Lower Arm Ball Joint Breakaway Torque
After shaking the ball joint stud several times, Use Preload Socket (MB991006) to measure the breakaway torque of the ball joint. (Scheme 1) If the breakaway torque of the ball joint is not within 0-35 INCH lbs. (0.0-3.9 N.m), if the ball joint is difficult to turn, or if does not turn smoothly, replace the lower arm assembly.
Scheme 1
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Axle Shaft Nut | 160-202 (216-274) | |
| Caliper Assembly Bolt | 67-81 (90-110) | |
| Crossmember Bolt | 30-44 (39-59) | |
| Crossmember Nut | 116-130 (158-176) | |
| Lower Arm-To-Crossmember Bolts | ||
| Front | 130-144 (176-196) | |
| Rear | 116-130 (158-176) | |
| Lower Arm-To-Knuckle Nut | 73-87 (98-118) | |
| Stabilizer Bar-To-Crossmember Bolt | 116-130 (158-176) | |
| Stabilizer Bar-To-Rear Roll Stopper Nut | 34-44 (45-59) | |
| Stabilizer Fixture Bolt | 13-19 (17-25) | |
| Steering Gear & Joint Connecting Nut | 11-15 (16-20) | |
| Strut Assembly Self-Locking Nut | 38-52 (50-70) | |
| Strut Assembly-To-Body Nut | 30-36 (39-49) | |
| Strut Assembly-To-Knuckle Nut | 116-130 (158-176) | |
| Tie Rod End-To-Knuckle Nut | 16-22 (20-30) | |
| INCH Lbs. (N.m) | ||
| Front Anti-Lock Brake System (ABS) Speed Sensor Bolt | 90-124 (10-14) | |
