Block Joint Type
- Disconnect the block joint type pipes by grasping the female side of the block with pliers or similar tool and holding firmly, and then remove the connection bolt or nut.
Scheme 62
Scheme 63
Scheme 64
- Install the SST (49 N061 0A0) to the arrow side of the clamp as shown in figure.
- Push the SST (49 N061 0A0) with your thumb until it snaps into the clamp. CAUTION: Excessive force to the SST (49 N061 0A0) may damage the clamp. Be careful not to press hard when inserting the SST (49 N061 0A0) into the clamp.
- Raise the stopper, and pull the SST (49 N061 0A0) from the piping.
- Remove the SST (49 N061 0A0) from the clamp.
| CAUTION | Be careful not to bend the SST (49 N061 0A0) needle when removing the clamp. If the SST (49 N061 0A0) needle is bent, the clamp can not be opened. |
Scheme 65
- Temporarily tighten the joint bolt by hand.
- Connect the block joint type pipes by grasping the female side of the block with pliers or similar tool and holding firmly, and then tighten the connection bolt or nut with a torque wrench.
