Vehicle Bus Systems
In order to make the components used in our vehicles more efficient we utilize bus structures (commonly referred to as I-Bus, K-Bus, D-Bus, DS2-Bus Byteflight, PT-CAN, etc.). By using bus structures in vehicles, we can accelerate communication between several different control modules.
Many common vehicle systems (such as entertainment, safety, powertrain, etc.) are "stand alone" systems but also require information from other modules/systems in order to be more efficient. In order to obtain the required information the systems must also be able to simultaneously communicate without interfering with each other, which is accomplished by using various bus structures.
Example
The PDC receives information on vehicle speed from the ABS/ASC/DSC control unit.
To receive this signal, it is transmitted from
- ABS/ASC/DSC control unit to the IKE via the CAN-Bus
- IKE control unit to the PDC control unit via the K-Bus splice (inside the BC1) control unit.
The workshop network operates in a similar fashion.
Scheme 181
Workshop Local Area Network (LAN)
A network is nothing more than a group of devices interconnected so that they can communicate with each other. A LAN is a network that is localized to a specific area, such as a workshop or office.
The bus systems (I-Bus, K-Bus, PT-CAN, D-Bus,...) that we have been using in our vehicles for quite sometime, are nothing more than networks with different configurations.
Scheme 182
All workshops are currently equipped with a GT1, DISplus, SSS, Diagnostic Head, Access Point, desktop computer(s) and printer(s) which can be considered as satellite components (control modules/sensors).
In order for these components to communicate with each other, either directly or indirectly, they must be interconnected via a cable/wire to a common point or switching device. Consider the switching device/hub to be similar to the IKE, which monitors all devices connected to it and allows the devices to communicate with each other. The interconnection of these devices results in the establishment of a network localized to the workshop area thereby establishing a Local Area Network (LAN) in the workshop.
Network Structure
By having the workshop configured to allow the various devices used on a daily basis to be interconnected/networked with each other, as indicated in the illustration, additional components can easily be added and online updates can automatically be installed on all connected devices, as long as they have an approved IP address.
The network that exist in the workshop is not much different than the network structure that is used in our vehicles. In order for control modules to communicate with each other they must be correctly identified.
The identification process can be considered to occur as part of the coding procedure which is done at the end of the assembly process or at anytime a new component/module/system is added to the vehicle. By not recoding the vehicle after adding or removing a module/system, the communication on a particular bus can be hampered.
This is especially true
- If a response form a module that is no longer installed is expected
- If a new module transmits data that is not expected by anyone else on the bus because it is not correctly identified
The VO for a vehicle can be considered to contain the IP addresses of the modules installed in the vehicle.
If the devices on the workshop network do not have a rigidly assigned IP address, online updates to specific devices can not occur. The operation/performance of a network can be greatly hampered if multiple devices share an address, since the transmitted data is not able to reach the correct device, it can result in jamming up the operation of the network.
Scheme 183
Network Connections
When establishing a network which will utilize multiple access terminals/jacks it is recommended that the jacks and cables attached to the specific jacks are numbered and that the corresponding end of the cable that connects to the router/switched hub should be numbered as well.
Example: The illustration below shows a basic network structure with no miscellaneous devices connected, other than a Server and Switched Hub.
The cables running to/from the Switched Hub are all numbered on both ends to make troubleshooting the network easier in the event of a problem with the cabling, wall jack or Switched Hub connections.
Not having the cable and wall jacks number would be like trying to troubleshoot a problem with an electrical circuit in the vehicle where all the wires are the same color and the components connected have no pin assignments.
Scheme 184
Once additional devices are connected it becomes very important that the configuration information (IP Address, Gateway Address, Subnet Mask and Device Name) is entered correctly for each device that is connected to the network. Each device must be assigned a specific/unique IP Address.
It is very important that the IP address not be shared by multiple devices located on the network, as this can result in "Locking-up" the network, which can have a detrimental effect on any control module(s) being programmed or coded.
Scheme 185
Accessing Configuration Information
DISplus/GT1
Select "Administration"
Scheme 186
Select "System"
Scheme 187
The screen now displays the network configuration information for the device being used DISplus/GT1.
Scheme 188
Select "Diagnostic Head"
Scheme 189
Select "Free diagnostic head"
Note. In order for an interface to be displayed it must be connected to a vehicle and the ignition turned on.
Scheme 190
Network configuration information for the selected interface is displayed.
Example: A red color band will be assigned to this interface once "OK" is selected
Scheme 191
Scheme 192
Scheme 193
Workshop Network Components
A LAN currently exists in all workshops to allow the diagnostic equipment (DISplus, GT1, SSS, OPPS, OPS & Diagnostic Head) to communicate with each other. In order to successfully diagnose, code and program a vehicle, it is required to have all equipment connected to the workshop network.
Access Point
Allows direct wireless access to LAN for GT1 and Diagnostic Head or Diagnostic head establishes connection to LAN via wireless communication and thereby can be connected to DISplus or GT1, which are connected to LAN
Access point is connected directly to LAN. Symbol -Model Spectrum 24/AP 3020-100
Scheme 194
Wall Jack
Connection point for devices such as GT1, DISplus, Access Point, SSS, Diagnostic Head, OPPS/OPS Head, Printer and Network Server to Switched Router via RJ45 cable.
Scheme 195
CAT 5 Ethernet Cable
Used to establish a connection between
- Wall jack and Switched Router/Hub
- Wall jack and devices such as GT1, DISplus, Access Point, SSS, Diagnostic Head, OPPS/OPS Head and Network Server.
Scheme 196
Switched Hub
LAN switched distribution hub for all devices connected to the network. Routes communication telegrams / messages to specific devices from specific devices. Allows multiple devices to communicate with each other without reducing data transfer rate.
Cisco Switch WS-C2950-24
Scheme 197
Server
Central computer which controls interface/communication between all devices on the Workshop LAN and communication to external networks and Internet. Keystone device for network operation along with switch/router.
Scheme 198
A group of computers that are interconnected with each other and able to communicate with each other either by transferring data via a wired or wireless connection.
Local Area Network (LAN)
A network that exists within a specific area.
Example: By having all computers, testers and printers in the workshop interconnected results in a Workshop LAN.
Ethernet
The term Ethernet is a communications protocol used to define a method & speed by which interconnected devices are able to communicate with each other by either a wired (twisted pair) or fiberoptic connection.
Common Ethernet communication protocol terms
10BaseT - Able to transmit data at a rate of 10Mbps for a maximum distance of 100 meters per segment.
100BaseT - Able to transmit data at a rate of 100Mbps for a maximum distance of 1000 meters per segment.
The speed differences are obtained by modifying the method of encoding the data to be transferred. The maximum distance consist of the distance from switched hub to wall jack plus length of cable used to connect a particular device. The greater the distance the greater the chance of signal loss/disturbance.
Ethernet Cable (CAT 5)
A standard used to define an 8 wire cable (4 twisted pair) that is commonly used to interconnect various computers in the establishment of an ethernet network. Certified to transmit data at a maximum rate of 100Mbps.
RJ-45 Connectors
The plastic connectors at the end of a CAT 5 cable, used to connect the cable to device/computer, wall jack and hub.
Accepts RJ-45 connectors when connecting devices to the network. Connection point for devices like DISplus, GT1, SSS, Diagnostic Head, workshop computers and printer.
Recommendation is that outlet/jack is numbered and the corresponding end of the ether-net cable connected to the switched hub is numbered as well, to assist in troubleshooting in the event of a problem.
Example: A wall jack outlet is labeled as #1 the other end of the cable at the hub should also be labeled #1.
Allows multiple devices to send information over the network at the same time without slowing down the communication process. A switched hub essentially isolates the two devices that are communicating, thereby providing each component on the network a separate connection at the maximum data transfer rate of the network.
Example: A switched HUB is similar to the use of cloverleafs on the highway, traffic does not need to stop if a change in direction needs to be made, plus traffic flows smoothly from point to point.
A regular HUB does not provide each component with a separate connection point to the network but rather a shared connection point. By sharing a connection point the data transfer rate of the network is reduced when multiple devices try to communicate.
Example: A regular HUB is similar to the use of a 4 way intersection, the smaller the amount of traffic using the intersection the quicker a car can go through the intersection and reach its desired destination. The greater the traffic the longer it will take for a car to reach its desired destination.
The switched hub installed as part of the workshop wiring project is a Cisco WS-C2950-24.
Network Server
A computer that provides information/data to other computers located on the network. A server allows computers on its network to access information on another network, such as the internet. The server is the keystone device that allows computers on its specific network to access information on another network.
As an example a server can obtain and distribute software updates to all computers located on its network, instead of having to physically install the updates to each computer individually.
Automatic/Online Updates
The ability to connect the network server to the BMW server and check for new software updates (Diagnostic, Coding & Programming data) then downloads the information to all computers/equipment located on the network automatically at a specific time.
Example: New updates can be installed on SSS, GT1 and DISplus overnight in order to have latest data available the next morning.
The application that performs online updates is referred to as JET stream.
The access point is a wireless communication device that is able to establish a wireless connection with a GT1 and/or a diagnostic head and allows them to communicate with other devices on the network.
Manufactured by Symbol - Model Spectrum 24 /AP 3020-100
Scheme 199
Interface Name
The specific name assigned to the device (Ex. Diagnostic Head Blue A)
IP Address
It is a unique four segment number used to identify a specific device located on a specific network. The number represents the address of the device on the network and is necessary when communicating with other devices located on the network.
Example: 92.168.100.10
Usually the first three segments are used to identify the network and the last segment identifies the device. The IP Subnet Mask information generally defines which segments are needed to identify the network and which identify the device.
In order for a devices on the network to communicate with other devices on the network it must know the addresses of those devices. If a print command is sent from a computer to a printer on the network, the command must be addressed specifically to the desired printer.
Example: An IP address is no different than your home address, in order to receive a letter specifically directed to you, your name and address must be correctly displayed on the letter.
IP addresses are assigned by the network administrator/provider and are rigidly assigned to the device(s) located within the workshop network, by entering it into the device during the initial setup.
IP Subnet Mask
This information is used to define which segment(s) of the four segment IP address specifically identifies the device and which identify the specific network.
Example: 255.255.255.0
Indicates that the first three segments (255.255.255) identify the specific network that the device is located on. The last segment (0) indicates that this is the segment that will identify the specific device.
Gateway
This information identifies the four segment address of the component located on the network responsible for communicating from the current network to another network. If there is no address in this location then a connection to any devices outside of the current network can not be established.
Note. The network and device address information must be entered exactly as defined by the network administrator for your facility, otherwise the devices can not be accessed.
