AIRFLOW MODE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]

1. Disconnect the negative battery cable.
2. Remove the TCM. (AT) (See «TCM REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S22574760762010072700000) .)
3. Remove the A/C amplifier. (See «A/C AMPLIFIER REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S16757882682010072700000) .)
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.

Scheme 21

Scheme 22

Scheme 23

1. Connect battery positive voltage to airflow mode actuator terminal F (or G), and ground to terminal G (or F), and then verify that the airflow mode actuator operates as shown in «AIRFLOW MODE ACTUATOR OPERATION CHART»(ref-367648-S42666189462010072700000) . Apply the external power supply. If the operation condition is not normal, replace the airflow mode actuator. AIRFLOW MODE ACTUATOR OPERATION CHART Terminal Airflow mode actuator operation F G B+ Ground DEFROSTER-->VENT Ground B+ VENT-->DEFROSTER
2. Verify that the resistance between terminals A and E, and C and E matches the airflow mode actuator operation as shown in the graph. If the operation condition and resistance are not normal, replace the airflow mode actuator.
3. Install the air mix actuator with the lever the position shown in the figure.

Scheme 24

BLOWER MOTOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the figure.
3. Install in the reverse order of removal.

Scheme 25

Scheme 26

1. Connect battery positive voltage to blower motor terminal A, ground to terminal B, and then verify that the blower motor operates smoothly. If the operation condition is not normal, replace the blower motor.

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .)
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 28

1. Verify that the continuity between the power transistor terminals is as indicated in «RESISTANCE CHART»(ref-367648-S06416362132010072700000) . If there is any malfunction, replace the power transistor. If the blower motor operation is not normal even though no malfunction can be verified, inspect the A/C amplifier. (See «A/C AMPLIFIER INSPECTION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S08976149552010072700000) .) RESISTANCE CHART Tester lead Resistance (kilohm) + - A B infinity A C 11.0 A D infinity B A Continuity detected B C Continuity detected B D 1.5 C A 11.0 C B infinity C D infinity D A Continuity detected D B 1.5 D C Continuity detected

Scheme 29

1. Measure the clearance around the entire circumference between the pressure plate and A/C compressor pulley using a feeler gauge.
2. Inspect the clearance. If not within the specification, adjust the clearance by changing the shim (0.2 mm {0.008 in}, 0.5 mm {0.02 in}) or the number of shims. Magnetic clutch clearance 0.20-0.45 mm {0.008-0.017 in}

Scheme 30

Scheme 31

1. Connect battery positive voltage to magnetic clutch terminal B and ground to terminal A.
2. Verify that the magnetic clutch turns on. If the magnetic clutch does not turn on, replace the A/C compressor.

Scheme 32

1. Disconnect the negative battery cable.
2. Pry the solar radiation sensor from the dashboard using a flathead screwdriver wrapped with protective tape.
3. Remove in the order indicated in the figure. CAUTION: After the solar radiation sensor removal, the sensor connector could fall in the dashboard making the installation difficult. Therefore, hold the rooted end of the sensor connector using a clip or similar tool to prevent it from falling.
4. Install in the reverse order of removal.

Scheme 33

1. Shine a fluorescent light or expose the solar radiation sensor to natural sunlight.
2. Connect the positive (+) lead to terminal A and the negative (-) lead to terminal B of the solar radiation sensor, and verify that the voltage value is output. If the voltage is 0 V , replace the solar radiation sensor.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the under cover.
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 35

1. Measure the temperature around the ambient temperature sensor, then measure the resistance between the terminals of the ambient temperature sensor. If the characteristics of the ambient temperature sensor are not (Scheme 35), replace the ambient temperature sensor.

Scheme 36

1. Disconnect the negative battery cable.
2. Remove the driver's side lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .)
3. Remove the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 37

Scheme 38

1. Measure the temperature around the passenger compartment temperature sensor and measure the resistance between passenger compartment temperature sensor terminal. If the characteristics of the passenger compartment temperature sensor are not (Scheme 37), replace the passenger compartment temperature sensor.
2. Connect battery positive voltage to passenger compartment temperature sensor terminal A, ground to terminal C, and then verify that the fan operation. If there is any malfunction, replace the passenger compartment temperature sensor.

EVAPORATOR TEMPERATURE SENSOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]

1. Remove the evaporator temperature sensor from the A/C unit. (See «A/C UNIT DISASSEMBLY/ASSEMBLY»(ref-367660-S33647174192010072700000) .)

REFRIGERANT PRESSURE SWITCH REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]

1. Disconnect the negative battery cable.
2. Discharge the refrigerant from the system. (See «REFRIGERANT CHARGING»(ref-367641-S12059913632010072700000) .)
3. Hold the piping block with pliers or a similar tool and loosen the refrigerant pressure switch using a wrench.
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.

Scheme 39

Refrigerant Pressure Switch Installation Note

1. Apply compressor oil to the O-ring joints.

Scheme 40

Scheme 41

Scheme 42

1. Connect the manifold gauge.
2. Verify the high-pressure side reading.
3. Disconnect the refrigerant pressure switch connector.
4. Verify continuity between the terminals of the refrigerant pressure switch. If the continuity is not normal, replace the refrigerant pressure switch.

Scheme 43

1. Disconnect the negative battery cable.
2. Remove the lower panel. (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .)
3. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .)
4. Remove the center panel unit. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-367632-S21389676612010072700000) .)
5. Remove in the order indicated in the figure.
6. Install in the reverse order of removal.

Scheme 44

1. Turn the ignition switch to the ON position.
2. Connect the negative (-) lead of the tester to body ground.
3. By inserting the positive (+) lead of the tester into each climate control unit terminal, measure the voltage according to the «TERMINAL VOLTAGE CHART»(ref-367648-S39973627722010072700000) . If there is any malfunction, inspect the parts under "Inspection item(s)". If the parts under "Inspection item(s)" are found to be normal, replace the climate control unit. «TERMINAL VOLTAGE CHART»(ref-367648-S39973627722010072700000) TERMINAL VOLTAGE CHART Terminal Signal name Connected to Measurement condition Voltage (V) Inspection item(s) A B+ ROOM 15 A fuse Under any condition B+ ROOM 15 A fuse Related wiring harness B ACC Ignition switch Ignition switch ACC B+ Ignition switch Related wiring harness Ignition switch LOCK 1.0 or less C TNS TNS relay When light switch TNS B+ light switch Related wiring harness When light switch OFF 1.0 or less D Panel light control Panel light control switch Light switch ON and panel light control switch at max 1.0 or less Panel light control switch Related wiring harness Light switch ON and panel light control switch at min 11.5 E IG2 Ignition switch Ignition switch ON B+ Ignition switch Related wiring harness Ignition switch LOCK or ACC 1.0 or less F Vehicle speed Instrument cluster When vehicle driving 1.0 or less Instrument cluster Related wiring harness G Shield GND A/C amplifier Under any condition 1.0 or less A/C amplifier Related wiring harness H GND Body ground Under any condition 1.0 or less Related wiring harness I Serial signal 1 A/C amplifier Inspect the continuity in the wiring harness between climate control unit terminal I and A/C amplifier terminal 1R. Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. Continuity A/C amplifier Related wiring harness J MS-CAN_H CAN related module Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. Related wiring harness K Serial signal 2 A/C amplifier Inspect the continuity in the wiring harness between climate control unit terminal K and A/C amplifier terminal 1 P. Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. Continuity A/C amplifier Related wiring harness L MS-CAN_L CAN related module Because this terminal is for communication, good/no good judgment by terminal voltage is not possible. Related wiring harness

Scheme 45

1. Disconnect the negative battery cable.
2. Remove the TCM. (AT) (See «TCM REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S22574760762010072700000) .)
3. Remove in the order indicated in the figure.
4. Install in the reverse order of removal.

Scheme 46

Scheme 47

1. Turn the ignition switch to the ON position.
