Front Axle - Evolution: Removal & Installation Mitsubishi Lancer IX

Suspension Front 11 illustrations ~387 words

HUB BOLT REPLACEMENT

Required Special Tools

  1. MB990767: End Yoke Holder
  2. MB991618: Hub Bolt Remover
CAUTIONDuring maintenance, take care not to contact the parts or tools to the caliper because the paint of caliper will be scratched.

Scheme 65

Scheme 65
Scheme 65

Scheme 66

Scheme 66
Scheme 66
  1. Remove the caliper assembly and suspend it with wire so that it does not fall.
  2. Remove the brake disc.
  3. Use special tools MB990767 and MB991618 to remove the hub bolts.
  4. Install the plain washer to the new hub bolt, and install the bolt with a nut.
  5. Install the brake disc, caliper assembly and tighten the caliper assembly mounting bolts to the specified torque 108 +/- 10 N.m (80 +/- 7 ft-lb).

Scheme 67

Scheme 67: REMOVAL AND INSTALLATION
Scheme 67: REMOVAL AND INSTALLATION

Required Special Tools

  1. MB990767: End Yoke Holder
  2. MB990241: Axle Shaft Puller
  3. MB991354: Puller Body
  4. MB990211: Slide Hammer
  5. MB991897: Ball Joint Remover

<< A >> DRIVE SHAFT NUT REMOVAL

CAUTIONDo not apply pressure to wheel bearing by the vehicle weight to avoid possible damage when drive shaft nut is loosened.

Use special tool MB990767 to fix the hub and remove the drive shaft nut.

Scheme 68

Scheme 68
Scheme 68

<< B >> CALIPER ASSEMBLY REMOVAL

CAUTIONDuring maintenance, take care not to contact the parts or tools to the caliper because the paint of caliper will be scratched.

Secure the removed caliper assembly with wire, etc.

<< C >> SELF LOCKING NUT (CONNECTION FOR AND TIE ROD END) REMOVAL

CAUTIONDo not remove the nut from ball joint. Loosen it and use special tool MB991897 to avoid possible damage to ball joint threads. Hang special tool MB991897 with cord to prevent it from falling.

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
  1. Install special tool MB991897 as shown in the figure.
  2. Turn the bolt and knob as necessary to make the jaws of special tool MB991897 parallel, tighten the bolt by hand and confirm that the jaws are still parallel. NOTE: When adjusting the jaws in parallel, make sure the knob is in the position shown in the figure.
  3. Tighten the bolt with a wrench to disconnect the tie rod end and remove the self locking nut.

Scheme 71

Scheme 71: << D >> DRIVE SHAFT REMOVAL
Scheme 71: << D >> DRIVE SHAFT REMOVAL

Scheme 72

Scheme 72
Scheme 72
  1. Use special tools MB990241 (MB990242 and MB990244), MB991354 and MB990767 to push out the drive shaft from the hub and knuckle.
  2. Withdraw the drive shaft from the hub by pulling the bottom of the hub and knuckle towards you.
  3. Hang the drive shaft on the vehicle body with a rope.

<< A >> WASHER/DRIVE SHAFT NUT INSTALLATION

CAUTIONBefore securely tightening the drive shaft nuts, make sure there is no load on the wheel bearings. Otherwise the wheel bearings will be damaged.

Scheme 73

Scheme 73
Scheme 73
  1. Be sure to install the drive shaft washer in the specified direction.
  2. Using special tool MB990767, tighten the drive shaft nut to the specified torque 226 +/- 19 N.m (167 +/- 21 ft-lb).

Scheme 74

Scheme 74: DISASSEMBLY AND REASSEMBLY
Scheme 74: DISASSEMBLY AND REASSEMBLY

Scheme 75

Scheme 75: << F >> FRONT WHEEL HUB ASSEMBLY REMOVAL
Scheme 75: << F >> FRONT WHEEL HUB ASSEMBLY REMOVAL
  1. If the front wheel hub is seized, remove the knuckle together with front wheel hub and fix them with a vise.
  2. Use special tools MB990244 (MB990241), MB991354 and MB990211 to pull out the front wheel hub from the knuckle.
