Automatic Transaxle Shift Mechanism: Overview Mazda 6 GJ

Scheme 1311

Scheme 1312

Scheme 1313

1. Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Disconnect the selector lever component connector. (Scheme 1311): Selector Lever Component Connector
2. Remove the selector lever component. Disconnect the selector cable from the selector lever component. (Scheme 1312): Selector Cable Remove the selector lever component. (Scheme 1313): Selector Lever Component And Nuts With Torque Specification
3. Install in the reverse order of removal.

Scheme 1314

1. Disconnect the negative battery cable.
2. Remove the aerodynamic under cover NO.2. (FS5A-EL) (See «AERODYNAMIC UNDER COVER NO.2 REMOVAL/INSTALLATION»(ref-581657-S19487724012013101400000).)
3. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).)
4. Remove the dashboard. (See «DASHBOARD REMOVAL/INSTALLATION»(ref-581614-S23273769092013101400000).)
5. Remove the A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-581666-S35905141042013101400000).)
6. Remove the SAS control module. (See «SAS CONTROL MODULE REMOVAL/INSTALLATION»(ref-581610-S09754629802013101400000).)
7. Remove in the order indicated in the table.
8. Install in the reverse order of removal.
9. Adjust the selector cable after having installed. (See «SELECTOR CABLE ADJUSTMENT»(ref-581689-S20551449592013101400000).) (Scheme 1314): Selector Cable Components With Torque Specification

Scheme 1315

Scheme 1316

Scheme 1317

1. Remove the negative battery cable.
2. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).)
3. Shift the selector lever to the P position.
4. Unlock the lock piece of the selector cable (selector lever side) in the order as shown in the figure. (Scheme 1315): Lock Piece And Safety Lock
5. Verify that the manual shaft is in the P position. (Scheme 1316): Manual Shaft In P Position
6. Lock the lock piece and safety lock of the selector cable (selector lever side) in the order as shown in the figure. (Scheme 1317): Lock Piece And Safety Lock

Scheme 1318

1. Switch the ignition to ON.
2. Perform the following procedures to inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581689-S41787927862013101400000).) Verify that the selector lever can be operated as shown in the figure. (Scheme 1318): Selector Lever Operation Diagram Verify that the selector lever can be operated smoothly and moderately.

Shift-Lock System Inspection

1. Switch the ignition to ON.
2. Shift the selector lever to the P position.
3. Perform the following procedures to inspect the shift-lock system. If there is any malfunction, inspect the shift-lock solenoid. (See «SHIFT-LOCK SOLENOID INSPECTION»(ref-581689-S31593321102013101400000) .) Verify that the selector lever cannot be selected from P to R position when the brake pedal is released. Verify that the selector lever can be selected from P to R position when the brake pedal is depressed.

Shift-Lock Solenoid Inspection

Scheme 1319

Scheme 1320

1. Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the rear console. (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Disconnect the selector lever component connector. (Scheme 1319): Identifying Selector Lever Component Connector
2. According to the table, measure the voltage between selector lever component terminals and body GND. (Scheme 1320): Identifying Selector Lever Component Connector Terminals If there is any malfunction, repair or replace the related wiring harness. If there is no malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581689-S41787927862013101400000).) VOLTAGE SPECIFICATION Terminal Connected to Test condition Voltage (V) E-GND Brake switch Brake pedal depressed B+ Brake pedal released Below 1.0 I-GND Ignition switch Switch the ignition to ACC or ON B+ Switch the ignition to off Below 1.0 K-GND Body GND Under any conditions Below 1.0

Scheme 1321

1. Switch the ignition to off.
2. Verify that the selector lever is in the P position.
3. Without the brake pedal depressed, verify that the selector lever cannot be shifted from the P position.
4. Remove the panel cover using a tape-wrapped flathead screwdriver as shown in the figure. (Scheme 1321): Removing Panel Cover Using Tape-Wrapped Flathead Screwdriver
5. Insert the flathead screwdriver into the emergency override hole and push it down.
6. Verify that the selector lever can be shifted from the P position. If there is any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-581689-S41787927862013101400000).)
