PRECAUTION
- NOTICE FOR INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM REFERENCE System Name See procedure Navigation System (for DVD) «INITIALIZATION»(ref-349706-S07943075812009120800000) Advanced Parking Guidance System Power Trunk Lid System Rear Door Sunshade System
Scheme 206
Scheme 207
Scheme 208
Scheme 209
Communication table
| Sender | Receiver | Signal | Line |
|---|---|---|---|
| ECM | Main body ECU | Shift position switch signal | CAN |
| Main body ECU | Rear junction block ECU | Reverse position signal | CAN |
| Combination meter | Rear junction block ECU | Vehicle speed signal | CAN |
| No. 1 console switch | Rear junction block ECU | Rear sunshade switch signal | LIN - CAN |
| Curtain switch*1 | Rear junction block ECU | Rear sunshade switch signal | CAN |
| Rear power seat module switch*2 | Rear junction block ECU | Rear sunshade switch signal | CAN |
COMMUNICATION REFERENCE
CUSTOMIZE PARAMETERS
- CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Select the setting by referring to the table below. Others SYSTEM REFERENCE System Default Contents Setting Rear Shade Delay Time 0.7 s Function to adjust reverse-linked sunshade lowering function's response time 0.7s/1.2s/0.9s/0.0s R-pos to Rear Sun Shade COM ON Reverse linked function ON or OFF
- NOTICE FOR INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM REFERENCE System Name See procedure Navigation System (for DVD) «INITIALIZATION»(ref-349706-S07943075812009120800000) Advanced Parking Guidance System Power Trunk Lid System Rear Door Sunshade System
- PRECAUTIONS WHEN USING TECHSTREAM When using the Techstream with the engine switch off to troubleshoot: Connect the Techstream to the vehicle, and turn a courtesy light switch on and off at 1.5 second intervals until communication between the tester and vehicle begins. After all DTCs are cleared, check if the trouble occurs again 6 seconds after the engine switch is turned on (IG).
Scheme 210
Scheme 211
Scheme 212
Communication Table
| Sender | Receiver | Signal | Line |
|---|---|---|---|
| Combination switch (Rear door sunshade switch) | Rear door ECU LH | Rear door sunshade switch signal | LIN - CAN |
| Combination switch (Rear door sunshade switch) | Rear door ECU RH | Rear door sunshade switch signal | LIN - CAN |
| Rear power seat module switch (Rear door sunshade switch) | Rear door ECU LH | Rear door sunshade switch signal | CAN |
| Rear power seat module switch (Rear door sunshade switch) | Rear door ECU RH | Rear door sunshade switch signal | CAN |
| Rear power window regulator motor LH | Rear door ECU LH | Window position signal | LIN - CAN |
| Rear power window regulator motor RH | Rear door ECU RH | Window position signal | LIN - CAN |
| Rear door ECU LH | No. 1 Console Switch | Door sunshade open/close status signal | CAN - LIN |
| Rear door ECU RH | No. 1 Console Switch | Door sunshade open/close status signal | CAN - LIN |
COMMUNICATION REFERENCE
INITIALIZATION
- RESET REAR DOOR SUNSHADE SYSTEM NOTE: The rear curtain position reset operation must be performed when one of the following occurs: 1) battery removal and installation; 2) ECU reset; or 3) jam protection related detachment. Turn the engine switch on. Push the front or rear switch's rear door sunshade switch. HINT: The motor must be moved in the lowering direction. Push the front or rear switch's rear door sunshade switch. HINT: Make sure that the rear curtain raises.
- RESET REAR DOOR SUNSHADE POSITION AFTER DETACHMENT NOTE: If the curtain is operating and detaches as a result of the jam protection function, the motor must be operated in the raise direction in order to return it to normal. If the motor is not returned to normal, the cover may not close properly during the lowering operation. After the rear curtain stops at the fully raised position, continue holding the switch for 5 seconds. Stopped --> Raising --> Stopped at fully raised position --> 5 sec.
