Automatic Transaxle - Overhaul [CD4E]: Removal & Installation Mazda Tribute I

Installation

Note. Apply a light coat of petroleum jelly to the O-ring before installation.

Scheme 436

Scheme 437

1. Install the OSS sensor. Connect the OSS sensor electrical connector.
2. Install the splash shield.
3. Install the LH front wheel.
4. Lower vehicle.
5. Check the transaxle fluid level, add fluid as necessary using MERCON(R) Multi-Purpose (ATF) Transaxle Fluid.
6. Start the engine and move the transaxle range selector lever through all gear positions.

Scheme 438

Scheme 439

Scheme 440

1. Raise and support the vehicle.
2. Remove the LH front wheel.
3. Remove the splash shield.
4. Place a drain pan beneath the turbine shaft speed (TSS) sensor.
5. Remove the TSS sensor. Disconnect the TSS sensor electrical connector. Remove the bolt. Inspect the TSS sensor bore.
6. Inspect the O-ring seal for nicks or cuts. Install a new seal as necessary.

Note. Apply a light coat of petroleum jelly to the O-ring seal before installation.

Scheme 441

Scheme 442

1. Install the TSS sensor. Connect the TSS electrical connector.
2. Remove the drain pan.
3. Install the splash shield.
4. Install the LH front wheel.
5. Lower the vehicle.
6. Check the transaxle fluid level, add fluid as necessary using MERCON(R) Automatic Transaxle Fluid (ATF).
7. Start the engine and move the transaxle range selector lever through all gear positions.

Removal

Note. Servicing the intermediate/overdrive servo in the vehicle is only recommended in the event of a leak. If servicing is required due to a servo condition, it is necessary to remove and disassemble the transaxle to inspect the intermediate/overdrive band assembly and direct clutch for damage.

Scheme 443

Scheme 444

Scheme 445

Scheme 446

Scheme 447

1. Raise and support the vehicle. WARNING: The servo is under pressure. Servo and servo cover are under high spring force. Use caution when removing the servo cover. Failure to follow these instructions may result in personal injury.
2. Assemble the special tool.
3. Remove the splash shield.
4. Remove the transaxle cooler line bracket bolt and position the bracket out of the way. CAUTION: Do not use a screwdriver to remove the retaining ring or damage to the case may occur. Use only snap ring pliers to remove the retaining ring.
5. Using the special tool, remove the servo retaining ring. Install the special tool. Compress the servo assembly by tightening the bolt. Remove the retaining ring.
6. Remove the special tool.
7. Remove the servo cover assembly.
8. Remove the intermediate and overdrive servo piston and return spring.
9. Wipe the servo piston and the servo cover cap with a lint free cloth. CAUTION: Do not clean the rubber sealing surfaces of the servo piston and the servo cover cap with cleaning solvent or damage to the sealing surface may result.
10. Inspect the servo piston for cracks on its pressure surfaces and in the sealing area. Look for damage near the point where the servo piston is attached to the servo rod.
11. Squeeze the servo piston lip for flexibility. If the lip feels brittle, install a new piston
12. Inspect the servo retainer spring for cracks, breaks or deformation.

Scheme 448

Scheme 449

Scheme 450

Scheme 451

Scheme 452

Scheme 453

1. Assemble the special tool.
2. Install the special tool. CAUTION: Do not use a screwdriver to install the retaining ring or damage to the case may occur. Use only snap ring pliers to install the retaining ring. NOTE: If the servo cover will not seat deep enough in the bore to install the servo cover retaining ring, use a blunt punch or small hammer and gently tap the cover around the outer edge until the servo cover retaining ring can be installed.
3. Tighten the special tool bolt. Install the servo cover retaining ring.
4. If the case is stamped "WG", install a wide-grooved snap ring, or the servo will be damaged.
5. Loosen the special tool bolt. When the spring tension is released, remove the special tool.
6. Install the transaxle fluid cooler line.
7. Install the splash shield.
8. Lower the vehicle.
9. Start the vehicle. Place the transaxle range selector lever in each gear and allow to engage. Check for leaks.
10. Check transaxle fluid.

Scheme 454

Scheme 455

Scheme 456

Scheme 457

Scheme 458

Scheme 459

1. Raise and support the vehicle.
2. Remove the splash shield.
3. Remove the cross brace.
4. Remove the lower vibration dampener.
5. Remove the cross brace.
6. Remove the top and bottom mount cups.
7. Remove the rubber mount.

Scheme 460

Scheme 461

Scheme 462

Scheme 463

Scheme 464

Scheme 465

1. Install a new rubber mount.
2. Install the top and bottom mount cups.
3. Install the cross brace.
4. Install the lower vibration dampener.
5. Install the cross brace.
6. Install the splash shield.
7. Lower the vehicle.

Scheme 466

Scheme 467

Scheme 468

Scheme 469

Scheme 470

Scheme 471

Scheme 472

Scheme 473

1. Disconnect the breather tube and mass air flow (MAF) sensor.
2. Remove the intake tube and air cleaner cover.
3. Remove the air cleaner assembly.
4. Install the special tools.
5. Install the special tools.
6. Remove the upper transaxle mount bolt.
7. Remove the upper transaxle insulator.
8. Remove the top and bottom mount cups.

Scheme 474

Scheme 475

Scheme 476

Scheme 477

Scheme 478

Scheme 479

Scheme 480

Scheme 481

1. Install the top and bottom mount cups.
2. Install the upper transaxle insulator.
3. Install the upper transaxle bolt.
4. Remove the special tool.
5. Remove the special tool.
6. Install the air cleaner assembly.
7. Install the intake tube and air cleaner cover.
8. Connect the breather tube and mass air flow (MAF) sensor.

Scheme 482

Scheme 483

Scheme 484

Scheme 485

Scheme 486

1. Remove the battery tray.
2. Disconnect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor.
3. Remove the intake tube and air cleaner cover.
4. Remove the air cleaner assembly.
5. Remove the bolts from the rack.
6. Remove the bolts and nuts from the mount, and remove the mount.

Note. Prior to tightening the mount nuts install the mount bolt for correct alignment.

Scheme 487

Scheme 488

Scheme 489

Scheme 490

Scheme 491

1. Install a new mount and bolts. Install the mount. Loosely install the bolt for correct alignment. Install the nuts and bolt.
2. Install the bolts to the rack.
3. Install the air cleaner assembly.
4. Install the intake tube and air cleaner cover.
5. Connect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor. NOTE: Before installing the battery tray check the vent tube hose for any obstructions, kinks, or incorrect routing position.
6. Install the battery tray.

Scheme 492

Scheme 493

Scheme 494

Scheme 495

1. Disconnect the breather tube and mass air flow (MAF) sensor.
2. Remove the intake tube and air cleaner cover.
3. Remove the air cleaner assembly.
4. Remove the bolts and nuts from the mount, and remove the mount.

Note. Prior to installing the mount nuts, install the mount bolt for correct alignment

Scheme 496

Scheme 497

Scheme 498

Scheme 499

1. Install a new mount and bolts. Install the mount. Loosely install the bolt Tighten the nuts first, then the bolts.
2. Install the air cleaner assembly.
3. Install the intake tube and air cleaner cover.
4. Connect the breather tube and MAF sensor.

Scheme 500

Scheme 501

1. Raise and support the vehicle. NOTE: Place a suitable drain pan under the vehicle.
2. Remove the transaxle drain plug and drain the fluid.
3. Remove the LH halfshaft. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) .
4. Using the special tools, remove and discard the LH differential seal.

Scheme 502

Scheme 503

1. Using the special tool, install the LH differential seal.
2. Install the LH halfshaft. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) .
3. Remove the drain pan and lower the vehicle.
4. Install the transaxle drain plug. After the fluid has been drained, clean the drain plug threads and apply a small amount of Pipe Sealant with Teflon(R)
5. Add MERCON(R) Automatic Transaxle Fluid (ATF).
6. Start the engine and move the transaxle range selector lever through all gear positions. Refill as necessary.
7. Allow the transaxle fluid to reach operating temperature and fill as necessary.

Scheme 504

Scheme 505

Scheme 506

Scheme 507

Scheme 508

1. Place the vehicle in neutral.
2. Disconnect the battery cables.
3. Remove the battery and tray.
4. Disconnect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor.
5. Remove the intake tube and air cleaner cover.
6. Remove the air cleaner assembly. NOTE: It may be necessary to remove the thermostat housing to gain access to the transaxle range (TR) sensor.
7. Remove the thermostat housing.
8. Remove the transaxle range (TR) sensor. Disconnect the TR sensor electrical connector. Remove the bolts. Remove the TR sensor.

Note. Make sure the transaxle is in the NEUTRAL position.

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

1. Install the transaxle range (TR) sensor and loosely install the bolts.
2. Using the special tool, align the TR sensor and tighten the bolts. Connect the electrical connector.
3. Install the thermostat housing.
4. Install the air cleaner assembly.
5. Install the intake tube and air cleaner cover.
6. Connect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor. NOTE: Before installing the battery tray check the vent tube hose for any obstructions, kinks, or incorrect routing position.
7. Install the battery and tray.
8. Connect the battery cables.
9. Check the correct operation with parking brake control engaged. The engine should start only in PARK or NEUTRAL. Backup lamps should be active only in the REVERSE position.

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

Scheme 521

Scheme 522

Scheme 523

Scheme 524

Scheme 525

Scheme 526

Scheme 527

Scheme 528

Scheme 529

Scheme 530

Scheme 531

Scheme 532

Scheme 533

Scheme 534

Scheme 535

Scheme 536

Scheme 537

Scheme 538

Scheme 539

Scheme 540

Scheme 541

Scheme 542

Scheme 543

Scheme 544

Scheme 545

Scheme 546

Scheme 547

Scheme 548

Scheme 549

Scheme 550

Scheme 551

Scheme 552

Scheme 553

Scheme 554

Scheme 555

Scheme 556

Scheme 557

Scheme 558

Scheme 559

Scheme 560

Scheme 561

Scheme 562

1. Disconnect the battery cables.
2. Remove the battery and the battery tray.
3. Disconnect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor.
4. Remove the intake tube and air cleaner cover.
5. Remove the air cleaner assembly.
6. Disconnect the transaxle range (TR) sensor.
7. Disconnect the HO2S.
8. Disconnect the transaxle harness connector and remove the wire harness bracket nut.
9. Position the wire harness bracket out of the way.
10. Disconnect the vent hose from the transaxle filler tube bracket.
11. Unclip the wire harness.
12. Disconnect the shift cable.
13. Disconnect the wire harness from the shift cable bracket to gain access to the bracket bolts.
14. Remove the shift cable and bracket, and position out of the way.
15. Disconnect the starter motor harness connector.
16. Disconnect the ground wire.
17. Remove two starter bolts, and remove the starter motor.
18. Install the special tools.
19. Remove both electrical connectors from the valve cover to gain access to the engine lifting bracket.
20. Install the special tools.
21. Install the special tools.
22. Remove the upper transaxle retaining bolts.
23. Remove the LH upper transaxle mount plate.
24. Remove the bolts, and remove the rear transaxle mount.
25. Remove the RH engine mount bolt. NOTE: It is necessary to raise the engine a couple of inches in order to remove the transaxle.
26. Using the special tool raise the engine.
27. Raise and support the vehicle.
28. Remove both front wheels.
29. Remove the two splash shields.
30. Disconnect the two HO2S sensors.
31. If transaxle disassembly is necessary, remove the drain plug and drain the fluid into a suitable container. Install the drain plug when the fluid has drained. CAUTION: Index-mark the mounting bracket studs and the intermediate shaft bearing bracket holes for correct assembly.
32. Remove the RH halfshaft, intermediate shaft bearing, and intermediate shaft assembly. Refer to «INTERMEDIATE SHAFT»(ref-165629-S28240738952004090800000) .
33. Remove the LH halfshaft assembly. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) .
34. Remove the cross brace.
35. Disconnect the HO2S connector and unclip the two clips from the oil pan bolt studs.
36. Remove the exhaust pipe. Install the special tool. Remove the rubber hanger. Remove the bolts, and remove the pipe.
37. Disconnect the front exhaust pipe flange.
38. Disconnect the rear exhaust pipe flange and remove the exhaust pipe.
39. If equipped, remove the driveshaft.
40. For four-wheel-drive vehicles, remove the RH exhaust manifold to gain access to the PTO bracket.
41. Remove the bolts and the bracket.
42. Remove the cross brace dampener.
43. Remove the cross brace.
44. Remove the bolts from the PTO unit.
45. Remove the PTO bolt and the PTO unit.
46. Lower the vehicle. NOTE: It is necessary to lower the transaxle in order to clear the subframe to remove the transaxle.
47. Lower the transaxle enough to clear the subframe.
48. Raise the vehicle.
49. Remove the access cover.
50. Remove the four flexplate nuts.
51. Remove the fluid cooler tube. Disconnect the output shaft speed (OSS) sensor. Disconnect the turbine shaft speed (TSS) sensor. Remove the bolt. Remove the fluid cooler tube and position it aside.
52. Remove the OSS sensor.
53. Remove the fluid cooler line.
54. Install the transaxle jack and secure the transaxle to the jack.
55. Remove the bolts.
56. Remove the vent tube.
57. Remove the bolt.
58. Remove the bolt. CAUTION: The torque converter is heavy. Install the special tool before lowering the transaxle.
59. Move the transaxle back far enough to install the special tool.
60. Lower the transaxle from the engine compartment.

TRANSAXLE - INSTALLATION

Note. If the torque converter was not installed during assembly it must be installed now.

Scheme 563

Scheme 564

Scheme 565

Scheme 566

Scheme 567

Scheme 568

Scheme 569

Scheme 570

Scheme 571

Scheme 572

Scheme 573

Scheme 574

Scheme 575

Scheme 576

Scheme 577

Scheme 578

Scheme 579

Scheme 580

Scheme 581

Scheme 582

Scheme 583

Scheme 584

Scheme 585

Scheme 586

Scheme 587

Scheme 588

Scheme 589

Scheme 590

Scheme 591

Scheme 592

Scheme 593

Scheme 594

Scheme 595

Scheme 596

Scheme 597

Scheme 598

Scheme 599

Scheme 600

Scheme 601

Scheme 602

Scheme 603

Scheme 604

Scheme 605

Scheme 606

Scheme 607

Scheme 608

Scheme 609

Scheme 610

Scheme 611

1. Using the special tool, install the torque converter. NOTE: The torque converter hub must be fully seated into the transaxle pump drive gear.
2. Check the installation depth of the torque converter. Lay a straightedge on the transaxle converter housing. Check the clearance between the straight edge and the pilot hub.
3. Lubricate the torque converter pilot hub with Multi Purpose Grease.
4. Install the special tool.
5. Position the transaxle in place.
6. Remove the special tool.
7. Move the transaxle assembly toward the engine assembly and install the bolt.
8. Install the bolts.
9. Remove the transaxle jack.
10. Install the fluid cooler line.
11. Install the OSS sensor.
12. Install the fluid cooler tube. Install the fluid cooler tube. Install the bolt. Connect the output shaft speed (OSS) sensor. Connect the turbine shaft speed (TSS) sensor (white connector).
13. Install four flexplate nuts.
14. Install the access cover.
15. Connect the main control cover tube.
16. Lower the vehicle.
17. Using the special tool, raise the transaxle enough to install the cross brace.
18. Raise the vehicle.
19. Install the PTO unit and bolt.
20. Install the PTO bolts.
21. Install the cross brace.
22. Install the crossmember dampener.
23. Install the PTO bracket.
24. For four-wheel-drive vehicles, install the RH exhaust manifold. .
25. If equipped, install the driveshaft.
26. Install the exhaust pipe, and connect the exhaust pipe flange.
27. Connect the front flange.
28. Install the exhaust pipe. Install the pipe, and install the bolts. Install the rubber hanger. Remove the special tool.
29. Connect the HO2S sensor wire to the oil pan bolt studs and connect the connector.
30. Install the cross brace.
31. Install the LH halfshaft assembly. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) . CAUTION: Align the mounting bracket studs and the intermediate shaft bearing bracket holes with the marks made during removal.
32. Install the RH halfshaft, intermediate shaft bearing, and intermediate shaft assembly. Refer to «INTERMEDIATE SHAFT»(ref-165629-S28240738952004090800000) .
33. Install the two splash shields.
34. Install both front wheels.
35. Lower the vehicle.
36. Lower the engine onto the RH engine mount.
37. Install the bolt for the RH engine mount.
38. Install the rear transaxle mount.
39. Install the transaxle mount assembly.
40. Install the bolts.
41. Remove the special tool.
42. Remove the special tool.
43. Remove the special tool.
44. Connect the electrical connectors to the valve cover.
45. Install the starter motor, and install two bolts.
46. Install the ground cable.
47. Install the starter motor harness connector.
48. Install the shift cable and bracket.
49. Install the wire harness clip to the shift cable bracket.
50. Connect the shift cable.
51. Connect the wire harness.
52. Install the wire harness bracket, and connect the transaxle harness connector.
53. Connect the HO2S connector.
54. Connect the two HO2S sensors.
55. Connect the transaxle range (TR) sensor. NOTE: If not done during assembly, the digital TR sensor must be aligned.
56. Using the special tool, align the digital TR sensor.
57. Install the air cleaner assembly.
58. Install the intake tube and air cleaner cover.
59. Connect the breather tube and mass air flow (MAF) / intake air temperature (IAT) sensor. NOTE: Before installing the battery tray, check the vent tube hose for any obstructions, kinks or incorrect routing position.
60. Install the battery and tray.
61. Connect the battery cables.
62. Check the power take off (PTO) unit.
63. Fill the transaxle. Refer to «TRANSAXLE FLUID DRAIN AND REFILL»(ref-175492-S38267892912005042100000) .

Scheme 612

Scheme 613

Scheme 614

1. Raise and support the vehicle. NOTE: Determine the source of the fluid leak. If the leak is from the transaxle, continue with this procedure.
2. If it is determined that the fluid leak is coming from the power take off (PTO) unit, remove the PTO. NOTE: Place a suitable drain pan under the vehicle.
3. Remove the transaxle drain plug and drain the fluid.
4. Remove the RH halfshaft. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) .
5. If equipped remove the PTO.
6. If the vehicle is equipped with a PTO, use the special tools to remove the RH differential seal.
7. If the vehicle is not equipped with a PTO, use the special tools to remove the RH differential seal.

Scheme 615

Scheme 616

Scheme 617

1. If the vehicle is equipped with a PTO, use the special tools to install the RH differential seal.
2. If the vehicle is not equipped with a PTO, use the special tools to install the RH differential seal.
3. If equipped install the PTO.
4. Install the RH halfshaft. Refer to «HALFSHAFT (FRONT)»(ref-165629-S42040775062004083100000) .
5. Install the transaxle drain plug. After the fluid has been drained, clean the drain plug threads and apply a small amount of Pipe Sealant with Teflon(R).
6. Remove the drain pan and lower the vehicle.
7. Add MERCON(R) Automatic Transaxle Fluid (ATF).
8. Start the engine and move the transaxle range selector lever through all gear positions. Refill as necessary.
9. Allow the transaxle fluid to reach operating temperature and fill as necessary.

Scheme 618

1. Raise and support the vehicle.
2. Place a suitable container under the transaxle drain plug. NOTE: If an integral problem is suspected, drain the fluid through a paper filter. A small amount of metal or friction particles may be found from normal wear. However, if excessive metal and friction particles are present, internal service will be required.
3. Remove the transaxle drain plug and drain transaxle fluid.

Scheme 619

1. Install the transaxle drain plug. After the fluid has been drained, clean the drain plug threads and apply a small amount of Pipe Sealant with Teflon(R).
2. Lower the vehicle
3. Add 3.7 liters (3.9 quarts) of MERCON(R) Automatic Transaxle Fluid (ATF).
4. Start the engine and run through all gears for a total of five minutes at idle. Turn off the engine.
5. Repeat the previous steps to help flush fluid from the torque converter.
