Driver Assistance System (Bsw) (Sedan): Removal & Installation Nissan Altima L33

Collision/avoidance 6 illustrations ~263 words

Installation

Installation is in the reverse order of removal.

Scheme 79

Scheme 79: REMOVAL

Scheme 80

Scheme 80
  1. Remove the instrument lower panel LH. Refer to " «REMOVAL AND INSTALLATION»(ref-576024-S27742912012013090900000) ".
  2. Remove screws (<--) that retain the upper switch carrier (1) to the instrument lower panel LH (2).
  3. Release upper tab (B) and lower tab (C) using a suitable tool (A), then remove the warning system switch (4) from the upper switch carrier. Trunk opener switch VDC switch Heated steering wheel switch

Installation is in the reverse order of removal.

Scheme 81

Scheme 81: Exploded View

Note. LH side shown; RH side similar.

Removal

  1. Remove the front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-576034-S29413013892013090900000) ".
  2. Remove the door mirror corner finisher using a suitable tool.
  3. Remove the blind spot warning indicator screws.
  4. Remove the blind spot warning indicator.

Installation is in the reverse order of removal.

Scheme 82

Scheme 82: REMOVAL
  1. Remove trunk lid finisher. Refer to " «EXPLODED VIEW»(ref-576023-S03466703882013090900000) ".
  2. Disconnect the harness connector (A) from rear view camera.
  3. Push the rear view camera (1) in direction shown below (<--) and pull out to remove.

Installation is in the reverse order of removal.

Scheme 83

Scheme 83: Exploded View

Scheme 84

Scheme 84: Removal
  1. Remove the trunk lid finisher. Refer to " «TRUNK LID FINISHER: REMOVAL AND INSTALLATION»(ref-576023-S21984453652013090900000) ".
  2. Disconnect the air tube from the rear view camera air pump motor.
  3. Disconnect the harness connector from the rear view camera air pump motor.
  4. Remove the rear view camera air pump motor bracket nuts (A).
  5. Remove the rear view camera air pump motor assembly (1).

Installation is in the reverse order of removal.
