Driver Assistance System (Mod) (Sedan): Adjustments Nissan Altima L33

Collision/avoidance 1 illustration ~369 words

Work Procedure (Rear View Camera Calibration)

CAUTIONPerform the calibration under the specified vehicle condition (fuel full, no-load, specified tire pressure, etc.). Refer to " WORK PROCEDURE (PREPARATION) ".

Scheme 104

Scheme 104
Scheme 104
  1. CHECK REAR VIEW CAMERA HEIGHT Measure the rear view camera height "H". >> GO TO 2.
  2. REAR VIEW CAMERA CALIBRATION Select "Work Support" on "AVM" with CONSULT. Select "REAR CAMERA ITS". Select "OK". CAUTION: Perform the calibration after the ignition or engine has been kept on for at least 10 minutes to stabilize camera. Operate CONSULT outside the vehicle, and close all doors to retain appropriate vehicle altitude. Input the rear view camera height "H", and then touch "APPLY". Confirm that the same value is displayed on the center display. Confirm the following items: The target should be accurately placed. The vehicle should be stopped. The vehicle should be under the specified vehicle condition. Select "Start" to perform calibration. Confirm the displayed item. "Completed": Select "Completion". Otherwise, perform the following services: Displayed item Possible cause Service procedure SUSPENSION - Temporary malfunction in internal processing of the rear view camera. Go back to Step 1 00H Routine not activated Rear view camera unit malfunction. Position the target appropriately again. Perform the aiming again. Refer to " «WORK PROCEDURE (TARGET SETTING)»(ref-576067-S00166081642013090900000) ". 10H Writing error Temporary malfunction in internal processing of the rear view camera. Rear view camera malfunction. X AIMING NG Y (X: 0 - 7, Y: 1 - 8) - A target is not-yet-placed. (The rear view camera cannot detect a target.) The position of the rear view camera is not correct. Inappropriate work environment. Inappropriate vehicle condition. Position the target appropriately again. Perform the aiming again. Refer to " «WORK PROCEDURE (PREPARATION)»(ref-576067-S41248872712013090900000) ". ABNORMALLY COMPLETED - NOTE: Replace camera unit if "00H Routine not activated" or "10H Writing error" are repeatedly indicated during the above two services are performed. Confirm that "Completed" is displayed and then select "End" to close the calibration procedure. >> GO TO 3.
  3. PERFORM SELF-DIAGNOSIS Perform self-diagnosis of ITS control unit with CONSULT. Is any DTC detected? YES >> Perform diagnosis on the detected DTC and repair or replace the applicable item. Refer to " «DTC INDEX»(ref-576064-S14761827702013090900000) ". NO >> GO TO 4.
  4. ACTION TEST Test the system operation by action test. Refer to " «DESCRIPTION»(ref-576067-S02701137532013090900000) ". >> Work End.
