Lan System: Overview Nissan Frontier D40

Communication Devices 2 illustrations ~110 words

DESCRIPTION

"Diag on CAN" is a diagnosis using CAN communication instead of previous DDL1 and DDL2 communication line, between control unit and diagnosis unit.

CAN Communication System Diagram. Scheme 85

Scheme 85: CAN Communication System Diagram
NameHarnessDescription
DDL1Tx RxIt is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling)
DDL2K-LINEIt is used for trouble diagnosis. (CAN-H and CAN-L are used for controlling)
Diag on CANCAN-H CAN-LIt is used for trouble diagnosis and control.

HARNESS DESCRIPTION

Abbreviation List

Abbreviations in CAN communication signal chart, and the diagnosis sheet are as per the following list.

AbbreviationUnit nameSELECT SYSTEM (CONSULT-II)CAN DIAG SUPPORT MNTR (CONSULT-II)
4WDTransfer control unitALL MODE AWD/4WDAWD/4WD
A-BAGAir bag diagnosis sensor unitAIR BAG
ABSABS actuator and electric unit (control unit)ABSVDC/TCS/ABS
BCMBCMBCMBCM/SEC
DIFFDifferential lock control unitDIFF LOCKDIFF LOCK
DLCData link connector
ECMECMENGINEECM
IPDM-EIPDM E/RIPDM E/RIPDM E/R
M&ACombination meterMETERMETER/M&A
STRGSteering angle sensorSTRG
TCMTCMA/TTCM

ABBREVIATION LIST

VEHICLE EQUIPMENT IDENTIFICATION INFORMATION

Note. Check CAN system type from the vehicle shape and equipment. Models with ABLS see scheme 36: Identifying Vehicle Equipment Identification Information (Models With ABLS) Models with VDC see scheme 37: Identifying VDC OFF Switch (Models With VDC) Models with electronic locking rear differential

Identifying Differential Lock Mode Switch. Scheme 86

Scheme 86: Identifying Differential Lock Mode Switch
