Basic System (HVAC): Removal & Installation Mazda RX-8 I рестайлинг

BLOWER UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Ashtray Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-367662-S32092558042010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-367632-S21389676612010072700000) .) Steering shaft installation nuts (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) A/C amplifier (See «A/C AMPLIFIER REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S16757882682010072700000) .) (See «A/C AMPLIFIER REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-367647-S41243175932010072700000) .) TCM (AT) (See «TCM REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S22574760762010072700000) .) Auto light/wiper control module (See «AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION»(ref-367665-S22945446202010072700000) .) Door lock control module (See «DOOR LOCK CONTROL MODULE REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS SYSTEM»(ref-367649-S05742391692010072700000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-367662-S15841994732010072700000) .)
3. Remove the blower unit as shown in the figure.
4. Install in the reverse order of removal.

Scheme 51

Scheme 52

1. Disassemble in the order indicated in the table. CAUTION: If a non-specified grease is used, it may result in abnormal noise or improper operation of the links. Apply only the specified grease to each link.
2. Assemble in the reverse order of disassembly.

A/C UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Discharge the refrigerant from the system. (See «REFRIGERANT CHARGING»(ref-367641-S12059913632010072700000) .)
3. Drain the engine coolant. (See «ENGINE COOLANT REPLACEMENT [13B-MSP]»(ref-367619-S09402478192010072700000) .)
4. Remove the following parts: Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Ashtray Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-367662-S32092558042010072700000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-367662-S38463010542010072700000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-367662-S39346719792010072700000) .) Center panel unit (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-367632-S21389676612010072700000) .) Steering shaft installation nuts (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION»(ref-367652-S39447008962010072700000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-367662-S39687945372010072700000) .) A/C amplifier (See «A/C AMPLIFIER REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S16757882682010072700000) .) (See «A/C AMPLIFIER REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-367647-S41243175932010072700000) .) TCM (AT) (See «TCM REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S22574760762010072700000) .) Auto light/wiper control module (See «AUTO LIGHT/WIPER CONTROL MODULE REMOVAL/INSTALLATION»(ref-367665-S22945446202010072700000) .) Door lock control module (See «DOOR LOCK CONTROL MODULE REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS SYSTEM»(ref-367649-S05742391692010072700000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-367662-S15841994732010072700000) .) CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
5. Remove the A/C unit as shown in the figure.
6. Install in the reverse order of removal.
7. Inspect for engine coolant leakage. (See «ENGINE COOLANT LEAKAGE INSPECTION [13B-MSP]»(ref-367619-S36400923022010072700000) .)
8. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-367641-S04501745152010072700000) .)

Scheme 53

A/C Unit Installation Note

1. When installing a new A/C unit or evaporator, add compressor oil to the refrigerant cycle.

Supplemental amount (approx. quantity)

20 ml {20 cc, 0.7 fl oz.}

Scheme 54

1. Disassemble in the order indicated in the table. CAUTION: If a non-specified grease is used, it may result in abnormal noise or improper operation of the links. Apply only the specified grease to each link.
2. Assemble in the reverse order of disassembly.

When Evaporator Is Replaced

1. Assemble the evaporator temperature sensor as shown in the figure.

Scheme 55

When Evaporator Is Not Replaced

1. Install the evaporator temperature sensor by aligning it with the positions marked prior to removal.

Scheme 56

1. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .)
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

AIRFLOW MODE MAIN LINK REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the A/C amplifier. (See «A/C AMPLIFIER REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S16757882682010072700000) .) (See «A/C AMPLIFIER REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-367647-S41243175932010072700000) .)
3. Remove the airflow mode link set.
4. Remove the airflow mode main link as shown in the figure.
5. Install in the reverse order of removal.

Scheme 57

Scheme 58

1. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-367655-S22416401702010072700000) .) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-367655-S26865680542010072700000) .) Inner scuff plate (See «INNER SCUFF PLATE REMOVAL/INSTALLATION»(ref-367662-S01328246102010072700000) .) Ashtray illumination bulb (See «ASHTRAY ILLUMINATION BULB REMOVAL/INSTALLATION»(ref-367665-S29067692132010072700000) .) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-367662-S08997723562010072700000) .) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-367662-S03575028422010072700000) .) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-367662-S03253420052010072700000) .) Seat belt rail (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-367672-S25226145952010072700000) .) Floor covering (See «FLOOR COVERING REMOVAL/INSTALLATION»(ref-367662-S36387226182010072700000) .)
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 59

1. Disconnect the negative battery cable.
2. Discharge the refrigerant from the system. (See «REFRIGERANT CHARGING»(ref-367641-S12059913632010072700000) .)
3. Remove the fresh-air duct and air cleaner. (See «INTAKE-AIR SYSTEM REMOVAL/INSTALLATION [13B-MSP]»(ref-367618-S14848159782010072700000) .)
4. Remove the drive belt. (See «DRIVE BELT REPLACEMENT [13B-MSP]»(ref-367623-S36063400392010072700000) .)
5. Do not allow remaining compressor oil in the A/C compressor and pipes to spill, and remove in the order indicated in the table. CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
6. Install in the reverse order of removal.
7. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-367641-S04501745152010072700000) .)

A/C Compressor Installation Note

Scheme 60

1. Rotate new A/C compressor shaft six to eight revolutions while collecting refrigerant oil in a clean measuring device. Use this refrigerant oil to refill new compressor. Do not allow refrigerant oil to become contaminated.
2. Rotate old A/C compressor shaft six to eight revolutions while collecting refrigerant oil in a separate, clean measuring device.
3. Compare those oil amounts. The amount of the oil drained from the new A/C compressor should be greater than the old one.
4. Pour the same amount oil of drained from the old A/C compressor back into the new A/C compressor. A/C compressor oil type DENSO OIL8 A/C compressor oil sealed volume (approx. quantity) 60 ml {60 cc, 2.03 fl oz.}

Scheme 61

1. Disconnect the negative battery cable.
2. Discharge the refrigerant from the system. (See «REFRIGERANT CHARGING»(ref-367641-S12059913632010072700000) .)
3. Remove the under cover.
4. Do not allow remaining compressor oil in the condenser and pipes to spill, and remove in the order indicated in the table. CAUTION: If moisture or foreign material enters the refrigeration cycle, cooling ability will be lowered and abnormal noise or other malfunction could occur. Always plug open fittings immediately after removing any refrigeration cycle parts.
5. Install in the reverse order of removal.
6. Perform the refrigerant system performance test. (See «REFRIGERANT SYSTEM PERFORMANCE TEST»(ref-367641-S04501745152010072700000) .)

Condenser Installation Note

1. When replacing the new condenser, add compressor oil to the refrigeration cycle. Supplemental amount (approx. quantity) 20 ml {20cc, 0.7 fl oz.}

Refrigerant Line Installation Note

1. Apply compressor oil to the O-ring joints.
2. Tighten the piping joints.
