Interior: Overview Lexus LS IV

SYSTEM DESCRIPTION

1. GENERAL By operating the rear sunshade switch for the front or rear seats, the rear sunshade rises to cover the back window glass and helps block sunlight for the rear passengers.
2. REAR SUNSHADE SYSTEM DESCRIPTION By operating the switch, the rear sunshade rises and lowers. When the shift lever is on R, the park/neutral position switch sends a reverse-linked signal to the rear sunshade, and the rear sunshade lowers. The visibility to the rear of the vehicle improves without any switch operation. When the shift lever is moved to P or the vehicle speed is 15 km/h (9 mph) or more, the rear sunshade is raised. When the engine switch is turned off while the rear sunshade is rising or lowering, the operation continues until the rear sunshade has fully risen or fully lowered, respectively. After the engine switch is turned from on (IG) to off, the rear sunshade can be operated for approximately 60 seconds.

OPERATION CHECK

1. CHECK MANUAL OPERATION By operating the switch, check that the rear sunshade rises and lowers.
2. CHECK REVERSE LINKED OPERATION If the shift lever is moved to R while the rear sunshade is rising, check that the rear sunshade automatically lowers. When the shift lever is moved to P or the vehicle is driven at 15 km/h (9 mph) or more, check that the rear sunshade rises again.
3. CHECK KEY OFF SWITCH OPERATION When the engine switch is turned off while the rear sunshade is rising or lowering, check that the operation continues until the rear sunshade has fully risen or fully lowered, respectively. After the engine switch is turned from on (IG) to off, check that the rear sunshade can be operated for approximately 60 seconds.

DESCRIPTION

DTC DETECTION CONDITION CHART

A rear sunshade switch signal is sent from the No. 2 console switch (Integration control & panel) to the No. 1 console switch (combination switch). Then the signal is sent through LIN communication to the outer mirror switch, which then sends the signal through CAN communication to the rear junction block ECU, and the rear sunshade operates.

Scheme 1

Scheme 2

1. CHECK DTC OUTPUT Clear the DTCs (see «DATA LIST/ACTIVE TEST» ). Check for DTCs (see «DATA LIST/ACTIVE TEST» ). Result RESULT REFERENCE Result Proceed to No DTC is output A DTC U1114 is output B DTC U1127 is output C B: GO TO CAN COMMUNICATION SYSTEM (See «DTC U1114 LOST COMMUNICATION WITH MAIN SWITCH MODULE»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) C: GO TO LIN COMMUNICATION SYSTEM (See «DTC U1127 LOST COMMUNICATION WITH CENTER CONSOLE SWITCH ECU» ) A: Go to next step
2. READ VALUE USING TECHSTREAM (REAR SUNSHADE SWITCH) Use the Data List to check if the rear sunshade switch is functioning properly. Center Console Switch ITEM/RANGE REFERENCE Tester Display Measurement Item/Range (Display) Normal Condition Diagnostic Note Rear Shade Switch Rear sunshade switch/ON or OFF ON: Rear sunshade switch is pressed OFF: Rear sunshade switch is not pressed - OK: Rear sunshade raises or lowers. NG: Go to step 3 OK: REPLACE NO. 1 CONSOLE SWITCH (See «REMOVAL» )
3. INSPECT NO. 2 CONSOLE SWITCH Disconnect the No. 2 console switch connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Switch Condition Specified Condition 8-12 Rear sunshade switch is pushed Below 200 ohms 8-12 Rear sunshade switch is not pushed 10 kohms or higher NG: REPLACE NO. 2 CONSOLE SWITCH (See «REMOVAL» ) OK: REPLACE NO. 1 CONSOLE SWITCH (See «REMOVAL» )

A rear sunshade signal is sent from the rear power seat module switch to the rear junction block ECU through CAN communication, and the rear sunshade operates.

Scheme 3

Scheme 4

1. CHECK DTC OUTPUT Clear the DTCs (see «DATA LIST/ACTIVE TEST» ). Check for DTCs (see «DATA LIST/ACTIVE TEST» ). Result RESULT REFERENCE Result Proceed to No DTC is output A DTC U0210 is output B B: GO TO CAN COMMUNICATION SYSTEM (See «DTC U0210 LOST COMMUNICATION WITH "SEAT CONTROL MODULE C"»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) A: Go to next step
2. CHECK SYSTEM Check if the vehicle is equipped with the Ottoman. Result RESULT REFERENCE Result Proceed to w/o Ottoman A w/ Ottoman B B: Go to step 6 A: Go to next step
3. READ VALUE USING TECHSTREAM (REAR SUNSHADE SWITCH) Use the Data List to check if the rear sunshade switch is functioning properly. Rear Console Switch ITEM/RANGE REFERENCE Tester Display Measurement Item/Range (Display) Normal Condition Diagnostic Note Rear Shade Switch Rear sunshade switch/ON or OFF ON: Rear sunshade switch is pressed OFF: Rear sunshade switch is not pressed - OK: Rear sunshade raises or lowers. NG: Go to step 4 OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )
4. CHECK HARNESS AND CONNECTOR (CURTAIN SWITCH - REAR POWER SEAT MODULE SWITCH) Disconnect the r3 curtain switch connector. Disconnect the r1 power seat module switch connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition r3-8 (SW1) - r1-20 (SW1) Always Below 1 ohms r3-15 (GND) - r1-5 (GND) Always Below 1 ohms r3-8 (SW1) - Body ground Always 10 kohms or higher r3-15 (GND) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK CURTAIN SWITCH (OPERATION) Temporarily replace the curtain switch with a new or normally functioning one (see «DISASSEMBLY»(/lexus/ls/iv-2006-2012/remont/seats/#seat) ). Check that the rear sunshade can be raised and lowered by using the curtain switch. OK: Rear sunshade can be raised and lowered with curtain switch Result RESULT REFERENCE Result Proceed to OK A NG (for Fixed Seat Type) B NG (for Power Seat) C B: REPLACE REAR POWER SEAT MODULE SWITCH (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) C: REPLACE REAR POWER SEAT MODULE SWITCH (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) A: END (CURTAIN SWITCH IS DEFECTIVE)
6. READ VALUE USING TECHSTREAM (REAR SUNSHADE SWITCH) Use the Data List to check if the rear sunshade switch is functioning properly. Rear Console Switch ITEM/RANGE REFERENCE Tester Display Measurement Item/Range (Display) Normal Condition Diagnostic Note Rear Shade Switch Rear sunshade switch/ON or OFF ON: Rear sunshade switch is pressed OFF: Rear sunshade switch is not pressed - OK: Rear sunshade raises or lowers. NG: REPLACE REAR POWER SEAT MODULE SWITCH (See «AUDIO AND REAR AIR CONDITIONER CONTROL SWITCH (FOR OTTOMAN)»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )

A rear sunshade switch signal is sent from the front switch (No. 2 console switch) to the outer mirror switch through LIN communication. The outer mirror then sends the signal to the rear junction block ECU through CAN communication, and the rear sunshade operates. For the rear switch (curtain switch), a rear sunshade signal is sent from the rear power seat module switch to the rear junction block ECU, and the rear sunshade operates.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. CHECK DTC OUTPUT Clear the DTCs (see «DATA LIST/ACTIVE TEST» ). Check for DTCs (see «DATA LIST/ACTIVE TEST» ). Result RESULT REFERENCE Result Proceed to No DTC is output A DTC U0141, U0210, U1114 is output B DTC U1127 is output C B: GO TO CAN COMMUNICATION SYSTEM (See «DIAGNOSTIC TROUBLE CODE CHART»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) C: GO TO LIN COMMUNICATION SYSTEM (See «DTC U1127 LOST COMMUNICATION WITH CENTER CONSOLE SWITCH ECU» ) A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM Select the Active Test, use the Techstream to generate a control command, and then check that the shade raises/ lowers. Body No. 4 CONTROL RANGE REFERENCE Tester Display Test Part Control Range Diagnostic Note Rear Sunshade Operation Rear Sunshade Operation Down, No or Up - OK: Rear sunshade raises or lowers NG: Go to step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (STATUS OF REAR SUNSHADE CLOSE) Use the Data List to check if the rear sunshade limit switch is functioning properly. Body No. 4 ITEM/RANGE REFERENCE Tester Display Measurement Item/Range Normal Condition Diagnostic Note Rear Sunshade Close Status of the rear sunshade close/YES or NO YES: Rear sunshade limit switch is OFF (Rear sunshade is lowered) NO: Rear sunshade limit switch is ON (Rear sunshade is raised) - OK: Rear sunshade raises or lowers OK: Go to step 5 NG: Go to next step
4. CHECK HARNESS AND CONNECTOR (REAR SUNSHADE ASSEMBLY - REAR JUNCTION BLOCK AND BODY GROUND) Disconnect the S25 shade connector. Disconnect the S61 ECU connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition S25-3 (RSL) - S61-22 (LMT) Always Below 1 ohms S25-3 (RSL) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE REAR SUNSHADE ASSEMBLY (See «REMOVAL» )
5. INSPECT FUSE (RR S/SHADE) Remove the RR S/SHADE fuse from luggage room junction block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition RR S/SHADE fuse Always Below 1 ohms NG: REPLACE FUSE OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (LUGGAGE ROOM JUNCTION BLOCK - BODY GROUND) Disconnect the LG junction block connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition LG-1 - Body ground Always 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (REAR SUNSHADE ASSEMBLY - REAR JUNCTION BLOCK AND BODY GROUND) Disconnect the S25 shade connector. Disconnect the S61 ECU connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition S25-2 (RSMU) - S61-4 (MU) Always Below 1 ohms S25-1 (RSMD) - S61-3 (MD) Always Below 1 ohms S25-4 (RSE) - Body ground Always Below 1 ohms S25-2 (RSMU) - Body ground Always 10 kohms or higher S25-1 (RSMD) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
8. INSPECT REAR SUNSHADE ASSEMBLY Remove the rear sunshade assembly (see «REMOVAL» ). Apply battery voltage and check the operation of the window shade motor. Standard STANDARD SPECIFICATION Measurement Condition Specified Condition Battery positive (+) --> 1 (RSMD) Battery negative (-) --> 4 (RSE) Sunshade lowers Battery positive (+) --> 2 (RSMU) Battery negative (-) --> 4 (RSE) Sunshade raises NG: REPLACE REAR SUNSHADE ASSEMBLY (See «REMOVAL» ) OK: REPLACE LUGGAGE ROOM JUNCTION BLOCK ASSEMBLY (REAR JUNCTION BLOCK ECU)

1. GENERAL By operating the rear door sunshade switch for the front or rear seats, the rear curtain rises to cover the window glass and helps block sunlight for the rear passengers.
2. REAR DOOR SUNSHADE SYSTEM DESCRIPTION By operating the switch, check that the rear curtain rises and lowers. After the engine switch is turned from on (IG) or start to off, check that the rear curtain can be operated for approximately 60 seconds. After the rear curtain is fully raised or while the rear curtain is being raised, if the window is moved out of the fully closed position, the sunshade automatically lowers.
3. JAM PROTECTION FUNCTION The jam protection function detaches the rear curtain if a foreign object gets jammed in the rear curtain during the raising operation.

HINT

Before performing the inspection, make sure the power window control system is operating normally.

1. CHECK MANUAL OPERATION By operating the switch, check that the rear curtain rises and lowers. When the rear curtain on both sides or one side is fully raised and the No. 2 console switch's rear door sunshade switch is pressed, check that the rear curtains lower. When the switch is pressed again, check that the rear curtains rise.
2. CHECK KEY OFF SWITCH OPERATION When the read door sunshade is operating and the engine switch is turned from on to off, check that the operation continues. After the engine switch is turned from on (IG) or start to off, check that the rear curtain can be operated for approximately 60 seconds.
3. CHECK WINDOW OPERATION LINKED FUNCTION After the rear curtain is fully raised or while the rear curtain is being raised, if the window is moved out of the fully closed position, check that the sunshade automatically lowers.
4. CHECK JAM PROTECTION FUNCTION (MECHANICAL DETACHMENT FUNCTION) CAUTION: Do not use a part of your body, for example, your hand, to check the jam protection. Do not allow anything to become caught in the rear curtain by accident in this procedure. Perform the inspection from the inside of the vehicle. NOTE: Do not use hard objects such as a hammer, to avoid damage to the rear curtain. When the rear curtain close operation is operating and an object is caught between the vehicle body and rear curtain, check that the rear curtain detaches. After the rear curtain detaches, the position reset operation must be performed (see «INITIALIZATION» ).

The ECU receives signals from the switch modules and ECUs via the CAN communication system.

DTC DETECTION CONDITION CHART

A rear door sunshade switch signal is sent from the No. 2 console switch to the outer mirror switch assembly through LIN communication. The outer mirror switch then sends the signal to the rear door ECUs through CAN communication, and the rear curtains operate.

Scheme 10

A rear door sunshade switch signal is sent from the rear power seat module switch to the rear door ECUs through CAN communication, and the rear curtains operate.

Scheme 11

Scheme 12

1. CHECK DTC Clear the DTC (see «DTC CHECK/CLEAR» ). Check for DTC (see «DTC CHECK/CLEAR» ). Result RESULT REFERENCE Result Proceed to No DTCs are output A U0210 is output B B: GO TO CAN COMMUNICATION SYSTEM (See «DTC U0210 LOST COMMUNICATION WITH "SEAT CONTROL MODULE C"»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) A: Go to next step
2. CHECK SYSTEM Check if the vehicle is equipped with the Ottoman. Result RESULT REFERENCE Result Proceed to w/o Ottoman A w/ Ottoman B B: Go to step 6 A: Go to next step
3. READ VALUE USING TECHSTREAM (REAR DOOR SUNSHADE SWITCH) Select the item below in the Data List, and read its value displayed on the Techstream to check the rear door sunshade switch. Rear Console Switch ITEM/RANGE REFERENCE Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Shade Switch Rear left door sunshade switch/ON or OFF ON: Rear door sunshade switch is pressed OFF: Rear door sunshade switch is not pressed - RR Shade Switch Rear right door sunshade switch/ON or OFF ON: Rear door sunshade switch is pressed OFF: Rear door sunshade switch is not pressed - OK: Rear curtain is operated normally. NG: Go to step 4 OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )
4. CHECK HARNESS AND CONNECTOR (CURTAIN SWITCH - REAR POWER SEAT MODULE SWITCH) Disconnect the r3 curtain switch connector. Disconnect the r1 power seat module switch connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition r3-18 (SW2) - r1-7 (SW2) Always Below 1 ohms r3-13 (SW3) - r1-3 (SW3) Always Below 1 ohms r3-4 (SWE2) - r1-16 (SWE2) Always Below 1 ohms r3-18 (SW2) - Body ground Always 10 kohms or higher r3-13 (SW3) - Body ground Always 10 kohms or higher r3-4 (SWE2) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. CHECK CURTAIN SWITCH ASSEMBLY (OPERATION) Temporarily replace the curtain switch with a new or normally functioning one (see «DISASSEMBLY»(/lexus/ls/iv-2006-2012/remont/seats/#seat) ). Check that the curtain can be raised or lowered by using the curtain switch. OK: Curtain can be raised or lowered with curtain switch. Result RESULT REFERENCE Result Proceed to OK A NG (for Fixed Seat Type) B NG (for Power Seat) C B: REPLACE REAR POWER SEAT MODULE SWITCH (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) C: REPLACE REAR POWER SEAT MODULE SWITCH (See «REMOVAL»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) A: END (CURTAIN SWITCH IS DEFECTIVE)
6. READ VALUE USING TECHSTREAM (REAR DOOR SUNSHADE SWITCH) Select the item below in the Data List, and read its value displayed on the Techstream to check the rear door sunshade switch. Rear Console Switch ITEM/RANGE REFERENCE Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Shade Switch Rear left door sunshade switch/ON or OFF ON: Rear door sunshade switch is pressed OFF: Rear door sunshade switch is not pressed - RR Shade Switch Rear right door sunshade switch/ON or OFF ON: Rear door sunshade switch is pressed OFF: Rear door sunshade switch is not pressed - OK: Rear curtain is operated normally. NG: REPLACE REAR POWER SEAT MODULE SWITCH (See «AUDIO AND REAR AIR CONDITIONER CONTROL SWITCH (FOR OTTOMAN)»(/lexus/ls/iv-2006-2012/remont/entertainment-systems/#audiovisual) ) OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )

The rear door ECU operates the motor of the rear curtain (rear door sunshade).

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. CHECK DTC Clear the DTC (see «DTC CHECK/CLEAR» ). Check for DTC (see «DTC CHECK/CLEAR» ). Result RESULT REFERENCE Result Proceed to No DTCs are output A U0202 is output B B: GO TO CAN COMMUNICATION SYSTEM (See «DTC U0202 LOST COMMUNICATION WITH "DOOR CONTROL MODULE D"»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR SUNSHADE OPERATION) Select the Active Test, use the Techstream to generate a control command, and then check that the rear door sunshade operates. Rear Left Door CONTROL RANGE REFERENCE Tester Display Test Part Control Range Diagnostic Note Rear Door Sunshade Up Rear curtain Up or Stop - Rear Door Sunshade Down Rear curtain Down or Stop - OK: Rear curtain is operated normally. NG: Go to step 3 OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )
3. CHECK HARNESS AND CONNECTOR (REAR CURTAIN LH - REAR DOOR ECU LH) Disconnect the O15 ECU connector. Disconnect the O16 curtain connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition O16-1 (SSA-) - O15-10 (SSA-) Always Below 1 ohms O16-2 (SSA+) - O15-1 (SSA+) Always Below 1 ohms O16-3 (SHSE) - O15-30 (SHSE) Always Below 1 ohms O16-4 (SHSB) - O15-8 (SHSB) Always Below 1 ohms O16-5 (SHS2) - O15-28 (SHS2) Always Below 1 ohms O16-6 (SHS1) - O15-27 (SHS1) Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT REAR CURTAIN LH Remove the rear curtain LH (see «REMOVAL» ). Apply battery voltage and check the operation of the rear curtain LH. Standard STANDARD SPECIFICATION Measurement Condition Specified Condition Battery positive (+) --> 2 (SSA+) Battery negative (-) --> 1 (SSA-) Raises curtain Battery positive (+) --> 1 (SSA-) Battery negative (-) --> 2 (SSA+) Lowers curtain Reconnect the rear curtain connector. Measure the waveform according to the value(s) in the table below. Waveform (Reference) WAVEFORM REFERENCE Item Content Terminal No. (Symbols) O16-5 (SHS2) - O16-3 (SHSE) O16-6 (SHS1) - O16-3 (SHSE) Tool Setting 2 V/DIV., 1 msec/DIV. Condition Engine switch on (IG), rear door sunshade switch is pressed NG: REPLACE REAR CURTAIN LH (See «REMOVAL» ) OK: REPLACE REAR DOOR ECU LH (See «REMOVAL» )

The rear door ECU operates the motor of the rear curtain (rear door sunshade).

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. CHECK DTC Clear the DTC (see «DTC CHECK/CLEAR» ). Check for DTC (see «DTC CHECK/CLEAR» ). Result RESULT REFERENCE Result Proceed to No DTCs are output A U0201 is output B B: GO TO CAN COMMUNICATION SYSTEM (See «DTC U0201 LOST COMMUNICATION WITH "DOOR CONTROL MODULE C"»(/lexus/ls/iv-2006-2012/remont/communication-devices/#can-communication) ) A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (DOOR SUNSHADE OPERATION) Select the Active Test, use the Techstream to generate a control command, and then check that the rear door sunshade operates. Rear Right Door CONTROL RANGE REFERENCE Tester Display Test Part Control Range Diagnostic Note Rear Door Sunshade Up Rear curtain Up or Stop - Rear Door Sunshade Down Rear curtain Down or Stop - NG: Go to step 3 OK: USE SIMULATION METHOD TO CHECK (See «HOW TO PROCEED WITH TROUBLESHOOTING» )
3. CHECK HARNESS AND CONNECTOR (REAR CURTAIN RH - REAR DOOR ECU RH) Disconnect the O2 ECU connector. Disconnect the O5 curtain connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE REFERENCE Tester Connection Condition Specified Condition O5-1 (SSA-) - O2-10 (SSA-) Always Below 1 ohms O5-2 (SSA+) - O2-1 (SSA+) Always Below 1 ohms O5-3 (SHSE) - O2-30 (SHSE) Always Below 1 ohms O5-4 (SHSB) - O2-8 (SHSB) Always Below 1 ohms O5-5 (SHS2) - O2-28 (SHS2) Always Below 1 ohms O5-6 (SHS1) - O2-27 (SHS1) Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT REAR CURTAIN RH Remove the rear curtain RH (see «REMOVAL» ). Apply battery voltage and check the operation of the rear curtain RH. Standard STANDARD SPECIFICATION Measurement Condition Specified Condition Battery positive (+) --> 2 (SSA+) Battery negative (-) --> 1 (SSA-) Raises curtain Battery positive (+) --> 1 (SSA-) Battery negative (-) --> 2 (SSA+) Lowers curtain Reconnect the rear curtain connector. Measure the waveform according to the value(s) in the table below. Measurement Condition ITEM SPECIFICATION Item Content Terminal No. (Symbols) O5-5 (SHS2) - O5-3 (SHSE) O5-6 (SHS1) - O5-3 (SHSE) Tool Setting 2 V/DIV., 1 msec/DIV. Condition Engine switch on (IG), rear door sunshade switch is pressed NG: REPLACE REAR CURTAIN RH (See «REMOVAL» ) OK: REPLACE REAR DOOR ECU RH (See «REMOVAL» )

Scheme 21

Scheme 22
