Interior: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 37

Scheme 38

1. REMOVE REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
2. REMOVE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
3. REMOVE REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
4. REMOVE REAR DOOR TRIM COVER LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
5. REMOVE REAR DOOR FRAME GARNISH LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
6. REMOVE REAR DOOR NO. 2 FRAME GARNISH LH (See «REMOVAL»(ref-349743-S08341206512009120800000) )
7. REMOVE REAR CURTAIN SUB-ASSEMBLY LH for Standard Body: Remove the rear curtain. Remove the 10 screws. Detach the 3 clips, disconnect the connector and remove the curtain. for Long Body: Remove the rear curtain. Remove the 10 screws. Detach the 4 clips, disconnect the connector and remove the curtain.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. INSPECT REAR CURTAIN SUB-ASSEMBLY LH Apply battery voltage and check the operation of the rear curtain LH. OK SPECIFIED CONDITION CHART Measurement Condition Specified Condition Battery's positive (+) lead to terminal 2 (SSA+) and negative (-) lead to terminal 1 (SSA-) Rear curtain raises Battery's positive (+) lead to terminal 1 (SSA-) and negative (-) lead to terminal 2 (SSA+) Rear curtain lowers HINT: To prevent the motor from burning out, stop operation as soon as the rear curtain is fully raised or lowered. CAUTION: Be careful when the rear curtain raises and lowers. Something could get caught in the rear curtain and cause an injury.
2. INSPECT REAR CURTAIN SUB-ASSEMBLY RH Apply battery voltage and check the operation of the rear curtain RH. OK SPECIFIED CONDITION CHART Measurement Condition Specified Condition Battery's positive (+) lead to terminal 2 (SSA+) and negative (-) lead to terminal 1 (SSA-) Rear curtain raises Battery's positive (+) lead to terminal 1 (SSA-) and negative (-) lead to terminal 2 (SSA+) Rear curtain lowers HINT: To prevent the motor from burning out, stop operation as soon as the rear curtain is fully raised or lowered. CAUTION: Be careful when the rear curtain raises and lowers. Something could get caught in the rear curtain and cause an injury.
3. INSPECT CURTAIN SWITCH ASSEMBLY for Fixed Seat Type: Remove the curtain switch assembly (see «DISASSEMBLY»(ref-349741-S13569311732009120800000) ). for Power Seat: Remove the curtain switch assembly (see «DISASSEMBLY»(ref-349741-S14719108602009120800000) ). Measure the voltage between the terminals when the switch is operated. HINT: As the circuit has a diode, perform the measurement with the tester in diode mode. Standard voltage VOLTAGE SPECIFICATION Tester Connection Switch Condition Specified Condition Tester positive (+) lead --> 18 (SW2) - Tester negative (-) lead --> 4 (SWE2) Rear Door Sunshade Switch LH ON Below 1.5 V Tester positive {+) lead --> 13 (SW3) - Tester negative (-) lead --> 4 (SWE2) Rear Door Sunshade Switch RH ON Below 1.5 V If the result is not as specified, replace the curtain switch.
4. INSPECT INTEGRATION CONTROL AND PANEL ASSEMBLY Remove the integration control and panel assembly (see «REMOVAL»(ref-349723-S41495230852009120800000) ). Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Switch Condition Specified Condition 8 - 11 Rear door sunshade switch is pushed Below 1 ohms 8 - 11 Rear door sunshade switch is not pushed 10 kohms or higher If the result is not as specified, replace the integration control and panel.

INSTALLATION

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. INSTALL REAR CURTAIN SUB-ASSEMBLY LH for Standard Body: Install the rear curtain. Connect the connector and attach the 3 clips to install the curtain. Install the 10 screws. for Long Body: Install the rear curtain. Connect the connector and attach the 4 clips to install the curtain. Install the 10 screws.
2. INSTALL REAR DOOR NO. 2 FRAME GARNISH LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
3. INSTALL REAR DOOR FRAME GARNISH LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
4. INSTALL REAR DOOR TRIM COVER LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
5. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
6. INSTALL REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
7. INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG LH (See «INSTALLATION»(ref-349743-S20724193642009120800000) )
8. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-349706-S07943075812009120800000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
3. REMOVE FRONT SEAT ASSEMBLY Remove the front seat (See «REMOVAL»(ref-349741-S20172361262009120800000) ).
4. REMOVE REAR SEAT ASSEMBLY (for Fixed Type) Remove the rear seat (See «REMOVAL»(ref-349741-S36365163922009120800000) ).
5. REMOVE REAR SEAT ASSEMBLY (for Power Seat) Remove the rear seat (See «REMOVAL»(ref-349741-S26853688812009120800000) ).
6. REMOVE FRONT DOOR SCUFF PLATE LH Put protective tape around the front door scuff plate. Using a molding remover, detach the 4 clips. Detach the 7 claws and remove the front door scuff plate LH.
7. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
8. REMOVE COWL SIDE TRIM BOARD LH Detach the 3 claws and remove the cowl side trim board.
9. REMOVE COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
10. REMOVE FRONT PILLAR GARNISH LH Detach the 2 clips from the vehicle body. Cut off clip A. Detach the claw and remove the front pillar garnish. Remove clip A from the vehicle body. Protect the curtain shield airbag assembly. Completely cover the airbag with a cloth or nylon sheet and secure the ends of the cover with adhesive tape, as shown in the illustration. NOTE: Cover the curtain shield airbag with a protective cover as soon as the front pillar garnish is removed.
11. REMOVE FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
12. REMOVE REAR DOOR SCUFF PLATE LH Put protective tape around the rear door scuff plate. Using a molding remover, detach the 3 clips. Detach the 7 claws and remove the rear door scuff plate.
13. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
14. REMOVE CENTER LOWER PILLAR GARNISH LH Detach the 2 claws and 6 clips, and remove the center lower pillar garnish.
15. REMOVE CENTER LOWER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
16. REMOVE CENTER UPPER PILLAR GARNISH LH Remove the 2 screws. Detach the claw. Pass the front seat outer belt floor anchor through the center upper pillar garnish, and remove the center upper pillar garnish.
17. REMOVE CENTER PILLAR GARNISH UPPER RH HINT: Use the same procedure described for the LH side.
18. REMOVE SHOULDER BELT ANCHOR COVER LH Detach the 6 claws of the cover, and slide the cover in the direction of the arrow to remove it.
19. REMOVE SHOULDER BELT ANCHOR COVER RH HINT: Use the same procedure described for the LH side.
20. REMOVE REAR SEAT SIDE GARNISH LH Detach the 6 claws and remove the rear seat side garnish.
21. REMOVE REAR SEAT SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
22. REMOVE INNER ROOF SIDE GARNISH LH Pull the garnish away from the body and detach the 4 clips (do not detach clip A). Detach the 2 claws of the guide, and pull the inner roof side garnish in the direction of the arrow to remove it. HINT: Clip A remains attached to the body. Remove clip A from the vehicle body.
23. REMOVE INNER ROOF SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
24. REMOVE MAP LIGHT ASSEMBLY Using a screwdriver, detach the 2 claws and open the 2 covers. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a molding remover, detach the 2 clips. Disconnect the 2 connectors and then remove the map light.
25. REMOVE SPOT LIGHT ASSEMBLY Using a molding remover, detach the 4 claws. Disconnect the connector and then remove the spot light.
26. REMOVE REAR VANITY LIGHT ASSEMBLY HINT: Use the same procedure to remove the vanity light on the other side. Using a screwdriver, detach the 4 claws and remove the lens. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a molding remover, detach the claw. Disconnect the connector and then remove the vanity light.
27. REMOVE COAT HOOK (w/o Rear Cooler) HINT: Use the same procedure to remove the hook on the other side. Remove the screw and coat hook.
28. REMOVE ROOF SIDE REGISTER BEZEL LH (w/ Rear Cooler) Remove the screw. Detach the claw and remove the roof side register.
29. REMOVE ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) HINT: Use the same procedure described for the LH side.
30. REMOVE ASSIST GRIP SUB-ASSEMBLY HINT: Use the same procedure for all the assist grips. Using a screwdriver, detach the 4 claws and remove the 2 assist grip covers. HINT: Tape the screwdriver tip before use. Detach the 2 clips and remove the assist grip.
31. REMOVE VISOR BRACKET COVER HINT: Use the same procedure to remove the cover on the other side. Using a molding remover, detach the 4 claws and remove the visor bracket cover.
32. REMOVE VISOR ASSEMBLY LH Remove the 2 screws and visor.
33. REMOVE VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
34. REMOVE VISOR HOLDER HINT: Use the same procedure to remove the holder on the other side. Turn the visor holder approximately 45° and pull it out as shown in the illustration. Detach the 2 claws and remove the visor holder.
35. REMOVE FRONT WIPER ARM LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
36. REMOVE FRONT WIPER ARM RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
37. REMOVE FRONT FENDER TO COWL SIDE SEAL LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
38. REMOVE FRONT FENDER TO COWL SIDE SEAL RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
39. REMOVE HOOD TO COWL TOP SEAL (See «REMOVAL»(ref-349735-S07548571092009120800000) )
40. REMOVE COWL TOP VENTILATOR LOUVER PROTECTOR LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
41. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-349735-S07548571092009120800000) )
42. REMOVE CENTER ROOF DRIP SIDE FINISH MOLDING LH Remove the center roof drip side finish molding (See «REMOVAL»(ref-349736-S10538419072009120800000) ).
43. REMOVE CENTER ROOF DRIP SIDE FINISH MOLDING RH HINT: Use the same procedure described for the LH side.
44. REMOVE RAIN SENSOR COVER (See «REMOVAL»(ref-349753-S08426038372009120800000) )
45. DISCONNECT RAIN SENSOR CONNECTOR
46. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (See «REMOVAL»(ref-349753-S08426038372009120800000) )
47. REMOVE UPPER WINDSHIELD OUTSIDE MOLDING (See «REMOVAL»(ref-349760-S30975639572009120800000) )
48. REMOVE WINDSHIELD GLASS (See «REMOVAL»(ref-349760-S30975639572009120800000) )
49. REMOVE NO. 2 WINDSHIELD GLASS STOPPER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
50. REMOVE WINDSHIELD GLASS RETAINER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
51. REMOVE WINDSHIELD GLASS ADHESIVE DAM (See «REMOVAL»(ref-349760-S30975639572009120800000) )
52. REMOVE WINDSHIELD GLASS SEAL (See «REMOVAL»(ref-349760-S30975639572009120800000) )
53. CLEAN WINDSHIELD GLASS (See «REMOVAL»(ref-349760-S30975639572009120800000) )
54. REMOVE NO. 1 WINDSHIELD GLASS STOPPER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
55. CLEAN VEHICLE BODY (See «REMOVAL»(ref-349760-S30975639572009120800000) )
56. REMOVE ROOF HEADLINING ASSEMBLY Disconnect the roof wire connectors and detach each clamp from the front pillar. w/ Sliding Roof: Disconnect the drive gear connector. w/o Sliding Roof: Detach the hook, 12 claws, 3 fasteners and 4 clips. w/ Sliding Roof: Detach the hook, 12 claws, 10 fasteners and 4 clips. Remove the roof headlining through the front of the vehicle.
57. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
58. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
59. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
60. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH

Scheme 81

Scheme 82

Scheme 83

1. REMOVE ROOF SILENCER PAD w/o Sliding Roof: Remove the 4 roof silencer pads. w/ Sliding Roof, w/o Rear Cooler: Remove the 4 roof silencer pads. w/ Sliding Roof, w/ Rear Cooler: Remove the 4 roof silencer pads.
2. REMOVE NO. 1 ROOF WIRE Detach the 2 claws and remove the bulb holder from the vanity light. HINT: Use the same procedure to remove the bulb holder on the other side. Remove the double-sided tape and roof wire.

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. INSTALL NO. 1 ROOF WIRE w/o Sliding Roof: Apply double-sided tape to the areas of the roof headlining as shown in the illustration. Align the wire harness marking of the roof wire with the front part of the roof headlining (A), and apply tape {width: 8 mm (0.314 in.)} to fix the roof wire in place. Remove the peeling paper of the double-sided tape, and place the roof wire on the roof headlining along the wire harness marking areas. Fix the roof wire in place by applying vinyl tape to the wire harness marking areas of the roof wire as shown in the illustration. For areas near connectors, apply the vinyl tape as shown in the part of the illustration labeled (A). Attach the 2 claws to install the bulb holder. HINT: Use the same procedure to install the bulb holder on the other side. w/ Sliding Roof: Apply double-sided tape to the areas of the roof headlining as shown in the illustration. Align the wire harness marking of the roof wire with the front part of the roof headlining (A), and apply tape {width: 8 mm (0.314 in.)} to fix the roof wire in place. Remove the peeling paper of the double-sided tape, and place the roof wire on the roof headlining along the wire harness marking areas. Fix the roof wire in place by applying vinyl tape to the wire harness marking areas of the roof wire as shown in the illustration. For areas near connectors, apply the vinyl tape as shown in the part of the illustration labeled (A). Attach the 2 claws to install the bulb holder. HINT: Use the same procedure to install the bulb holder on the other side.
2. INSTALL ROOF SILENCER PAD w/o Sliding Roof: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape. w/ Sliding Roof, w/o Rear Cooler: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape. w/ Sliding Roof, w/ Rear Cooler: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape.

HINT

A bolt without a torque specification is shown in the standard bolt chart (See SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

1. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH Install the front door opening trim weatherstrip as shown in the illustration.
2. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure described for the LH side.
3. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH Install the rear door opening trim weatherstrip as shown in the illustration.
4. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure described for the LH side.
5. PLACE ROOF HEADLINING ASSEMBLY IN VEHICLE Place the roof headlining into the vehicle through the front side. HINT: Place the roof headlining into the vehicle so that the windshield can be installed.
6. INSTALL NO. 1 WINDSHIELD GLASS STOPPER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
7. INSTALL NO. 2 WINDSHIELD GLASS STOPPER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
8. INSTALL UPPER WINDSHIELD OUTSIDE MOLDING (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
9. INSTALL WINDSHIELD GLASS RETAINER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
10. INSTALL WINDSHIELD GLASS ADHESIVE DAM (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
11. INSTALL WINDSHIELD GLASS SEAL (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
12. INSTALL WINDSHIELD GLASS (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
13. CHECK FOR LEAK AND REPAIR (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
14. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
15. CONNECT RAIN SENSOR CONNECTOR
16. INSTALL RAIN SENSOR COVER (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
17. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING LH Install the center roof drip side finish molding (See «INSTALLATION»(ref-349736-S01712591262009120800000) ).
18. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING RH HINT: Use the same procedure described for the LH side.
19. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
20. INSTALL COWL TOP VENTILATOR LOUVER PROTECTOR LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
21. INSTALL HOOD TO COWL TOP SEAL (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
22. INSTALL FRONT FENDER TO COWL SIDE SEAL LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
23. INSTALL FRONT FENDER TO COWL SIDE SEAL RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
24. INSTALL FRONT WIPER ARM LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
25. INSTALL FRONT WIPER ARM RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
26. INSTALL ROOF HEADLINING ASSEMBLY w/o Sliding Roof: Attach the hook, 12 claws, 3 fasteners and 4 clips to install the roof headlining. w/ Sliding Roof: Attach the hook, 12 claws, 10 fasteners and 4 clips to install the roof headlining. w/ Sliding Roof: Connect the drive gear connector. Connect the roof wire connectors and attach each clamp.
27. INSTALL VISOR HOLDER HINT: Use the same procedure to install the holder on the other side. Attach the 2 claws to install the visor holder. Push in the visor holder and turn it approximately 45° as shown in the illustration.
28. INSTALL VISOR ASSEMBLY LH Install the visor with the 2 screws.
29. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
30. INSTALL VISOR BRACKET COVER HINT: Use the same procedure to install the cover on the other side. Attach the 4 claws to install the visor bracket cover.
31. INSTALL ASSIST GRIP SUB-ASSEMBLY HINT: Use the same procedure for all the assist grips. Assemble the assist grip, 2 clips and 2 covers as shown in the illustration. Install the assist grip.
32. INSTALL COAT HOOK (w/o Rear Cooler) HINT: Use the same procedure to install the hook on the other side. Install the coat hook with the screw.
33. INSTALL ROOF SIDE REGISTER BEZEL LH (w/ Rear Cooler) Attach the claw to install the roof side register bezel. Install the screw.
34. INSTALL ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) HINT: Use the same procedure described for the LH side.
35. INSTALL REAR VANITY LIGHT ASSEMBLY HINT: Use the same procedure to install the vanity light on the other side. Connect the connector. Attach the claw to install the vanity light. Install the 2 screws. Attach the 4 claws to install the lens.
36. INSTALL SPOT LIGHT ASSEMBLY Connect the connector. Attach the 4 claws to install the spot light.
37. INSTALL MAP LIGHT ASSEMBLY Connect the 2 map light connectors. Attach the 2 clips to install the map light. Install the 2 screws. Attach the 2 claws to close the 2 covers.
38. INSTALL INNER ROOF SIDE GARNISH LH Install a new clip A to the inner roof side garnish. Attach the 5 clips and 2 claws to install the inner roof side garnish.
39. INSTALL INNER ROOF SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
40. INSTALL REAR SEAT SIDE GARNISH LH Attach the 6 claws to install the rear seat side garnish.
41. INSTALL REAR SEAT SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
42. INSTALL SHOULDER BELT ANCHOR COVER LH Slide the cover in the direction shown in the illustration and attach the 6 claws to install the cover.
43. INSTALL SHOULDER BELT ANCHOR COVER RH HINT: Use the same procedure described for the LH side.
44. INSTALL CENTER UPPER PILLAR GARNISH LH Pass the front seat outer belt floor anchor through the center upper pillar garnish. Attach the claw to install the center upper pillar garnish. Install the 2 screws.
45. INSTALL CENTER UPPER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
46. INSTALL CENTER LOWER PILLAR GARNISH LH Attach the 2 claws and 6 clips to install the center lower pillar garnish.
47. INSTALL CENTER LOWER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
48. INSTALL REAR DOOR SCUFF PLATE LH Attach the 3 clips. Attach the 7 claws to install the rear door scuff plate.
49. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
50. INSTALL FRONT PILLAR GARNISH LH Install a new clip A to the front pillar garnish. Attach the claw and 2 clips to install the front pillar garnish.
51. INSTALL FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
52. INSTALL COWL SIDE TRIM BOARD LH Attach the 3 claws to install the cowl side trim board.
53. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
54. INSTALL FRONT DOOR SCUFF PLATE LH Attach the 4 clips. Attach the 7 claws to install the front door scuff plate.
55. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
56. INSTALL REAR SEAT ASSEMBLY (for Fixed Type) Install the rear seat (See «INSTALLATION»(ref-349741-S36437420052009120800000) ).
57. INSTALL REAR SEAT ASSEMBLY (for Power Seat) Install the rear seat (See «INSTALLATION»(ref-349741-S24840229242009120800000) ).
58. INSTALL FRONT SEAT ASSEMBLY Install the front seat (See «INSTALLATION»(ref-349741-S29651146302009120800000) ).
59. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
60. CHECK SRS WARNING LIGHT Check the SRS warning light (See «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
61. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349732-S09051375432009120800000) )

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to disable the SRS system. NOTE: After the engine switch is turned off, the HDD navigation system requires approximately 6 minutes to record various types of memory and settings. As a result, after turning the engine switch off, wait 6 minutes or more before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
3. REMOVE FRONT SEAT ASSEMBLY Remove the front seat (See «REMOVAL»(ref-349741-S20172361262009120800000) ).
4. REMOVE REAR SEAT ASSEMBLY (for Fixed Type) Remove the rear seat (See «REMOVAL»(ref-349741-S36365163922009120800000) ).
5. REMOVE REAR SEAT ASSEMBLY (for Power Seat) Remove the rear seat (See «REMOVAL»(ref-349741-S26853688812009120800000) ).
6. REMOVE REAR SEAT ASSEMBLY (for Ottoman) Remove the rear seat (See «REMOVAL»(ref-349741-S19112888892009120800000) ).
7. REMOVE FRONT DOOR SCUFF PLATE LH Put protective tape around the front door scuff plate. Using a molding remover, detach the 4 clips. Detach the 7 claws and remove the front door scuff plate.
8. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
9. REMOVE COWL SIDE TRIM BOARD LH Detach the 3 claws and remove the cowl side trim board.
10. REMOVE COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
11. REMOVE FRONT PILLAR GARNISH LH Detach the 2 clips. Cut off clip A. Detach the claw and remove the front pillar garnish LH. Remove clip A from the vehicle body. Protect the curtain shield airbag assembly. Completely cover the airbag with a cloth or nylon sheet and secure the ends of the cover with adhesive tape, as shown in the illustration. NOTE: Cover the curtain shield airbag with a protective cover as soon as the front pillar garnish is removed.
12. REMOVE FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
13. REMOVE REAR DOOR SCUFF PLATE LH Put protective tape around the rear door scuff plate. Using a molding remover, detach the 4 clips. Detach the 7 claws and remove the rear door scuff plate.
14. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
15. REMOVE CENTER LOWER PILLAR GARNISH LH Detach the 2 claws and 6 clips, and remove the center lower pillar garnish.
16. REMOVE CENTER LOWER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
17. REMOVE CENTER UPPER PILLAR GARNISH LH Remove the 2 screws. Detach the claw. Pass the front seat outer belt floor anchor through the center upper pillar garnish, and remove the center upper pillar garnish.
18. REMOVE CENTER UPPER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
19. REMOVE SHOULDER BELT ANCHOR COVER LH Detach the 6 claws of the cover, and slide the cover in the direction of the arrow to remove it.
20. REMOVE SHOULDER BELT ANCHOR COVER RH HINT: Use the same procedure described for the LH side.
21. REMOVE REAR SEAT SIDE GARNISH LH Detach the 6 claws and remove the rear seat side garnish.
22. REMOVE REAR SEAT SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
23. REMOVE INNER ROOF SIDE GARNISH LH Pull the garnish away from the body and detach the 4 clips (do not detach clip A). Detach the 2 claws of the guide, and pull the inner roof side garnish in the direction of the arrow to remove it. HINT: Clip A remains attached to the body. Remove clip A from the vehicle body.
24. REMOVE INNER ROOF SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
25. REMOVE MAP LIGHT ASSEMBLY Using a screwdriver, detach the 2 claws and open the 2 covers. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a molding remover, detach the 2 clips. Disconnect the 2 connectors and then remove the map light.
26. REMOVE SPOT LIGHT LENS (w/ Rear Seat Entertainment System) Detach the 4 claws and remove the spot light lens.
27. REMOVE ROOF CONSOLE BOX ASSEMBLY (w/ Rear Seat Entertainment System) Remove the 2 screws. Detach the 6 clips and 2 claws. w/o Infrared Rays Sensor: Disconnect the connector and then remove the roof console box. w/ Infrared Rays Sensor: Disconnect the 2 connectors and then remove the roof console box.
28. REMOVE SPOT LIGHT ASSEMBLY (w/o Rear Seat Entertainment System) Using a molding remover, detach the 4 claws. Disconnect the connector and then remove the spot light.
29. REMOVE REAR VANITY LIGHT ASSEMBLY HINT: Use the same procedure to remove the vanity light on the other side. Using a screwdriver, detach the 4 claws and remove the lens. HINT: Tape the screwdriver tip before use. Remove the 2 screws. Using a molding remover, detach the claw. Disconnect the connector and then remove the vanity light.
30. REMOVE COAT HOOK (w/o Rear Cooler) HINT: Use the same procedure to remove the hook on the other side. Remove the screw and coat hook.
31. REMOVE ROOF SIDE REGISTER BEZEL LH (w/ Rear Cooler) Remove the screw. Detach the claw and remove the roof side register.
32. REMOVE ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) HINT: Use the same procedure described for the LH side.
33. REMOVE ASSIST GRIP SUB-ASSEMBLY HINT: Use the same procedure for all the assist grips. Using a screwdriver, detach the 4 claws and remove the 2 assist grip covers. HINT: Tape the screwdriver tip before use. Detach the 2 clips and remove the assist grip.
34. REMOVE VISOR BRACKET COVER HINT: Use the same procedure to remove the cover on the other side. Using a molding remover, detach the 4 claws and remove the visor bracket cover.
35. REMOVE VISOR ASSEMBLY LH Remove the 2 screws and visor.
36. REMOVE VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
37. REMOVE VISOR HOLDER HINT: Use the same procedure to remove the holder on the other side. Turn the visor holder approximately 45° and pull it out as shown in the illustration. Detach the 2 claws and remove the visor holder.
38. REMOVE FRONT WIPER ARM LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
39. REMOVE FRONT WIPER ARM RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
40. REMOVE HOOD TO COWL TOP SEAL (See «REMOVAL»(ref-349735-S07548571092009120800000) )
41. REMOVE FRONT FENDER TO COWL SIDE SEAL LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
42. REMOVE FRONT FENDER TO COWL SIDE SEAL RH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
43. REMOVE COWL TOP VENTILATOR LOUVER PROTECTOR LH (See «REMOVAL»(ref-349735-S07548571092009120800000) )
44. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-349735-S07548571092009120800000) )
45. REMOVE CENTER ROOF DRIP SIDE FINISH MOLDING LH Remove the center roof drip side finish molding (See «REMOVAL»(ref-349736-S10538419072009120800000) ).
46. REMOVE CENTER ROOF DRIP SIDE FINISH MOLDING RH HINT: Use the same procedure described for the LH side.
47. REMOVE RAIN SENSOR COVER (See «REMOVAL»(ref-349753-S08426038372009120800000) )
48. DISCONNECT RAIN SENSOR CONNECTOR
49. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (See «REMOVAL»(ref-349753-S08426038372009120800000) )
50. REMOVE UPPER WINDSHIELD OUTSIDE MOLDING (See «REMOVAL»(ref-349760-S30975639572009120800000) )
51. REMOVE WINDSHIELD GLASS (See «REMOVAL»(ref-349760-S30975639572009120800000) )
52. REMOVE NO. 2 WINDSHIELD GLASS STOPPER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
53. REMOVE WINDSHIELD GLASS RETAINER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
54. REMOVE WINDSHIELD GLASS ADHESIVE DAM (See «REMOVAL»(ref-349760-S30975639572009120800000) )
55. REMOVE WINDSHIELD GLASS SEAL (See «REMOVAL»(ref-349760-S30975639572009120800000) )
56. CLEAN WINDSHIELD GLASS (See «REMOVAL»(ref-349760-S30975639572009120800000) )
57. REMOVE NO. 1 WINDSHIELD GLASS STOPPER (See «REMOVAL»(ref-349760-S30975639572009120800000) )
58. CLEAN VEHICLE BODY (See «REMOVAL»(ref-349760-S30975639572009120800000) )
59. REMOVE ROOF HEADLINING ASSEMBLY Disconnect the roof wire connectors and detach each clamp from the front pillar. w/ Sliding Roof: Disconnect the drive gear connector. w/o Sliding Roof: Detach the hook, 12 claws, 3 fasteners and 4 clips. w/ Sliding Roof: Detach the hook, 12 claws, 10 fasteners and 4 clips. w/ Rear Seat Entertainment System: Detach the hook, 12 claws, 8 fasteners and 4 clips. Remove the roof headlining through the front of the vehicle.
60. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
61. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
62. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
63. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH

Scheme 136

Scheme 137

Scheme 138

Scheme 139

1. REMOVE ROOF SILENCER PAD w/o Sliding Roof: Remove the 5 roof silencer pads. w/ Sliding Roof, w/o Rear Cooler: Remove the 5 roof silencer pads. w/ Sliding Roof, w/ Rear Cooler: Remove the 5 roof silencer pads. w/ Rear Seat Entertainment System: Remove the 6 roof silencer pads.
2. REMOVE NO. 1 ROOF WIRE Detach the 2 claws and remove the bulb holder from the vanity light. HINT: Use the same procedure to remove the bulb holder on the other side. Remove the double-sided tape and roof wire.

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

1. INSTALL NO. 1 ROOF WIRE w/o Sliding Roof: Apply double-sided tape to the areas of the roof headlining as shown in the illustration. Align the wire harness marking of the roof wire with the front part of the roof headlining (A), and apply tape {width: 8 mm (0.314 in.)} to fix the roof wire in place. Remove the peeling paper of the double-sided tape, and place the roof wire on the roof headlining along the wire harness marking areas. Fix the roof wire in place by applying vinyl tape to the wire harness marking areas of the roof wire as shown in the illustration. For areas near connectors, apply the vinyl tape as shown in the part of the illustration labeled (A). Attach the 2 claws to install the bulb holder. HINT: Use the same procedure to install the bulb holder on the other side. w/ Sliding Roof: Apply double-sided tape to the areas of the roof headlining as shown in the illustration. Align the wire harness marking of the roof wire with the front part of the roof headlining (A), and apply tape {width: 8 mm (0.314 in.)} to fix the roof wire in place. Remove the peeling paper of the double-sided tape, and place the roof wire on the roof headlining along the wire harness marking areas. Fix the roof wire in place by applying vinyl tape to the wire harness marking areas of the roof wire as shown in the illustration. For areas near connectors, apply the vinyl tape as shown in the part of the illustration labeled (A). Attach the 2 claws to install the bulb holder. HINT: Use the same procedure to install the bulb holder on the other side.
2. INSTALL ROOF SILENCER PAD w/o Sliding Roof: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape. w/ Sliding Roof, w/o Rear Cooler: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape. w/ Sliding Roof, w/ Rear Cooler: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape. w/ Rear Seat Entertainment System: Align the roof silencer pads with the markings on the roof headlining and install the pads using double-sided tape.

HINT

A bolt without a torque specification is shown in the standard bolt chart (See SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

1. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH Install the front door opening trim weatherstrip as shown in the illustration.
2. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure described for the LH side.
3. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH Install the rear door opening trim weatherstrip as shown in the illustration.
4. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure described for the LH side.
5. PLACE ROOF HEADLINING ASSEMBLY IN VEHICLE Place the roof headlining into the vehicle through the front side. HINT: Place the roof headlining into the vehicle so that the windshield can be installed.
6. INSTALL NO. 1 WINDSHIELD GLASS STOPPER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
7. INSTALL NO. 2 WINDSHIELD GLASS STOPPER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
8. INSTALL UPPER WINDSHIELD OUTSIDE MOLDING (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
9. INSTALL WINDSHIELD GLASS RETAINER (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
10. INSTALL WINDSHIELD GLASS ADHESIVE DAM (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
11. INSTALL WINDSHIELD GLASS SEAL (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
12. INSTALL WINDSHIELD GLASS (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
13. CHECK FOR LEAK AND REPAIR (See «INSTALLATION»(ref-349760-S14401779802009120800000) )
14. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
15. CONNECT RAIN SENSOR CONNECTOR
16. INSTALL RAIN SENSOR COVER (See «INSTALLATION»(ref-349753-S00297998492009120800000) )
17. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING LH Install the center roof drip side finish molding (See «INSTALLATION»(ref-349736-S01712591262009120800000) ).
18. INSTALL CENTER ROOF DRIP SIDE FINISH MOLDING RH HINT: Use the same procedure described for the LH side.
19. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
20. INSTALL COWL TOP VENTILATOR LOUVER PROTECTOR LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
21. INSTALL FRONT FENDER TO COWL SIDE SEAL LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
22. INSTALL FRONT FENDER TO COWL SIDE SEAL RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
23. INSTALL HOOD TO COWL TOP SEAL (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
24. INSTALL FRONT WIPER ARM LH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
25. INSTALL FRONT WIPER ARM RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )
26. INSTALL ROOF HEADLINING ASSEMBLY w/o Sliding Roof: Attach the hook, 12 claws, 3 fasteners and 4 clips to install the roof headlining. w/ Sliding Roof: Attach the hook, 12 claws, 10 fasteners and 4 clips to install the roof headlining. w/ Rear Seat Entertainment System: Attach the hook, 12 claws, 8 fasteners and 4 clips to install the roof headlining. w/ Sliding Roof: Connect the drive gear connector. Connect the roof wire connectors and attach each clamp.
27. INSTALL VISOR HOLDER HINT: Use the same procedure to install the holder on the other side. Attach the 2 claws to install the visor holder. Push in the visor holder and turn it approximately 45° as shown in the illustration.
28. INSTALL VISOR ASSEMBLY LH Install the visor with the 2 screws.
29. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure described for the LH side.
30. INSTALL VISOR BRACKET COVER HINT: Use the same procedure to install the cover on the other side. Attach the 4 claws to install the visor bracket cover.
31. INSTALL ASSIST GRIP SUB-ASSEMBLY HINT: Use the same procedure for all the assist grips. Assemble the assist grip, 2 clips and 2 covers as shown in the illustration. Install the assist grip.
32. INSTALL COAT HOOK (w/o Rear Cooler) HINT: Use the same procedure to install the hook on the other side. Install the coat hook with the screw.
33. INSTALL ROOF SIDE REGISTER BEZEL LH (w/ Rear Cooler) Attach the claw to install the roof side register bezel. Install the screw.
34. INSTALL ROOF SIDE REGISTER BEZEL RH (w/ Rear Cooler) HINT: Use the same procedure described for the LH side.
35. INSTALL REAR VANITY LIGHT ASSEMBLY HINT: Use the same procedure to install the vanity light on the other side. Connect the connector. Attach the claw to install the vanity light. Install the 2 screws. Attach the 4 claws to install the lens.
36. INSTALL SPOT LIGHT ASSEMBLY (w/o Rear Seat Entertainment System) Connect the connector. Attach the 4 claws to install the spot light.
37. INSTALL ROOF CONSOLE BOX ASSEMBLY (w/ Rear Seat Entertainment System) w/o Infrared Rays Sensor: Connect the connector, and then attach the 6 clips and 2 claws to install the roof console box. w/ Infrared Rays Sensor: Connect the 2 connectors, and then attach the 6 clips and 2 claws to install the roof console box. Install the 2 screws.
38. INSTALL SPOT LIGHT LENS (w/ Rear Seat Entertainment System) Attach the 4 claws to install the spot light lens.
39. INSTALL MAP LIGHT ASSEMBLY Connect the 2 map light connectors. Attach the 2 clips to install the map light. Install the 2 screws. Attach the 2 claws to close the 2 covers.
40. INSTALL INNER ROOF SIDE GARNISH LH Install a new clip A to the inner roof side garnish. Attach the 5 clips and 2 claws to install the inner roof side garnish.
41. INSTALL INNER ROOF SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
42. INSTALL REAR SEAT SIDE GARNISH LH Attach the 6 claws to install the rear seat side garnish.
43. INSTALL REAR SEAT SIDE GARNISH RH HINT: Use the same procedure described for the LH side.
44. INSTALL SHOULDER BELT ANCHOR COVER LH Slide the cover in the direction shown in the illustration and attach the 6 claws to install the cover.
45. INSTALL SHOULDER BELT ANCHOR COVER RH HINT: Use the same procedure described for the LH side.
46. INSTALL CENTER UPPER PILLAR GARNISH LH Pass the front seat outer belt floor anchor through the center upper pillar garnish. Attach the claw to install the center upper pillar garnish. Install the 2 screws.
47. INSTALL CENTER UPPER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
48. INSTALL CENTER LOWER PILLAR GARNISH LH Attach the 2 claws and 6 clips to install the center lower pillar garnish.
49. INSTALL CENTER LOWER PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
50. INSTALL REAR DOOR SCUFF PLATE LH Attach the 4 clips. Attach the 7 claws to install the rear door scuff plate.
51. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
52. INSTALL FRONT PILLAR GARNISH LH Install a new clip A to the front pillar garnish. Attach the claw and 2 clips to install the front pillar garnish.
53. INSTALL FRONT PILLAR GARNISH RH HINT: Use the same procedure described for the LH side.
54. INSTALL COWL SIDE TRIM BOARD LH Attach the 3 claws to install the cowl side trim board.
55. INSTALL COWL SIDE TRIM BOARD RH HINT: Use the same procedure described for the LH side.
56. INSTALL FRONT DOOR SCUFF PLATE LH Attach the 4 clips. Attach the 7 claws to install the front door scuff plate.
57. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure described for the LH side.
58. INSTALL FRONT SEAT ASSEMBLY Install the front seat (See «INSTALLATION»(ref-349741-S29651146302009120800000) ).
59. INSTALL REAR SEAT ASSEMBLY (for Fixed Type) Install the rear seat (See «INSTALLATION»(ref-349741-S36437420052009120800000) ).
60. INSTALL REAR SEAT ASSEMBLY (for Power Seat) Install the rear seat (See «INSTALLATION»(ref-349741-S24840229242009120800000) ).
61. INSTALL REAR SEAT ASSEMBLY (for Ottoman) Install the rear seat (See «INSTALLATION»(ref-349741-S09487469022009120800000) ).
62. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected (See «INITIALIZATION»(ref-349706-S07943075812009120800000) ).
63. CHECK SRS WARNING LIGHT Check the SRS warning light (See «DIAGNOSIS SYSTEM»(ref-349738-S23481667942009120800000) ).
64. INSTALL COWL TOP VENTILATOR LOUVER RH (See «INSTALLATION»(ref-349735-S39879645972009120800000) )

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

1. REMOVE INSTRUMENT PANEL FINISH PANEL END LH Using a molding remover, detach the 8 clips and claw. Remove the finish panel.
2. REMOVE INSTRUMENT PANEL FINISH PANEL END RH Using a molding remover, detach the 8 clips and claw. Remove the finish panel.
3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY Twist the shift lever knob in the direction indicated by the arrow and remove it.
4. REMOVE NO. 3 BOX PANEL Using a screwdriver, detach the 4 claws. HINT: Tape the screwdriver tip before use. Remove the box panel.
5. REMOVE REAR CONSOLE PANEL UPPER Place protective tape as shown in the illustration. Move the shift lever to N. Remove the 2 screws. Using a screwdriver, detach the 6 clips. HINT: Tape the screwdriver tip before use. Remove the panel and disconnect the connectors.
6. REMOVE CONSOLE PANEL SUB-ASSEMBLY UPPER Place protective tape as shown in the illustration. Detach the 2 clips. Remove the console panel and disconnect the connector.
7. REMOVE REAR CONSOLE END PANEL SUB-ASSEMBLY Using a molding remover, detach the 5 clips and 2 claws. Remove the end panel and disconnect the connector.
8. REMOVE CONSOLE COVER LOWER Remove the cover.
9. REMOVE CONSOLE BOX ASSEMBLY Remove the 4 bolts and 2 screws. Disconnect the connectors. Detach the 2 claws and remove the console box.

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

1. REMOVE CONSOLE BOX POCKET LOWER Detach the 8 claws and remove the box pocket.
2. REMOVE CONSOLE COMPARTMENT DOOR SUB-ASSEMBLY Using a screwdriver, detach the 2 claws. HINT: Tape the screwdriver tip before use. Using a screwdriver, detach the 2 dampers. HINT: Tape the screwdriver tip before use. Remove the 4 screws and compartment door.
3. REMOVE CONSOLE COMPARTMENT DOOR HINGE SUB-ASSEMBLY Slide the door hinge and remove the 2 screws. Remove the 2 screws and door hinge.
4. REMOVE CONSOLE COMPARTMENT DOOR LOCK SUB-ASSEMBLY Place protective tape as shown in the illustration. Using a screwdriver, detach the 2 clips. HINT: Tape the screwdriver tip before use. Detach the 2 claws and remove the door lock.

Scheme 168

Scheme 169

Scheme 170

1. INSTALL CONSOLE COMPARTMENT DOOR LOCK SUB-ASSEMBLY Attach the 2 clips and 2 claws to install the door lock.
2. INSTALL CONSOLE COMPARTMENT DOOR HINGE SUB-ASSEMBLY Install the 2 screws. Slide and install the door hinge with the 2 screws.
3. INSTALL CONSOLE COMPARTMENT DOOR SUB-ASSEMBLY Install the 4 screws. Attach the 2 dampers. Attach the 2 claws to install the compartment door.
4. INSTALL CONSOLE BOX POCKET LOWER Attach the 8 claws to install the box pocket.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see REMOVAL ).

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

1. INSTALL CONSOLE BOX ASSEMBLY Attach the 2 claws. Connect the connectors. Install the console box with the 4 bolts and 2 screws.
2. INSTALL CONSOLE COVER LOWER Install the cover.
3. INSTALL REAR CONSOLE END PANEL SUB-ASSEMBLY Connect the connector. Attach the 5 clips and 2 claws to install the end panel.
4. INSTALL CONSOLE PANEL SUB-ASSEMBLY UPPER Connect the connector. Attach the 2 clips to install the console panel.
5. INSTALL REAR CONSOLE PANEL UPPER Connect the connectors. Attach the 6 clips. Install the panel with the 2 screws.
6. INSTALL NO. 3 BOX PANEL Attach the 4 claws to install the box panel.
7. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY Install the shift lever knob and twist it in the direction indicated by the arrow.
8. INSTALL INSTRUMENT PANEL FINISH PANEL END RH Attach the 8 clips and claw to install the finish panel.
9. INSTALL INSTRUMENT PANEL FINISH PANEL END LH Attach the 8 clips and claw to install the finish panel.

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

1. REMOVE REAR SEAT CONSOLE BOX ASSEMBLY Using a screwdriver, detach the 4 clips and remove the rear seat console box front panel. HINT: Tape the screwdriver tip before use. Using a screwdriver, detach the 4 claws, then detach the 2 hooks and remove the rear seat console box lower cover. HINT: Tape the screwdriver tip before use. Remove the 6 bolts, and move the console box in the direction of the arrow shown in the illustration. Then detach the 2 clips, and remove the console box. Disconnect the connector.
2. REMOVE REAR SEAT CONSOLE ARMREST GARNISH LH Open the console door. While pulling up the armrest garnish, detach the 3 claws and 2 clips to remove it.
3. REMOVE REAR SEAT CONSOLE ARMREST GARNISH RH HINT: Use the same procedures described for the LH side.
4. REMOVE REAR SEAT CONSOLE PANEL ASSEMBLY Using a screwdriver, detach the 6 clips and remove the console panel. HINT: Tape the screwdriver tip before use. Disconnect the connector.
5. REMOVE REAR SEAT CONSOLE TABLE COVER FRONT Using a screwdriver, detach the 2 claws. HINT: Tape the screwdriver tip before use. Pull up the table cover and detach the 2 hooks to remove it.
6. REMOVE REAR SEAT CONSOLE TABLE ASSEMBLY Remove the 2 bolts, 2 nuts and console table.
7. REMOVE VOLTAGE INVERTER ASSEMBLY (See «REMOVAL»(ref-349755-S00415573172009120800000) )
8. REMOVE REAR SEAT CONSOLE ARMREST ASSEMBLY Take out the console armrest cover. Remove the 8 nuts and 2 bolts. Remove the 2 screws and console armrest. Disconnect the connector.

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

1. REMOVE REAR SEAT CONSOLE BOX Using a screwdriver, detach the 4 clips and remove the rear seat console box rear panel. HINT: Tape the screwdriver tip before use. Disconnect the 2 connectors and remove the 2 wire harness clamps. w/ Disc Player: Disconnect the 2 connectors. Remove the 4 bolts and console box. w/ Disc Player: Remove the 4 bolts and 2 brackets.
2. REMOVE TELEVISION SWITCH AND VOLUME ASSEMBLY
3. REMOVE REAR SEAT CONSOLE ARMREST BASE Remove the cover and 2 seals. Remove the 8 screws and inner tray. Using a screwdriver, detach the 10 claws and remove the console armrest base. NOTE: Detach the claws of the console armrest base from the backside. Disconnect the 3 connectors. w/ Cigarette Lighter: Disconnect the 4 connectors.
4. REMOVE SEAT VIBRATOR SWITCH Remove the clamp and seat vibrator switch.
5. REMOVE POWER OUTLET SOCKET (See «REMOVAL»(ref-349755-S19959609752009120800000) )
6. REMOVE POWER OUTLET SOCKET COVER (See «REMOVAL»(ref-349755-S19959609752009120800000) )
7. REMOVE CIGARETTE LIGHTER COVER (w/ Cigarette Lighter) (See «REMOVAL»(ref-349755-S19959609752009120800000) )
8. REMOVE CIGARETTE LIGHTER ASSEMBLY (w/ Cigarette Lighter) (See «REMOVAL»(ref-349755-S19959609752009120800000) )
9. REMOVE CIGARETTE LIGHTER BEZEL STAY (w/ Cigarette Lighter) (See «REMOVAL»(ref-349755-S19959609752009120800000) )
10. REMOVE REAR CONSOLE BOX WIRE Detach the 3 clamps and remove the rear console wire.

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

1. INSTALL REAR SEAT CONSOLE ARMREST ASSEMBLY Connect the connector. Install the console armrest with the 2 screws. Install the 8 nuts and 2 bolts. Install the console armrest cover.
2. INSTALL VOLTAGE INVERTER ASSEMBLY (See «INSTALLATION»(ref-349755-S34636152322009120800000) )
3. INSTALL REAR SEAT CONSOLE TABLE ASSEMBLY Install the console table with the 2 nuts and 2 bolts.
4. INSTALL REAR SEAT CONSOLE TABLE COVER FRONT Push down the table cover and attach the 2 hooks. Attach the 2 claws to install the table cover.
5. INSTALL REAR SEAT CONSOLE PANEL ASSEMBLY Connect the connector. Attach the 6 clips to install the console panel.
6. INSTALL REAR SEAT CONSOLE ARMREST GARNISH RH While lowering the armrest garnish, attach the 3 claws and 2 clips to install it.
7. INSTALL REAR SEAT CONSOLE ARMREST GARNISH LH HINT: Use the same procedures described for the RH side.
8. INSTALL REAR SEAT CONSOLE BOX ASSEMBLY Connect the connector. Move the console box in the direction of the arrow shown in the illustration, and attach the 2 clips. Then install the console box with the 6 bolts. Attach the 2 hooks and install the rear seat console box lower cover to the console box. Attach the 4 claws. Attach the 4 clips to install the rear seat console box front panel.
