Open circuit

1. If there is no continuity, the circuit is open. Repair or replace the harness. IAC valve terminal A (harness-side) and 104 pin breakout box terminal 54 IAC valve terminal B (harness-side) and 104 pin breakout box terminal 83

Short circuit

1. If there is continuity, the circuit is short. Repair or replace the harness. IAC valve terminal A (harness-side) and power supply IAC valve terminal A (harness-side) and GND IAC valve terminal B (harness-side) and power supply IAC valve terminal B (harness-side) and GND

1. If there is no continuity, the circuit is open. Repair or replace the harness. IMCC actuator terminal B (harness-side) and 104 pin breakout box terminal 28 IMCC actuator terminal A (harness-side) and main relay (harness-side) terminal D

1. If there is continuity, the circuit is short. Repair or replace the harness. IMCC actuator terminal A (harness-side) and body GND IMCC actuator terminal B (harness-side) and power supply IMCC actuator terminal B (harness-side) and body GND

Scheme 142

Scheme 143

1. Remove in the order indicated.
2. Install in the reverse order of removal.
