TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Connector Rod Cap Nuts | (1) | |
| Crankshaft Damper Bolt | ||
| Step 1 | 88 (120) | |
| Step 2 | Loosen One Full Turn | |
| Step 3 | 35-39 (47-53) | |
| Step 4 | Additional 85-95 Degrees | |
| Crankshaft Main Bearing Cap Bolts | (1) | |
| Cylinder Head Bolts (2) | ||
| Step 1 | 24-28 (32-38) | |
| Step 2 | Additional 85-95 Degrees | |
| Step 3 | Loosen One Full Turn | |
| Step 4 | 24-28 (32-38) | |
| Step 5 | Additional 85-95 Degrees | |
| Step 6 | Additional 85-95 Degrees | |
| Drive Belt Tensioner | 15-22 (20-30) | |
| EGR Pipe Nuts | 26-33 (35-45) | |
| EGR Valve Bolts | 14-19 (19-26) | |
| Engine Front Cover Bolts (3) | 15-22 (20-30) | |
| Engine Hanger Bolt | 73-92 (100-125) | |
| Engine Mount Nuts | 50-67(67-93) | |
| Engine Mount Through Bolts | 63-86 (85-116) | |
| Exhaust Manifold Nuts (4) (5) | 15-18 (20-25) | |
| Flex Plate Bolts (6) | 54-64 (73-87) | |
| Generator Bolts | 29-24 (40-55) | |
| Generator Bracket Bolts | 15-22 (20-30) | |
| Heated Oxygen Sensor | 22-36 (29-49) | |
| Knock Sensor | 15-22 (20-30) | |
| Oil Pan Drain Plug | 16-22 (22-30) | |
| Oil Pan Bolts (7) | 15-22 (20-30) | |
| Oil Pressure Switch | 9-12 (12-16) | |
| Spark Plug | 7-15 (9-20) | |
| Starter Motor Bolts | 28-38 (38-51) | |
| Transmission-To-Engine Bolts | 28-38 (38-51) | |
| INCH Lbs. (N.m) | ||
| A/C Pipe Stay Nut | 80-115 (9-13) | |
| Battery Clamp Nuts | 35-62 (4-7) | |
| Battery Tray Bolts & Nut | 71-106 (8-12) | |
| Camshaft Bearing Cap Bolts | 71-106 (8-12) | |
| Camshaft Position Sensor | 71-106 (8-12) | |
| Crankshaft Position Sensor | 71-106 (8-12) | |
| Ignition Coil Bolts | 53-70 (6-8) | |
| Intake Manifold Bolts (Lower) (8) | 71-106 (8-12) | |
| Intake Manifold Bolts (Upper) (9) | 71-106 (8-12) | |
| Oil Level Indicator Tube Bolt | 71-106 (8-12) | |
| Oil Pump Bolts (10) | 71-106 (8-12) | |
| Oil Strainer Bolts | 71-106 (8-12) | |
| Oil Strainer Stay Nut | ||
| Step 1 | 133 (15) | |
| Step 2 | Additional 45 Degrees | |
| PCM Connector Bolt | 26-44 (3-5) | |
| PCM Bracket Nuts | 80-115 (9-13) | |
| Radiator Bracket Bolts | 71-106 (8-12) | |
| Starter Motor Terminal Nuts | 89-106 (10-12) | |
| Thermostat Cover Bolts | 71-106 (8-12) | |
| Valve Cover Bolts (11) (12) | 71-106 (8-12) | |
| Water Bypass Tube Bolts | 71-106 (8-12) | |
| Water Pump Bolt | 89 (10) | |
| Water Pump Drive Belt Tensioner Bolt | 71-106 (8-12) | |
| (1) Specification not provided from manufacturer. (2) Tighten bolts in sequence. (Scheme 3) (3) Tighten bolts in sequence. (Scheme 4) (4) Tighten bolts in sequence. (Scheme 5) (5) Tighten bolts in sequence. (Scheme 6) (6) Tighten bolts in sequence. (Scheme 7) (7) Tighten bolts in sequence. (Scheme 8) (8) Tighten bolts in sequence. (Scheme 9) (9) Tighten bolts in sequence. (Scheme 10) (10) Tighten bolts in sequence. (Scheme 11) (11) Tighten bolts in sequence. (Scheme 12) (12) Tighten bolts in sequence. (Scheme 13) | ||
| (1) | Specification not provided from manufacturer. |
| (2) | Tighten bolts in sequence. (Scheme 3) |
| (3) | Tighten bolts in sequence. (Scheme 4) |
| (4) | Tighten bolts in sequence. (Scheme 5) |
| (5) | Tighten bolts in sequence. (Scheme 6) |
| (6) | Tighten bolts in sequence. (Scheme 7) |
| (7) | Tighten bolts in sequence. (Scheme 8) |
| (8) | Tighten bolts in sequence. (Scheme 9) |
| (9) | Tighten bolts in sequence. (Scheme 10) |
| (10) | Tighten bolts in sequence. (Scheme 11) |
| (11) | Tighten bolts in sequence. (Scheme 12) |
| (12) | Tighten bolts in sequence. (Scheme 13) |
