Control System - HVAC (Full Auto Air Conditioner): Overview Mazda RX-8 I рестайлинг

Scheme 13

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-367662-S24199587722010072700000) .)
3. Remove the keyless control module. (See «KEYLESS CONTROL MODULE REMOVAL/INSTALLATION»(ref-367649-S22374712322010072700000) .)
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.

Scheme 15

1. Connect battery positive voltage to air intake actuator terminal A (or C), and ground to terminal C (or A), and then verify that the air intake actuator operates as shown in «AIR INTAKE ACTUATOR OPERATION CHART»(ref-367648-S32014558952010072700000) . If the operation condition is not normal, replace the air intake actuator. AIR INTAKE ACTUATOR OPERATION CHART Terminal Air intake actuator operation G A C B+ Ground - RECIRCULATE-->FRESH B+ - Ground FRESH-->RECIRCULATE

Scheme 16

1. Disconnect the negative battery cable.
2. Remove the TCM. (AT) (See «TCM REMOVAL/INSTALLATION [SJ6A-EL]»(ref-367646-S22574760762010072700000) .)
3. Remove the A/C amplifier. (See «A/C AMPLIFIER REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-367648-S16757882682010072700000) .)
4. Remove in the order indicated in the figure.
5. Install in the reverse order of removal.

Scheme 17

Scheme 18

1. Connect battery positive voltage to air mix actuator terminal F (or G), and ground to terminal G (or F), and then verify that the air mix actuator operates as shown in «AIR MIX ACTUATOR OPERATION CHART»(ref-367648-S14330440562010072700000) . Apply the external power supply. If the operation condition is not normal, replace the air mix actuator. AIR MIX ACTUATOR OPERATION CHART Terminal Air mix actuator operation F G B+ Ground COLD-->HOT Ground B+ HOT-->COLD
2. Verify that the resistance between terminals A and E, and C and E matches the air mix actuator operation as shown in the graph. If the operation condition and resistance are not normal, replace the air mix actuator.
3. Install the air mix actuator with the lever the position shown in the figure.

Scheme 19
