FLUID CAPACITIES

Application	Dry Fill - Qts. (L)
LJ4A-EL	8.4 (8.0)

TRANSMISSION FLUID CAPACITIES

Torque converter is a sealed unit and cannot be disassembled for service. Inspect for damage and cracks. Replace torque converter if defective. Remove any rust from pilot hub and boss of converter.
Flush torque converter. After converter is removed from cleaner, thoroughly drain solvent through hub. Add about 2.1 qt. (2.0L) of clean ATF to converter. Agitate fluid by hand. Drain ATF from converter.

Application	Ft. Lbs. (N.m)
Converter Housing-To-Transaxle Case Bolt	20-22 (27-30)
Drum Support Bolt	12-15 (16-21)
Oil Pan Drain Plug	29-39 (40-53)
Oil Pump Cover Bolt	(1) 18-20 (24-27)
Oil Pump-To-Transaxle Case Bolt	18-20 (24-27)
Output Gear Nut	145-180 (197-245)
Shift Control (Manual) Rod Nut	12-16 (16-22)
Side Cover Bolt	14-16 (19-22)
2-4 Brake Band Lock Nut	24-31 (31-42)
INCH Lbs. (N.m)
Detent Spring Bolt	35-53 (4.0-5.8)
Location Bolt	70-86 (7.9-9.8)
Manual Rod Bracket Bolt	70-95 (7-10)
Oil Filter Bolt	62-80 (7-9)
Output Speed Sensor	44-61 (5-7)
Parking Mechanism Bracket-To-Case Bolt	35-52 (4-6)
Transmission Range Sensor Bolt	27-35 (3-4)
Valve Body Bolt	62-80 (7-9)
Valve Body Oil Pan Bolt	62-80 (7-9)
Valve Body-To-Case Bolt	62-80 (7-9)
Vehicle Speed Sensor Bolt	71-97 (8-11)
(1) Tighten in sequence. see scheme 97

(1)	Tighten in sequence. see scheme 97

TORQUE SPECIFICATIONS

Application			Specification
Band Servo
Servo Piston Diameter
Large			2.835" (72 mm)
Small			1.732" (42 mm)
4th Gear Servo Piston Outer Diameter			2.047" (52 mm)
Clutch Drive Plate Minimum Thickness
Forward Clutch			0.071" (1.80 mm)
All Other Clutches			0.055" (1.40 mm)
Clutch Pack Clearance
Forward Clutch			0.018-0.033" (0.45-0.85 mm)
No. Of Drive/Driven Plates			6/6
High Clutch			0.071-0.086" (1.80-2.20 mm)
No. Of Drive/Driven Plates			4/7
Low & Reverse Clutch			0.067-0.083" (1.70-2.10 mm)
No. Of Drive/Driven Plates			7/7
Overrunning Clutch			0.028-0.043" (0.70-1.10 mm)
No. Of Drive/Driven Plates			3/5
Reverse Clutch			0.020-0.031" (0.50-0.80 mm)
No. Of Drive/Driven Plates			2/3
Front Planetary Carrier (No. Of Teeth)
Sun Gear			33
Pinion Gear			21
Internal Gear			75
Idler Gear (No. Of Teeth)			53
Oil Pump
Bearing Outer Diameter			2.0" (51 mm)
Rotor End Clearance
Standard			0.0008-0.0015" (0.020-0.040 mm)
Service Limit			0.0019" (0.050 mm)
Rotor Side Clearance
Standard			0.0008-0.0059" (0.020-0.150 mm)
Service Limit			0.0059" (0.150 mm)
Output Gear (No. Of Teeth)			59
Pinion Gear Backlash			0.004-0.008" (0.10-0.20 mm)
Rear Planetary Carrier (No. Of Teeth)
Sun Gear			42
Pinion Gear			17
Internal Gear			75
Reduction Gear (No. Of Teeth)			17
Reverse Clutch End Play			0.022-0.035" (0.55-0.90)
Ring Gear (No. Of Teeth)			72
Torque Converter Depth			0.551" (14.00 mm)
Torque Converter Stall Torque Ratio			2.110:1
Total End Play			0.010-0.022" (0.25-0.55 mm)
Differential Bearing Preload			70-104 INCH Lbs. (7.9-11.7 N.m)

TRANSAXLE SPECIFICATIONS

Scheme 112: SPECIAL TOOLS
