Checking Wheel Bearing Rotation Starting Torque

  1. Install Front Hub Remover and Installer (MB991017 or MB990998) and Spacer (MB991000) as shown in illustration and tighten to 145-188 ft. lbs. (207-245 N.m). (Scheme 29)
  2. Hold front wheel hub assembly in a vice by using a wooden block. (Scheme 30)
  3. Rotate the hub in order to seat the bearing.
  4. Measure the wheel bearing rotation starting torque by using Preload Socket (MB990326) and Torque Wrench (MB990685).
  5. If the rotation starting torque is more than 9.12 INCH lbs. (1.03 N.m), replace the front wheel bearing assembly. If there is any signs of binding or tight spots when the wheel bearing turns, replace it.

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Checking Lower Ball Joint Breakaway Torque

  1. Shake the ball joint stud several times.
  2. Using Preload Socket (MB991006), check the breakaway torque of the ball joint. (Scheme 31)
  3. If the breakaway torque is more than 4.4-30.1 INCH lbs. (0.5-3.4 N.m), replace the lower arm assembly. If the breakaway torque is less than 4.4-30.1 INCH lbs. (0.5-3.4 N.m), check that the lower arm ball joint turns smoothly without excessive play. If there is no excessive play, the ball joint can be reused.

Scheme 31

Scheme 31

Checking Lower Arm Pillow Ball Bushing Rotation Starting Torque

  1. Insert the bolt to the lower arm pillow ball bushing, in the opposite direction, insert the washer and then install the nut.
  2. Rotate the inner sleeve (contained washer) several times and measure the rotation starting torque of the lower arm pillow ball bushing using Preload Socket (MB990326). (Scheme 32)
  3. If the rotation starting torque is more than 4.4-26.6 INCH lbs. (0.5-3.0 N.m), replace the pillow ball bushing. If the rotation starting torque is less than 4.4-26.6 INCH lbs. (0.5-3.0 N.m), check that the lower arm pillow ball bushing turns smoothly without excessive play. If there is no excessive play, the pillow ball bushing can be reused.

Scheme 32

Scheme 32
  1. Shake the ball joint stud several times.
  2. Install the nut to the stud and use Preload Socket (MB990326) to measure the turning torque of the ball joint. (Scheme 33)
  3. If the stabilizer link ball joint turning torque is more than 15-28 INCH lbs. (1.7-3.2 (N.m), replace the stabilizer link. If the stabilizer link ball joint turning torque is less than 15-28 INCH lbs. (1.7-3.2 (N.m), check that the ball joint turns smoothly and without excessive play. If so, it is possible to re-use that ball joint.

Scheme 33

Scheme 33

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Axle Shaft Nut145-188 (197-255)
Caliper Assembly Bolt72-87 (98-118)
Crossmember Bar Bolt29-44 (39-59)
Crossmember Bolt29-44 (39-59)
Crossmember-To-Body Bolt & Nut116-130 (158-176)
Front Wheel Hub Bolt58-72 (78-98)
Lower Arm-To-Crossmember Bolt
Front130-145 (176-196)
Rear117-130 (158-176)
Lower-To-Knuckle Nut72-87 (98-118)
Rear Roll Stopper Nut33-44 (45-59)
Stabilizer Bar Bracket Bolt25-32 (34-44)
Stabilizer Bracket Bolt13-18 (17-25)
Steering Gear & Joint Bolt72-87 (98-118)
Strut Assembly-To-Body Nut29-36 (39-49)
Strut Assembly-To-Knuckle Nut117-130 (158-176)
Strut Self-Locking Nut37-52 (50-70)
Tie Rod End-To-Knuckle Nut15-22 (20-30)
INCH Lbs. (N.m)
Dust Cover Bolt62-96 (7.0-10.8)
