The 3.0L (4v) is a four-valve-per-cylinder, dual overhead camshaft engine. The engine uses a distributorless ignition system. The cylinder block is a two-piece design with the upper portion housing the cylinders, and a separate lower cylinder block containing the main bearing caps. Both sections are made of aluminum, with inserts for the bearing areas and caps. An aluminum oil pan bolts to the bottom of the lower cylinder block and to the transaxle to provide greater strength.
The camshafts are mounted in the cylinder heads and act against a roller follower to open and close the valves. A hydraulic lash adjuster is located on one side of the roller follower and the valve tip on the opposite end. The camshafts are driven off the front of each cylinder head by two chains (one each side). Both of the chains are driven by sprockets that are located on the crankshaft, just in front of the oil pump.
Scheme 155
Scheme 156
Scheme 157
Scheme 158
This vehicle is equipped with
- a V-ribbed serpentine accessory drive belt.
- an automatic drive belt tensioner.
- a V-ribbed coolant pump belt.
New drive belts must be of the same type as originally installed.
Check the drive belt condition at 160,000 km (100,000 miles) then after every 24,000 km (15,000 miles).
Scheme 159
Scheme 160
Scheme 161
- With the vehicle in NEUTRAL, position it on a hoist.
- Remove the splash shield.
- Rotate the accessory drive belt tensioner counterclockwise and remove the belt.
- To install, reverse the removal procedure.
Scheme 162
Scheme 163
- Remove the coolant pump belt shield bolts and remove the coolant pump belt shield.
- Cut and remove the water pump belt. Discard the belt.
