagnosis. Make sure trip time is displayed properly. If NG, check trip time display.

SYMPTOM CHART
