Interior: Overhaul Lexus LS IV

Exterior/interior Trim 3 illustrations ~205 words

REASSEMBLY

HINT

A bolt without a torque specification is shown in the standard bolt chart (see SPECIFIED TORQUE FOR STANDARD BOLTS ).

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204

Scheme 205

Scheme 205
Scheme 205
  1. INSTALL REAR CONSOLE BOX WIRE Attach the 3 clamps to install the console box wire.
  2. INSTALL CIGARETTE LIGHTER BEZEL STAY (w/ Cigarette Lighter) (See «INSTALLATION»(ref-349755-S18729245482009120800000) )
  3. INSTALL CIGARETTE LIGHTER ASSEMBLY (w/ Cigarette Lighter) (See «INSTALLATION»(ref-349755-S18729245482009120800000) )
  4. INSTALL CIGARETTE LIGHTER COVER (w/ Cigarette Lighter) (See «INSTALLATION»(ref-349755-S18729245482009120800000) )
  5. INSTALL POWER OUTLET SOCKET COVER (See «INSTALLATION»(ref-349755-S18729245482009120800000) )
  6. INSTALL POWER OUTLET SOCKET (See «INSTALLATION»(ref-349755-S18729245482009120800000) )
  7. INSTALL SEAT VIBRATOR SWITCH Install the seat vibrator switch and clamp.
  8. INSTALL REAR SEAT CONSOLE ARMREST BASE Connect the 3 connectors. w/ Cigarette Lighter: Connect the 4 connectors. Attach the 10 claws to install the console armrest base. Install the inner tray with the 8 screws. Install a new cover and 2 seals.
  9. INSTALL TELEVISION SWITCH AND VOLUME ASSEMBLY
  10. INSTALL REAR SEAT CONSOLE BOX w/ Disc Player: Install the 2 brackets with the 4 bolts. Install the console box with the 4 bolts. Install the 2 wire harness clamps and connect the 2 connectors. w/ Disc Player: Connect the 2 connectors. Attach the 4 clips to install the rear seat console box rear panel.
