Audio / Video System (Diagnostics - Introduction): Other Lexus IS III

PRECAUTION [04/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: After the engine switch is turned off, the radio receiver assembly records various types of memory and settings. As a result, after turning the engine switch off, make sure to wait at least 90 seconds before disconnecting the cable from the negative (-) battery terminal. When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the terminal is reconnected. System Name See Procedure Air Conditioning System Refer to «INITIALIZATION [04/2013 - ]»(ref-665529-S01115916402014102400000) Variable Gear Ratio Steering System

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

1. DISC PLAYER OUTLINE A disc player uses a laser pickup to read digital signals recorded on a disc. By converting the digital signals to analog, it can play music, video and audio. WARNING: Do not look directly at the laser pickup because the disc player uses an invisible laser beam. Be sure to operate the player only as instructed. NOTE: Do not disassemble any part of the disc player. Do not apply oil to the disc player. Do not insert anything but a disc into the disc player. This player can play only audio CDs, CD-Rs (CD-Recordable) and CD-RWs (CD-ReWritable) that have any of the following marks: The following products may not be playable on your player. SACD dts CD Copy-protected CD Precautions for use of discs NOTE: CD-Rs, CD-RWs may not be played depending on the recording conditions or characteristics of the discs, or due to damage, dirt or deterioration caused by leaving the discs in the cabin for a long time. Unfinalized CD-Rs, CD-RWs cannot be played. CD-Rs, CD-RWs are more easily affected by a hot and humid environment than discs used for normal audio CDs. For this reason, some CD-Rs and CD-RWs may not play. If there are fingerprints or scratches on a disc, the disc may not play or the disc may skip. Some CD-Rs, CD-RWs may deteriorate if they are left in the cabin for a long time. Keep CD-Rs, CD-RWs in an opaque case. DualDiscs that mate DVD recorded material on one side with CD digital audio material on the other cannot be played. Keep discs away from dirt. Be careful not to damage the discs or leave fingerprints on them. Hold discs by the outer edge and center hole with the label side up. Leaving a disc exposed halfway out of the slot for a long time after pressing the disc eject button may cause deformation of the disc, making the disc unusable. If discs have adhesive tape, stickers, disc labels or any traces of such labels attached, the discs may not be ejected or player malfunctions may result. Keep discs away from direct sunlight. (Exposure to direct sunlight may cause deformation of the disc, making the disc unusable.) Do not use odd-shaped discs because these may cause player malfunctions. Do not use discs whose recording portion is transparent or translucent because they may not be inserted, ejected or played normally. Use only 4.7 in. (12 cm) discs. Do not use 3 in. (8 cm) discs either with or without adaptors. HINT: When it is cold or raining, if the windows fog up, mist and condensation may form in the player. In such cases, the disc may skip or stop in the middle of play. Ventilate or dehumidify the cabin for a while before using the player. The disc may skip if the player experiences strong vibrations when the vehicle is driven on rough roads or similar uneven surfaces. Cleaning NOTE: Do not use a lens cleaner because it may cause a malfunction in the pickup portion of the player. If dirt is on the disc surface, wipe it clean with a soft dry cloth such as an eyeglass cleaner for plastic lenses from the inside to the outside in a radial direction. NOTE: Pressing on the disc by hand or rubbing the disc with a hard cloth may scratch the disc surface. Use of solvents such as record spray, antistatic agents, alcohol, benzine, thinners or a chemical cloth may cause damage to the disc, making the disc unusable.
2. USB AUDIO SYSTEM FUNCTION OUTLINE The No. 1 stereo jack adapter assembly is equipped with a USB terminal. Connecting a USB device or "iPod" to the No. 1 stereo jack adapter assembly allows music files to be played. Not only is it possible to play music from a USB device with audio functions, it is also possible to play MP3, WMA or AAC music files that are stored on a USB device. In addition, "iPod" control software is installed, allowing file selection from playlists and operation using shuffle mode. HINT: Operation through the controls of a USB device or "iPod" cannot be performed while it is connected. USB audio system compatible devices USB device The following device formats can be used: Compatible USB device formats USB communication format: USB 2.0 HS (480 Mbps) and FS (12Mbps) File format: FAT16/32 (Windows) Class: Mass storage class MP3, WMA and AAC files written to a USB device with any format other than those listed above may not play correctly, and their names and folder names may not be displayed correctly. Items related to standards and limitations are as follows: Maximum directory hierarchy: 8 levels Maximum number of folders in device: 3000 (including the root folder) Maximum number of files in device: 9999 Maximum number of files per folder: 255 "iPod" "iPhone", "iPod", "iPod classic", "iPod nano" and "iPod touch" are trademarks of Apple Inc., registered in the U.S. and other countries. The following "iPod", "iPod nano", "iPod classic", "iPod touch" and "iPhone" devices can be used with this system. Made for: "iPod touch" (5th generation) "iPod touch" (4th generation) "iPod touch" (3rd generation) "iPod touch" (2nd generation) "iPod touch" (1st generation) "iPod classic" "iPod with video" "iPod nano" (7th generation) "iPod nano" (6th generation) "iPod nano" (5th generation) "iPod nano" (4th generation) "iPod nano" (3rd generation) "iPod nano" (2nd generation) "iPod nano" (1st generation) "iPhone 5" "iPhone 4S" "iPhone 4" "iPhone 3GS" "iPhone 3G" "iPhone" HINT: Depending on differences between models or software versions etc., some models might be incompatible with this system.
3. MP3/WMA/AAC OUTLINE Playable MP3 file standards Compatible standard MPEG1 LAYER3, MPEG2 LSF LAYER3 Compatible sampling frequency MPEG1 LAYER3: 32, 44.1, 48 (kHz) MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz) Compatible bit rate MPEG1 LAYER3: 32 to 320 (kbps) MPEG2 LSF LAYER3: 8 to 160 (kbps) Compatible with VBR Compatible channel mode Stereo, joint stereo, dual channel, monaural Playable WMA file standards Compatible standard WMA Ver. 7, 8, and 9 Compatible sampling frequency 32, 44.1, 48 (kHz) Compatible bit rate (Only compatible with 2-channel playback) Ver. 7, 8: CBR48 to 192 (kbps) Ver. 9: CBR48 to 320 (kbps) Compatible with VBR Playable AAC file standards Compatible standard MPEG4/AAC-LC Compatible sampling frequency 11.025, 16, 22.05, 24, 32, 44.1, 48 (kHz) Compatible bit rate 16 to 320 (kbps) Compatible with VBR ID3 tag, WMA tag and AAC tag Additional text information called an ID3 tag can be input to MP3 files. Information such as song titles and artist names can be stored. HINT: This player is compatible with ID3 tags of ID3 Ver. 1.0 and 1.1, and ID3 Ver. 2.2 and 2.3. (Number of characters complies with ID3 Ver. 1.0 and 1.1.) Additional text information called a WMA tag can be input to WMA files. Information such as song titles and artist names can be stored. Additional text information called an AAC tag can be input to AAC files. Information such as song titles and artist names can be stored. Usable media Only CD-ROMs, CD-Rs (CD-Recordable), CD-RWs (CD-ReWritable) and USB devices can be used to play MP3/WMA/AAC files. NOTE: CD-Rs, CD-RWs are more easily affected by a hot and humid environment than discs used for normal audio CDs. For this reason, some CD-Rs and CD-RWs may not be played. If there are fingerprints or scratches on a disc, the disc may not be played or the CD may skip. Some CD-Rs, CD-RWs may deteriorate if they are left in the cabin for a long time. Keep CD-Rs, CD-RWs in an opaque case. Usable media format Usable media format Disc format CD-ROM Mode 1, CD-ROM XA Mode 2 Form 1 File format ISO9660 Level 1 and Level 2 (Joliet, Romeo) HINT: MP3/WMA/AAC files written in any unlisted format may not be played normally or the file names or folder names may not be displayed correctly. This player is compatible with multi-session discs and can play CD-Rs, CD-RWs on which MP3/WMA/AAC files have been added. However, only the first session can be played. Discs whose first session includes both music data and MP3, WMA and AAC format data may not be played. Standards and restrictions Maximum directory levels 8 levels Maximum number of characters for a folder name/file name 32 characters Maximum number of folders 192 (Including empty folders, route folders, and folders that do not contain MP3/WMA/AAC files) Maximum number of files in a disc 255 (Including non-MP3/WMA/AAC files) File names Only files with an extension of ".mp3", ".wma" and ".m4a" can be recognized and played as MP3, WMA or AAC files. Save MP3, WMA or AAC files with an extension of ".mp3", ".wma" or ".m4a". NOTE: If non-MP3, non-WMA or non-AAC files are saved with an extension of ".mp3", ".wma" or ".m4a", those files may be wrongly recognized as MP3, WMA or AAC files and played. A loud noise may occur and damage to the speakers may result.
4. "Bluetooth" OUTLINE *1 Radio Receiver Assembly (Built-in "Bluetooth" Receiver Antenna) - - *a Example *b Cellular Network *c Cellular Phone ("Bluetooth" Compatible Type) *d Portable Audio Player ("Bluetooth" Compatible Type) *e "Bluetooth" Wireless Connection - - "Bluetooth" is a trademark owned by Bluetooth SIG, Inc. "Bluetooth" is a wireless connection technology that uses the 2.4 GHz frequency band. HINT: The communication performance of "Bluetooth" may vary depending on obstructions or radio wave conditions between communication devices, electromagnetic radiation, communication device sensitivity or antenna capacity. Hands-free function The "Bluetooth" built-in radio receiver assembly and a "Bluetooth" compatible cellular phone*1 can be connected using a "Bluetooth" wireless connection. This enables the use of the hands-free function on the cellular phone even if the phone is in a pocket or bag. For this reason, it is not necessary to use a connector or cable to connect the cellular phone. *1: Some versions of "Bluetooth" compatible cellular phones may not function properly. The hands-free function uses a "Bluetooth" wireless connection. A "Bluetooth" wireless connection can be affected by uncertain elements, such as vehicle location, time of day, etc. Therefore, problems related to establishing connection may be caused temporarily by "Bluetooth" connection conditions. It is necessary to check the frequency of occurrence, connection conditions using another cellular phone, etc. when performing diagnosis. Compatible hands-free devices Required "Bluetooth" specifications Ver. 2.0 or higher (Ver. 3.0+EDR recommended) Compatible profiles HFP (Hands Free Profile) Ver. 1.0 or higher (Ver. 1.6 or higher recommended)*1 OPP (Object Push Profile) Ver. 1.1 or higher*1 PBAP (Phone Book Access Profile) Ver. 1.0 or higher (Ver. 1.1 or higher recommended)*1 MAP (Message Access Profile) Ver. 1.0 or higher*2 Maximum number of hands-free devices that can be registered (including audio devices) 5 *1: This profile is necessary when using the contacts in the cellular phone. *2: This profile is necessary when using the message function. HINT: "Bluetooth" compatible cellular phone can be checked at http://www.lexus.com/MobileLink/. The amount of remaining battery charge displayed on the radio receiver assembly may be different from that of the "Bluetooth" device. "Bluetooth" audio function The "Bluetooth" built-in radio receiver assembly and a "Bluetooth" compatible portable audio player*2 can be connected using a "Bluetooth" wireless connection. This enables files stored in the portable audio player to be heard from the vehicle speakers. In addition, operations such as play/stop can be performed directly from the radio receiver assembly. *2: Some versions of "Bluetooth" compatible audio players may not be able to be connected via the "Bluetooth" function, or music may play, but functions available using the radio receiver assembly may be limited. Compatible "Bluetooth" audio devices Required "Bluetooth" specifications Ver. 2.0 or higher (Ver. 3.0+EDR recommended) Compatible profiles A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher (Ver. 1.2 or higher recommended) AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher (Ver. 1.4 or higher recommended) Maximum number of audio devices that can be registered (including hands-free devices) 5 HINT: The amount of remaining battery charge displayed on the radio receiver assembly may be different from that of the "Bluetooth" device.
5. RADIO DESCRIPTION Radio frequency band Radio broadcasts use the radio frequency bands shown in the table below. Service area The service areas of AM and FM broadcasts are vastly different. Sometimes an AM broadcast can be received very clearly but an FM stereo broadcast cannot. FM stereo has the smallest service area, and is prone to pick up static and other types of interference such as noise. *a FM (Stereo) *b FM (Monaural) *c AM Radio reception problems HINT: In addition to static, other problems such as "phasing", "multipath" and "fade out" exist. These problems are not caused by electrical noise, but by the radio signal propagation method itself. Phasing AM broadcasts are susceptible to electrical interference and another kind of interference called phasing. Occurring only at night, phasing is the interference created when a vehicle receives 2 radio wave signals from the same transmitter. One signal is reflected off the ionosphere and the other signal is received directly from the transmitter. *a Phasing *b Ionosphere Multipath Multipath is a type of interference created when a vehicle receives 2 radio wave signals from the same transmitter. One signal is reflected off buildings or mountains and the other signal is received directly from the transmitter. *a Multipath Fade out Fade out is caused by objects (buildings, mountains and other large obstructions) that deflect part of a signal, resulting in a weaker signal when the object is between the transmitter and vehicle. High frequency radio waves, such as FM broadcasts, are easily deflected by obstructions. Low frequency radio waves, such as AM broadcasts, are less likely to be deflected. *a Fade Out Noise problem Technicians must have a clear understanding about each customer's noise complaint. Use the following table to diagnose noise problems. Radio Frequency Noise Occurrence Condition Presumable Cause AM Noise occurs in a specific area Foreign noise Noise occurs when listening to an intermittent broadcast An identical program transmitted from multiple towers can cause noise where the signals overlap Noise occurs only at night Signal phasing FM Noise occurs while driving in a specific area Multipath resulting from a change in FM frequency
6. "HD Radio" FUNCTION OUTLINE (w/ HD Radio Function) The "HD Radio" system is a radio system that broadcasts in the IBOC (In-Band On-Channel) form that the iBiquity Co. has developed. By expanding the bandwidth per channel of conventional FM/AM bands, digital audio and data signals are additionally transmitted. "HD Radio" technology is manufactured under license from iBiquity Digital Corporation. U.S. and Foreign Patents. "HD Radio" and the HD and HD Radio logos are proprietary trademarks of iBiquity Digital Corp. Information for the music currently being listened to is stored in the system and can be transmitted to an "iPod" connected to the system. The information transferred to the "iPod" can be used for purchasing the music through the "iTunes" music store.
7. SDARS SYSTEM FUNCTION OUTLINE (w/ SDARS System) Satellite Digital Audio Radio Service (SDARS) is a satellite digital radio broadcast provided by Sirius XM Radio Inc. The broadcast (pay-type) is performed through satellites and terrestrial repeater networks. Several unique channels are available, and even if a vehicle changes locations, the same information can be received without breaks. Information such as song names, broadcast station names, etc. can be received. Also, traffic information can be received and displayed on the navigation screen. NOTE: To receive pay-type broadcasts, the customer must enter into a pay-type contract with XM Satellite Radio Inc. After entering into a contract, registration of the XM Radio ID is necessary. Also, if parts are replaced, the XM Radio ID must be re-registered. HINT: When disconnecting the cable from the negative (-) battery terminal, the broadcast station logo data will be initialized. It takes a while until the broadcast station logo data is updated to the latest one.
8. VEHICLE CUSTOMIZATION OUTLINE Customization of functions can also be customized on the multi-display assembly screen. Refer to Owner's Manual for further information on customizable items for the audio and visual system. HINT: Items available for customization via the audio and visual system can also be customized by using the Techstream. Some customize parameters displayed on the Techstream will be displayed on the "Vehicle Settings" screen for the audio and visual system. Users can customize these items.
9. AUTOMATIC SOUND LEVELIZER (ASL) FUNCTION OUTLINE The Automatic Sound Levelizer (ASL) function automatically adjusts the audio system volume level in order to compensate for increased vehicle noise (vehicle noise tends to increase as vehicle speed increases). The ASL adjusts the volume level based upon vehicle speed signals that it receives from the combination meter assembly.
10. COMMUNICATION SYSTEM AVC-LAN Outline Components of the audio and visual system communicate with each other via the AVC-LAN. The AVC-LAN uses a twisted pair of wires for its communication lines. The master unit of the AVC-LAN is the radio receiver assembly. HINT: The radio receiver assembly has the resistance (60 to 80 ohms) necessary for communication. If a short or open circuit occurs in the AVC-LAN circuit, communication is interrupted and the system will not operate normally. Local Bus Communication Outline Components of the audio and visual system communicate with each other via the local bus. The local bus uses a twisted pair of wires for its communication lines. The master unit of the local bus is the radio receiver assembly. HINT: The radio receiver assembly has the resistance (108 to 132 ohms) necessary for communication. The combination meter assembly has the resistance (108 to 132 ohms) necessary for communication. If a short or open circuit occurs in the local bus circuit, communication is interrupted and the system will not operate normally. CAN Communication Outline The audio and visual system uses CAN communication between the radio receiver assembly and ECUs.
11. DIAGNOSTIC FUNCTION OUTLINE The audio and visual system has a diagnostic function (the result is indicated on the master unit).

CAUTION / NOTICE / HINT

HINT

1. Use the following procedure to troubleshoot the audio and visual system.
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS When troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms Result Proceed to NEXT Result: 1 NEXT See step 3
3. INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard Voltage 11 to 14 V HINT: If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK CABIN Check that condensation is not likely to occur in the cabin and that the temperature is not high or extremely low in the cabin. OK Condensation is not likely being produced and the temperature is not high or extremely low. HINT: A humid cabin and a rapid change in temperature may lead to condensation. Condensation in the cabin may cause a short circuit. The audio and visual system may not operate normally when the temperature is -20°C (-4°F) or lower, or 65°C (149°F) or higher. Result Proceed to OK NG Result: 2 NG SET CABIN TO APPROPRIATE TEMPERATURE Result: 1 OK See step 5
5. CHECK CAN COMMUNICATION SYSTEM* Check if CAN communication system DTCs are output. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665785-S15342612202014102400000) Result Result Proceed to CAN DTCs are not output. A CAN DTCs are output. B Result: 2 B GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665785-S15342612202014102400000) Result: 1 A See step 6
6. CHECK FOR DTC* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) NOTE: Once DTC B1324 are cleared, they will not be stored even if there is a malfunction. If DTC B1324 is output, proceed to the troubleshooting procedure for DTC B1324 before clearing DTCs. Result Result Proceed to DTCs are output. A DTCs are not output. B Result: 2 B See step 10 Result: 1 A See step 7
7. DTC CLEAR* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) HINT: The present DTCs may not indicate actual malfunctions depending on the vehicle operating conditions. Result Proceed to NEXT Result: 1 NEXT See step 8
8. RECHECK FOR DTC* Refer to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Result Result Proceed to DTCs are output. A DTCs are not output. B HINT: Even if the problem symptom is not confirmed, check for DTCs. This is because the system stores history DTCs. If more information is needed, perform a recheck using the "System Check Mode" screen after rechecking for DTCs using the Techstream. Check for DTCs and inspect the area that the code indicates. Result: 2 B See step 10 Result: 1 A See step 9
9. DIAGNOSTIC TROUBLE CODE CHART Find the output code in Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665837-S25208393442014102400000) Result Proceed to NEXT Result: 1 NEXT See step 12
10. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [04/2013 - ]»(ref-665837-S26378820682014102400000) Result Result Proceed to Fault is not listed in Problem Symptoms Table. A Fault is listed in Problem Symptoms Table. B HINT: If the symptoms do not recur and no DTCs are output, attempt to reproduce the symptoms. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [04/2013 - ]»(ref-665529-S21853141262014102400000) Result: 2 B See step 12 Result: 1 A See step 11
11. PERFORM TROUBLESHOOTING BASED ON PROBLEM SYMPTOM Refer to Terminals of ECU. Refer to «TERMINALS OF ECU [04/2013 - ]»(ref-665837-S29447299522014102400000) Result Proceed to NEXT Result: 1 NEXT See step 12
12. CHECK CIRCUIT Adjust, repair or replace as necessary. Result Proceed to NEXT Result: 1 NEXT See step 13
13. RECHECK FOR DTC* After clearing DTCs, recheck for DTCs. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Body Electrical > Navigation System > Clear DTCs Body Electrical > Navigation System > Trouble Codes Result Proceed to NEXT Result: 1 NEXT See step 14
14. PERFORM CONFIRMATION TEST Result Proceed to NEXT Result: 1 NEXT END

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. CHECK PANEL & STEERING SWITCH HINT: The radio receiver assembly panel switches and steering switches are checked in the following procedure. Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. Enter diagnostic mode. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Select "Function Check/Setting" from the "Service Menu" screen. Select "Panel & Steering Switch" from the "Function Check/Setting I" screen. Panel & Steering Switch Check Mode SCREEN DESCRIPTION Display Content *a: Switch condition "Pushed" is displayed when any switch is pushed. *b: Number of switches pushed Number of switches pushed at once is displayed. If more than 3 switches are pushed at once, "More than 3" is displayed. *c: Rotary switch direction Direction of rotary switch is displayed. Operate each switch and check that the switch conditions are correctly displayed. NOTE: When the return switch on the remote operation board is pressed and held for 3 seconds or more, diagnostic mode will be canceled.
2. CHECK MICROPHONE HINT: The microphone and microphone input level are checked in the following procedure. Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. Enter diagnostic mode. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Select "Function Check/Setting" from the "Service Menu" screen. Select "Microphone Check" from the "Function Check/Setting I" screen. Microphone Check SCREEN DESCRIPTION Display Content *a: Microphone input level meter Monitors the microphone input level every 0.1 seconds and displays the results in 8 different levels. *b: Recording switch*1 Starts recording. *c: Stop switch*1 Stops recording and playing. *d: Play switch*1 Plays the recorded voice. *e: Recording indicator*1 Comes on while recording. *1: w/ Recording Function When speaking into the microphone, check that the microphone input level meter changes according to the input level. HINT: The microphone is active at all times when this screen is displayed. Push the recording switch and perform voice recording. HINT: Select the recording switch with the blower motor of the air conditioning system stopped. If an outlet of the air conditioning system is facing the microphone, noise may be recorded. While recording or playing, switches other than the stop switch cannot be pushed. When no recording is present, the play switch cannot be pushed. Recording will stop after 5 seconds or when the stop switch is pushed. Check that the recording indicator remains on while recording and that the recording can be played normally.
3. CHECK VEHICLE SIGNAL HINT: Vehicle signals received by the radio receiver assembly are checked in the following procedure. Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. Enter diagnostic mode. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Select "Function Check/Setting" from the "Service Menu" screen. Select "Vehicle Signal" from the "Function Check/Setting I" screen. Vehicle Signal Check Mode SCREEN DESCRIPTION Display Content Battery Battery voltage is displayed. IG Engine switch ON/OFF state is displayed. PKB Parking brake ON/OFF state is displayed. REV Reverse signal OFF state is displayed. When reverse signal is ON, this screen is not available. Using Techstream, confirm reverse signal state on Data List. Refer to «DATA LIST / ACTIVE TEST [04/2013 - ]»(ref-665837-S17208311062014102400000) SPEED Vehicle speed is displayed in km/h. TAIL Tail signal (light control switch) ON/OFF state is displayed. ADIM/TCAN Brightness state DIM (with)/BRIGHT (without) is displayed. HINT: Only items sending vehicle signals will be displayed. This screen displays vehicle signals received by the radio receiver assembly. This screen is updated once per second. When the "Vehicle Signal Check Mode" screen is displayed, check all the vehicle signal conditions.
4. CHECK HANDS-FREE VOICE QUALITY SETTING HINT: The hands-free voice of a "Bluetooth" compatible phone can be adjusted using the following procedure. Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. Enter diagnostic mode. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Select "Function Check/Setting" from the "Service Menu" screen. Select "HF Voice Quality Setting" from the "Function Check/Setting I" screen. Hands-Free Voice Quality Setting *a Numeric Keypad *b Setting Button *c Reset Button If necessary, refer to the table below to adjust the voice quality type with the numeric keypad. When adjusting the settings, use the number pad on the screen to input the voice quality type according to the table. SETTINGS Parameter Target Phenomenon Voice Quality Type Positive Effect of Changing Voice Quality Negative Effect of Changing Voice Quality A (Noise) The other party hears background noise when listening to your voice. 1000 The amount of background noise the other party hears when listening to your voice is reduced. The volume of voice the other party hears when listening to your voice may temporarily drop. B (Noise) The other party hears a lot of background noise when listening to your voice. 2000 The amount of background noise the other party hears when listening to your voice is sharply reduced. The volume of voice the other party hears when listening to your voice may temporarily drop. C (Echo) The other party hears weak echoes. 0100 The amount of echo is reduced (low level). Sound quality of the other party deteriorates (low level). D (Echo) The other party hears strong echoes. 0200 The amount of echo is reduced (high level). Sound quality of the other party deteriorates (high level). SETTINGS (WHEN MULTIPLE PHENOMENON OCCURRED) Parameter Target Phenomenon Voice Quality Type Positive Effect of Changing Voice Quality Negative Effect of Changing Voice Quality A+C The other party hears background noise and weak echoes when listening to your voice. 1100 The amount of background noise the other party hears when listening to your voice is reduced. The amount of echo is reduced (low level). The volume of voice may drop temporarily. Sound quality of the other party deteriorates (low level). A+D The other party hears background noise and strong echoes when listening to your voice. 1200 The amount of background noise the other party hears when listening to your voice is reduced. The amount of echo is reduced (high level). The volume of voice may drop temporarily. Sound quality of the other party deteriorates (high level). B+C The other party hears a lot of background noise and weak echoes when listening to your voice. 2100 The amount of background noise the other party hears when listening to your voice is sharply reduced. The amount of echo is reduced (low level). The volume of voice may drop temporarily. Sound quality of the other party deteriorates (low level). B+D The other party hears a lot of background noise and strong echoes when listening to your voice. 2200 The amount of background noise the other party hears when listening to your voice is sharply reduced. The amount of echo is reduced (high level). The volume of voice may drop temporarily. Sound quality of the other party deteriorates (high level). HINT: The default value is "0000". Settings will be applied when the setting button is selected. If voice quality type values that are not in the table are input, the setting will not be applied and a positive effect may not be gained. If the quality of phone calls decreases due to the changed settings, return the settings to "0000" by pressing the "INIT" switch.
5. CHECK SPEAKER HINT: This function is used when checking the speaker wiring and whether the speakers are functioning properly. Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. Turn audio mode on and play any audio source. HINT: This audio source will be used for the speaker check. Enter diagnostic mode. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Select "Failure Diagnosis" from the "Service Menu" screen. Select "System Check" from the "Failure Diagnosis" screen. Select "SP Check ON" from the "System Check Mode" screen. Check the speaker wiring and check that the speakers are functioning properly. HINT: Check that each speaker outputs sound from the selected audio source properly. "SP Check OFF" is displayed during the speaker check. Sound can be heard from the speakers around the vehicle in order beginning from a speaker on the front side. More than one speaker may sound simultaneously depending on the speaker wiring. Sound stops when any of the following conditions are met: The "SP Check OFF" switch is pressed. The engine switch is turned off. Diagnostic mode is turned off. The screen is changed to another screen. Audio mode is turned off.
6. CHECK SOFTWARE ERROR HISTORY HINT: This function is used to check the cause when the radio receiver assembly screen is blacked out. Check Software Error History. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Utility / Software Error History. Body Electrical > Navigation System > Utility Tester Display Software Error History When an item is stored for Software Error History, record it before repairing the radio receiver assembly. SOFTWARE ERROR HISTORY SCREEN DESCRIPTION Error Description Trigger Detail Software Reset Navi Microcomputer Hexadecimal Number Audio Microcomputer CAN Microcomputer No Video Signal Front Monitor Rear Monitor MOST Cold Restart Always HINT: Software Error History can store up to 5 history data items. If a new software error occurs when 5 data items have already been stored, the oldest data is cleared and the new data is stored. If an error that is unsupported by the Techstream occurs, a "-" is displayed for the display items. Clear software error history. When DTCs are cleared using any of the following operations, Software Error History will be cleared as well. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Cleared using the Techstream. Cleared using the system check mode screen. Cleared using the unit check mode screen.
7. CHECK OPTICAL DISC ERROR HISTORY HINT: This function is used to check the cause of an optical disc error. Check Optical Disc Error History. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Utility / Optical Disc Error History. Body Electrical > Navigation System > Utility Tester Display Optical Disc Error History When an item is stored for Optical Disc Error History, record it before proceeding with troubleshooting. OPTICAL DISC ERROR HISTORY SCREEN DESCRIPTION Display Content Error Type Displays the type of error. Device Displays the malfunctioning device. Date Displays the date and time that the malfunction occurred. "ERROR TYPE" SCREEN DESCRIPTION Error Type Detection Condition Action Read Error When a disc read error occurs. Proceed to next suspected area shown in Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [04/2013 - ]»(ref-665837-S26378820682014102400000) Disc damaged/upside down/dirty When it is determined that any of the following is the cause of the disc read error: The disc cannot be read. The disc cannot be read because of dirt or scratches. The disc cannot be read because it is inserted upside down. Cannot determine disc type An unsuitable disc is inserted. DPS error When an error occurs while decoding MP3/WMA/AAC files. Some files are corrupt When MP3/WMA/AAC files cannot be played back because they are unsupported. Even though the file extensions are MP3, WMA or AAC, files cannot be played back because the header information cannot be read. Some files cannot be found When a disc without music data is played back. When there are no playable MP3/WMA/AAC files. Copy protection violation When a file with copyright protection that cannot be played back is played back. "DEVICE" SCREEN DESCRIPTION Device Component DVD-P Not available CD-P Radio receiver assembly R-Seat DVD-P Not available HINT: Optical Disc Error History can store up to 7 history data items. If a new optical disc error occurs when 7 data items have already been stored, the oldest data is cleared and the new data is stored. If an error that is unsupported by the Techstream occurs, a "-" or blank is displayed for the display items. Clear optical disc error history. When DTCs are cleared using any of the following operations, Optical Disc Error History will be cleared as well. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Cleared using the Techstream. Cleared using the system check mode screen. Cleared using the unit check mode screen.
8. CHECK VIDEO DEVICE CONNECTION CHECK HINT: This function is used to detect disconnection of the video devices. In order to inspect the RSE, a disc should be inserted into the radio receiver assembly. Check Video Device Connection Check. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Utility / Video Device Connection Check. Body Electrical > Navigation System > Utility Tester Display Video Device Connection Check When an item is stored for Video Device Connection Check, record it before proceeding with troubleshooting. HINT: DTCs are stored when errors are detected. Depending on the vehicle, some of the items are not displayed on the "Error Detected Image Line (Type)" screen. VIDEO DEVICE CONNECTION CHECK SCREEN DESCRIPTION Error Detected Image Line (Type) Areas to be Checked H/U - > Separate Display (GVIF) Digital video signal between the radio receiver assembly and multi-display assembly H/U - > Full RSE (GVIF) Not available RSE - > Seat Back Display RH (GVIF) Not available RSE - > Seat Back Display LH (GVIF) Not available Rear Camera - > H/U (NTSC) NTSC video signal between the radio receiver assembly and rear television camera assembly IPA/BGM/PVM ECU - > Separate Display (GVIF) Not available IPA/BGM/PVM ECU - > H/U (NTSC) Not available IPA/BGM/PVM ECU - > H/U (GVIF) Not available Clear video device connection check. When DTCs are cleared using any of the following operations, Video Device Connection Check will be cleared as well. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Cleared using the Techstream. Cleared using the system check mode screen. Cleared using the unit check mode screen.
9. CHECK "Bluetooth" CONNECTION HISTORY HINT: This function is used to check the connection history when the connection between the radio receiver assembly and a "Bluetooth" device is unstable. Check "Bluetooth" Connection History. HINT: "Bluetooth" Connection History displays data stored in the internal memory of the ECU, such as the date a "Bluetooth" connection was attempted and the progress of a "Bluetooth" connection. By checking "Bluetooth" Connection History, the date, cause, etc. of a "Bluetooth" device failing to register or connect can be analyzed. "Bluetooth" connection history indicates the estimated cause of a malfunction, but does not determine it. Therefore, checking "Bluetooth" Connection History may not improve the problem. Performing inspection using the Techstream before recording the "Bluetooth" Connection History may clear the operation history. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Utility / "Bluetooth" Connection History. Body Electrical > Navigation System > Utility Tester Display Bluetooth Connection History When an item is stored for "Bluetooth" Connection History, record it before proceeding with troubleshooting. "BLUETOOTH" CONNECTION HISTORY SCREEN DESCRIPTION Item Content Occurrence Start Date/Time Date and time of "Bluetooth" connection are displayed. Occurrence End Date/Time Date and time of "Bluetooth" disconnection are displayed. History Type Type of "Bluetooth" Connection History is displayed. Result "Bluetooth" connection result is displayed. Contents "Bluetooth" connection status is displayed. "Bluetooth" Address "Bluetooth" device address is displayed. Continuance Time The number of retries when "Bluetooth" connection was performed is displayed. HISTORY TYPE: ACC ON Result Contents Detail Areas to be Checked - - Engine switch on (ACC) - HISTORY TYPE: REGISTRATION Result Contents Detail Areas to be Checked Success (HFP) No Error "Bluetooth" device was registered as a hands-free device properly. - Success (AVP) No Error "Bluetooth" device was registered as a "Bluetooth" audio device properly. - Failure Time Out Could not perform "Bluetooth" connection properly. Check that the "Bluetooth" device is in the cabin. Check that the "Bluetooth" device is not connected to another device using the "Bluetooth" connection. Restart the "Bluetooth" device and operate it again. Authentication Error Wrong PIN code was input for PIN code verification. Perform "Bluetooth" device registration again. (Input PIN code correctly.) Did not select the confirmation button even though a passkey was displayed. Perform "Bluetooth" device registration again. (When a passkey is displayed, select the confirmation button.) A verification error occurred between the radio receiver assembly and "Bluetooth" device. Restart the radio receiver assembly and "Bluetooth" device, and operate them again. ACL Link Disconnection "Bluetooth" connection was disconnected by operating the "Bluetooth" device. Perform "Bluetooth" device registration again. "Bluetooth" connection could not be established due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" device registration again. "Bluetooth" device was outside the communication area. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" device registration again. "Bluetooth" setting on the "Bluetooth" device was off. Change the "Bluetooth" setting to on and perform "Bluetooth" device registration again. "Bluetooth" device was off. Turn the "Bluetooth" device on and perform "Bluetooth" device registration again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. Memory Write Failure "Bluetooth" device information could not be stored in the radio receiver assembly. Perform "Bluetooth" device registration again. Other Error An error other than above occurred. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. Cancel No Error Registration was suspended by operating the radio receiver assembly or "Bluetooth" device. - HISTORY TYPE: CONNECTION Result Contents Detail Areas to be Checked Auto Connect Success (HFP) Manual Connect Success (HFP) No Error "Bluetooth" device was connected as a hands-free device properly. - Auto Connect Failure (HFP) Manual Connect Failure (HFP) Time Out Could not perform "Bluetooth" connection properly. Check that the "Bluetooth" device is in the cabin. Check that the "Bluetooth" device is not connected to another device using the "Bluetooth" connection. Restart the "Bluetooth" device and operate it again. Authentication Error Verification of authentication key between the radio receiver assembly and "Bluetooth" device failed. If "Bluetooth" connection failed again even though the "Bluetooth" connection was performed, perform registration again. A verification error occurred between the radio receiver assembly and "Bluetooth" device. Restart the radio receiver assembly and "Bluetooth" device, and operate them again. Page Time Out Could not find a "Bluetooth" device near the radio receiver assembly. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" connection could not be established due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. "Bluetooth" device was outside the communication area. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" setting on the "Bluetooth" device was off. Change the "Bluetooth" setting to on and perform "Bluetooth" connection again. "Bluetooth" device was off. Turn the "Bluetooth" device on and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. HISTORY TYPE: CONNECTION Result Contents Detail Areas to be Checked Auto Connect Failure (HFP) Manual Connect Failure (HFP) ACL Link Disconnection "Bluetooth" connection was disconnected by operating the "Bluetooth" device. Perform "Bluetooth" connection again. "Bluetooth" connection could not be established due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. "Bluetooth" device was outside the communication area. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" setting on the "Bluetooth" device was off. Change the "Bluetooth" setting to on and perform "Bluetooth" connection again. "Bluetooth" device was off. Turn the "Bluetooth" device on and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. SDP Error HFP was disabled on the "Bluetooth" device. Enable HFP on the "Bluetooth" device and perform "Bluetooth" connection again. "Bluetooth" device which operation had not been confirmed was used. Check that the "Bluetooth" device is hands-free compatible and its operation has been confirmed. Refer to «SYSTEM DESCRIPTION [04/2013 - ]»(ref-665837-S21567814442014102400000) Other Error An error other than above occurred. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. Manual Connect Cancel (HFP) No Error Connection was interrupted by operating the radio receiver assembly or "Bluetooth" device. - HISTORY TYPE: CONNECTION Result Contents Detail Areas to be Checked Auto Connect Success (AVP) Manual Connect Success (AVP) No Error "Bluetooth" device was connected as a "Bluetooth" audio device properly. - Auto Connect Failure (AVP) Manual Connect Failure (AVP) Time Out Could not perform "Bluetooth" connection properly. Check that the "Bluetooth" device is in the cabin. Check that the "Bluetooth" device is not connected to another device using the "Bluetooth" connection. Restart the "Bluetooth" device and operate it again. Authentication Error Verification of authentication key between the radio receiver assembly and "Bluetooth" device failed. If "Bluetooth" connection failed again even though the "Bluetooth" connection was performed, perform registration again. A verification error occurred between the radio receiver assembly and "Bluetooth" device. Restart the radio receiver assembly and "Bluetooth" device, and operate them again. Page Time Out Could not find a "Bluetooth" device near the radio receiver assembly. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" connection could not be established due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. "Bluetooth" device was outside the communication area. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" setting on the "Bluetooth" device was off. Change the "Bluetooth" setting to on and perform "Bluetooth" connection again. "Bluetooth" device was off. Turn the "Bluetooth" device on and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. HISTORY TYPE: CONNECTION Result Contents Detail Areas to be Checked Auto Connect Failure (AVP) Manual Connect Failure (AVP) ACL Link Disconnection "Bluetooth" connection was disconnected by operating the "Bluetooth" device. Perform "Bluetooth" connection again. "Bluetooth" connection could not be established due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. "Bluetooth" device was outside the communication area. Bring the "Bluetooth" device near the radio receiver assembly and perform "Bluetooth" connection again. "Bluetooth" setting on the "Bluetooth" device was off. Change the "Bluetooth" setting to on and perform "Bluetooth" connection again. "Bluetooth" device was off. Turn the "Bluetooth" device on and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. SDP Error AVP was disabled on the "Bluetooth" device. Enable AVP on the "Bluetooth" device and perform "Bluetooth" connection again. "Bluetooth" device which operation had not been confirmed was used. Check that the "Bluetooth" device is "Bluetooth" audio compatible and its operation has been confirmed. Refer to «SYSTEM DESCRIPTION [04/2013 - ]»(ref-665837-S21567814442014102400000) Other Error An error other than above occurred. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. Manual Connect Cancel (AVP) No Error Connection was interrupted by operating the radio receiver assembly or "Bluetooth" device. - HISTORY TYPE: DISCONNECTION Result Contents Detail Areas to be Checked Disconnection Complete (HFP) Link Loss The "Bluetooth" device was moved outside of the communication area. Move the "Bluetooth" device into the communication area. "Bluetooth" connection was disconnected due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. Disconnection from Partner "Bluetooth" connection was disconnected by operating the "Bluetooth" device. - Disconnection from Self "Bluetooth" connection was disconnected by operating the radio receiver assembly. - Other Error An error other than above occurred. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. Disconnection Complete (AVP) Link Loss The "Bluetooth" device was moved outside of the communication area. Move the "Bluetooth" device into the communication area. "Bluetooth" connection was disconnected due to wave interference around the vehicle. Check for wave interference and perform "Bluetooth" connection again. A malfunction occurred in the "Bluetooth" device. Restart the "Bluetooth" device and operate it again. Disconnection from Partner "Bluetooth" connection was disconnected by operating the "Bluetooth" device. - Disconnection from Self "Bluetooth" connection was disconnected by operating the radio receiver assembly. - Other Error An error other than above occurred. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. HISTORY TYPE: SEND Result Contents Detail Areas to be Checked Success No Error Call was made properly. - Failure Out of Service Outside the cellular phone service area. Move the vehicle into a cellular phone service area, check that the "Bluetooth" device is connected to the vehicle and operate the device again. Redial Regulation Redial of the "Bluetooth" device was restricted and could not make a hands-free call. Restart the "Bluetooth" device and operate it again. Other Error Could not make a hands-free call due to a "Bluetooth" device malfunction. Restart the "Bluetooth" device and operate it again. Could not make a hands-free call due to a radio receiver assembly malfunction. After turning the engine switch off and back on (IG) again, perform "Bluetooth" device registration again. Could not make a hands-free call from the radio receiver assembly because the call status of the "Bluetooth" device was not transmitted to the radio receiver assembly. Restart the "Bluetooth" device and operate it again. Clear "Bluetooth" connection history. When DTCs are cleared using any of the following operations, "Bluetooth" Connection History will be cleared as well. Refer to «DTC CHECK / CLEAR [04/2013 - ]»(ref-665837-S08838350392014102400000) Cleared using the Techstream. Cleared using the system check mode screen. Cleared using the unit check mode screen.

TERMINALS OF ECU [04/2013 - ]

HINT

Check from the rear of the connector while it is connected to the components.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. RADIO RECEIVER ASSEMBLY Terminal No. (Symbol) Wiring Color Terminal Description Condition Specification K73-3 (CNH1) V Local bus communication signal - - K73-4 (CNL1) P Local bus communication signal - - K73-18 (TX2+) B AVC-LAN communication signal - - K73-19 (TX2-) W AVC-LAN communication signal - - K72-1 (IG) - K70-7 (GND1) P - W-B Power source (IG) Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V K72-3 (ADIM) - K70-7 (GND1) LG - W-B Illumination (auto dimmer) signal Engine switch on (IG) Automatic light control sensor covered by hand, and light control switch in tail or head position 9 V or higher Engine switch on (IG) Automatic light control sensor not covered by hand, and light control switch in tail or head position Below 1 V K72-4 (MACC) - K70-7 (GND1)*1 R - W-B Microphone power supply Engine switch off Below 1 V Engine switch on (ACC) 4 to 6 V K72-5 (MIN+) - K70-7 (GND1) W - W-B Microphone voice signal See "Check Microphone" in Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665837-S12266083612014102400000) - K72-6 (SNS2) - K70-7 (GND1) L - W-B Microphone connection detection signal Always Below 1 V K72-7 (TX1+) L AVC-LAN communication signal - - K72-8 (TX1-) G AVC-LAN communication signal - - K72-9 (CANH) R CAN communication signal - - K72-10 (CANL) B CAN communication signal - - K72-11 (AGND) - Body ground Shield - Body ground Shield ground Always Below 1 V K72-12 (SG) - K70-7 (GND1) Shield - W-B External device connection detection signal External device connected Below 1 V K72-13 (VV+) - K70-7 (GND1) P - W-B Video signal External device playing (When stereo jack used) A waveform synchronized with video signals is output K72-14 (VV-) - K70-7 (GND1) L - W-B Video signal External device playing (When stereo jack used) A waveform synchronized with video signals is output K72-15 (PKB) - K70-7 (GND1) GR - W-B Parking brake signal See "Check Vehicle Signal" in Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665837-S12266083612014102400000) - K72-16 (MUT1) - K70-7 (GND1) LG - W-B Mute signal Engine switch on (ACC) Audio system playing 2.0 V or higher Audio system changing modes Below 1 V K72-17 (SPD) - K70-7 (GND1) L - W-B Vehicle speed signal See "Check Vehicle Signal" in Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665837-S12266083612014102400000) - K72-18 (SGND) - Body ground Shield - Body ground Shield ground Always Below 1 V K72-19 (MIN-) - K70-7 (GND1) B - W-B Microphone voice signal See "Check Microphone" in Operation Check Refer to «OPERATION CHECK [04/2013 - ]»(ref-665837-S12266083612014102400000) - K72-21 (SW1) - K72-23 (SWG) L - BR Steering pad switch signal No switch pushed 2.97 to 3.56 V Seek+ switch pushed 0.27 to 0.35 V Seek- switch pushed 0.86 to 1.03 V Volume+ switch pushed 1.51 to 1.79 V Volume- switch pushed 2.22 to 2.66 V K72-22 (SW2) - K72-23 (SWG) P - BR Steering pad switch signal No switch pushed 2.97 to 3.56 V MODE switch pushed 0.27 to 0.35 V On hook switch pushed 0.86 to 1.03 V Off hook switch pushed 1.51 to 1.79 V Voice switch pushed 2.22 to 2.66 V K72-23 (SWG) - K70-7 (GND1) BR - W-B Steering pad switch ground Always Below 1 V K72-25 (ADPG) - K70-7 (GND1) P - W-B External device connection detection signal External device connected Below 1 V External device not connected 2.1 to 3 V K72-26 (VAR+) - K72-27 (VA-) W - R Sound signal (Right) External device playing (When stereo jack used) A waveform synchronized with sound signals is output K72-27 (VA-) - K70-7 (GND1) R - W-B Ground Always Below 1 V K72-28 (VAL+) - K72-27 (VA-) B - R Sound signal (Left) External device playing (When stereo jack used) A waveform synchronized with sound signals is output K74-1 (VMTF) - K70-7 (GND1) W - W-B Visual mute signal Engine switch on (ACC) Screen display changes 2 V or higher --> Below 1 V --> 2 V or higher K74-11 (TX4+) G AVC-LAN communication signal - - K74-12 (TX4-) V AVC-LAN communication signal - - K70-1 (FR+) - K70-7 (GND1) W - W-B Sound signal (Right) Audio system playing A waveform synchronized with sound signals is output K70-2 (FL+) - K70-7 (GND1) B - W-B Sound signal (Left) Audio system playing A waveform synchronized with sound signals is output K70-3 (ACC1) - K70-7 (GND1) BE - W-B Power source (ACC) Engine switch off Below 1 V Engine switch on (ACC) 11 to 14 V K70-4 (+B1) - K70-7 (GND1) V - W-B Power source (+B) Always 11 to 14 V K70-5 (FR-) - K70-7 (GND1) G - W-B Sound signal (Right) Audio system playing A waveform synchronized with sound signals is output K70-6 (FL-) - K70-7 (GND1) R - W-B Sound signal (Left) Audio system playing A waveform synchronized with sound signals is output K70-7 (GND1) - Body ground W-B - Body ground Ground Always Below 1 V K70-10 (ILL+) - K70-7 (GND1) G - W-B Illumination signal Light control switch off Below 1 V Light control switch in tail or head position 11 to 14 V K71-2 (RL+) - K70-7 (GND1) W - W-B Voice signal Voice guidance sounding A waveform synchronized with voice signals is output K71-5 (ILL-) - K70-7 (GND1) BE - W-B Illumination signal Light control switch off Below 1 V Light control switch in tail or head position Pulse generation K71-6 (RL-) - K70-7 (GND1) B - W-B Voice signal Voice guidance sounding A waveform synchronized with voice signals is output K75-3 (ACC2) - K70-7 (GND1) BE - W-B Illumination power source (ACC) Engine switch off Below 1 V Engine switch on (ACC) 11 to 14 V K75-4 (+B2) - K70-7 (GND1) G - W-B Illumination power source (+B) Always 11 to 14 V K75-8 (GND2) - Body ground SB - Body ground Ground Always Below 1 V K120-1 (USV1) - Power source - - K120-2 (US1-) - Data signal - - K120-3 (US1+) - Data signal - - K120-4 (UGD1) - Ground - - K120-5 (USG1) - Shield ground - - K125-1 (GVIF) B Video signal (Digital) - - RA-5 (ANT+) - K70-7 (GND1) - - W-B Power source of antenna Engine switch on (ACC) Radio switch on and FM or AM selected 11 to 14 V *1: w/o Manual (SOS) Switch
2. STEREO COMPONENT AMPLIFIER ASSEMBLY Terminal No. (Symbol) Wiring Color Terminal Description Condition Specification P23-1 (+B) - P23-3 (GND) SB - BR Power source (+B) Always 11 to 14 V P23-3 (GND) - Body ground BR - Body ground Ground Always Below 1 V P23-4 (WFL+) - P23-3 (GND) R - BR Sound signal (Front Left) Audio system playing A waveform synchronized with sound signals is output P23-5 (WFR+) - P23-3 (GND) L - BR Sound signal (Front Right) Audio system playing A waveform synchronized with sound signals is output P23-6 (WF1+) - P23-3 (GND) GR - BR Sound signal (Woofer) Audio system playing A waveform synchronized with sound signals is output P23-7 (CTR+) - P23-3 (GND) GR - BR Sound signal (Front Center) Audio system playing A waveform synchronized with sound signals is output P23-12 (FL+) - P23-3 (GND) W - BR Sound signal (Front Left) Audio system playing A waveform synchronized with sound signals is output P23-13 (FR+) - P23-3 (GND) BE - BR Sound signal (Front Right) Audio system playing A waveform synchronized with sound signals is output P23-14 (RL+) - P23-3 (GND) BE - BR Sound signal (Rear Left) Audio system playing A waveform synchronized with sound signals is output P23-15 (RR+) - P23-3 (GND) LG - BR Sound signal (Rear Right) Audio system playing A waveform synchronized with sound signals is output P23-16 (+B2) - P23-3 (GND) BE - BR Power source (+B) Always 11 to 14 V P23-18 (GND2) - Body ground BR - Body ground Ground Always Below 1 V P23-19 (WFL-) - P23-3 (GND) B - BR Sound signal (Front Left) Audio system playing A waveform synchronized with sound signals is output P23-20 (WFR-) - P23-3 (GND) B - BR Sound signal (Front Right) Audio system playing A waveform synchronized with sound signals is output P23-21 (WF1-) - P23-3 (GND) L - BR Sound signal (Woofer) Audio system playing A waveform synchronized with sound signals is output P23-22 (CTR-) - P23-3 (GND) V - BR Sound signal (Front Center) Audio system playing A waveform synchronized with sound signals is output P23-27 (FL-) - P23-3 (GND) P - BR Sound signal (Front Left) Audio system playing A waveform synchronized with sound signals is output P23-28 (FR-) - P23-3 (GND) P - BR Sound signal (Front Right) Audio system playing A waveform synchronized with sound signals is output P23-29 (RL-) - P23-3 (GND) P - BR Sound signal (Rear Left) Audio system playing A waveform synchronized with sound signals is output P23-30 (RR-) - P23-3 (GND) W - BR Sound signal (Rear Right) Audio system playing A waveform synchronized with sound signals is output P24-1 (MUTE) - P23-3 (GND) LG - BR Mute signal Engine switch on (ACC) Audio system playing 2.0 V or higher Audio system changing modes Below 1 V P24-2 (L-) - P23-3 (GND) R - BR Sound signal (Left) Audio system playing A waveform synchronized with sound signals is output P24-3 (L+) - P23-3 (GND) B - BR Sound signal (Left) Audio system playing A waveform synchronized with sound signals is output P24-4 (R-) - P23-3 (GND) G - BR Sound signal (Right) Audio system playing A waveform synchronized with sound signals is output P24-5 (R+) - P23-3 (GND) W - BR Sound signal (Right) Audio system playing A waveform synchronized with sound signals is output P24-6 (SLD) - Body ground Shield - Body ground Shield ground Always Below 1 V P24-7 (TX-) G AVC-LAN communication signal - - P24-8 (TX+) L AVC-LAN communication signal - - P24-11 (SPD) - P23-3 (GND) L - BR Vehicle speed signal Engine switch on (IG) Wheel being rotated Pulse generation P24-12 (ACC) - P23-3 (GND) BE - BR Power source (ACC) Engine switch off Below 1 V Engine switch on (ACC) 11 to 14 V P24-14 (II1-) - P23-3 (GND) B - BR Voice signal Voice guidance sounding A waveform synchronized with voice signals is output P24-15 (II1+) - P23-3 (GND) W - BR Voice signal Voice guidance sounding A waveform synchronized with voice signals is output P24-18 (SLD1) - Body ground Shield - Body ground Shield ground Always Below 1 V P24-24 (TMUT) - Body ground*1 B - Body ground Mute signal Engine switch on (ACC) Audio system playing 2.0 V or higher Emergency call mode Below 1 V *1: w/ Manual (SOS) Switch
3. MULTI-DISPLAY ASSEMBLY Terminal No. (Symbol) Wiring Color Terminal Description Condition Specification K61-2 (ILL) - K61-13 (GND1) G - W-B Illumination signal Light control switch off Below 1 V Light control switch in tail or head position 11 to 14 V K61-3 (REV) - K61-13 (GND1) R - W-B Reverse signal Engine switch on (IG) Shift lever in R 11 to 14 V K61-7 (TX+) G AVC-LAN communication signal - - K61-8 (V+) - K61-13 (GND1) R - W-B Video signal Engine switch on (IG) Shift lever in R Camera lens not covered, displaying an image Pulse generation (Refer to waveform 1) Engine switch on (IG) Shift lever in R Camera lens covered, blacking out screen Pulse generation (Refer to waveform 2) K61-9 (V-) - K61-13 (GND1) W - W-B Ground Always Below 1 V K61-10 (CA+) - K61-13 (GND1) B - W-B Television camera power supply Engine switch on (ACC) 5.5 to 7.05 V K61-11 (VMTI) - K61-13 (GND1) W - W-B Visual mute signal Engine switch on (ACC) Screen display changes 2 V or higher --> Below 1 V --> 2 V or higher K61-12 (B) - K61-13 (GND1) V - W-B Power source (+B) Always 11 to 14 V K61-13 (GND1) - Body ground W-B - Body ground Ground Always Below 1 V K61-19 (TX-) V AVC-LAN communication signal - - K61-21 (CGND) - Body ground Shield - Body ground Shield ground Always Below 1 V K61-24 (ACC) - K61-13 (GND1) BE - W-B Power source (ACC) Engine switch off Below 1 V Engine switch on (ACC) 11 to 14 V K126-1 (GVIF) B Video signal (Digital) - - Reference (Oscilloscope waveform): Waveform 1 (camera lens not covered, displaying an image) Item Content Measurement terminal K61-8 (V+) - K61-13 (GND1) Measurement setting 200 mV/DIV., 50 μsec./DIV. Condition Engine switch on (IG), shift lever in R HINT: The video waveform changes according to the image sent by the television camera assembly. *a Waveform 1 (camera lens not covered, displaying an image) *b Synchronization Signal *c Video Waveform Waveform 2 (camera lens covered, blacking out the screen) Item Content Measurement terminal K61-8 (V+) - K61-13 (GND1) Measurement setting 200 mV/DIV., 50 μsec./DIV. Condition Engine switch on (IG), shift lever in R HINT: The video waveform changes according to the image sent by the rear television camera assembly. *a Waveform 2 (camera lens covered, blacking out the screen) *b Synchronization Signal *c Video Waveform
4. REMOTE OPERATION BOARD Terminal No. (Symbol) Wiring Color Terminal Description Condition Specification K78-1 (ILL+) - K78-4 (GND) G - W-B Illumination signal Light control switch off Below 1 V Light control switch in tail or head position 11 to 14 V K78-4 (GND) - Body ground W-B - Body ground Ground Always Below 1 V K78-8 (ILL-) - K78-4 (GND) BE - W-B Illumination signal Light control switch off Below 1 V Light control switch in tail or head position Pulse generation K78-10 (TX+) B AVC-LAN communication signal - - K78-11 (TX-) W AVC-LAN communication signal - - K78-14 (ACC) - K78-4 (GND) BE - W-B Power source (ACC) Engine switch off Below 1 V Engine switch on (ACC) 11 to 14 V
5. DCM (TELEMATICS TRANSCEIVER) (w/ Manual (SOS) Switch) Refer to «TERMINALS OF ECU [04/2013 - ]»(ref-665566-S01691017642014102400000)

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. CHECK DTC (CHECK USING TECHSTREAM) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Trouble Codes. Body Electrical > Navigation System > Trouble Codes Check for DTCs, and then write them down. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665837-S25208393442014102400000) NOTE: The audio and visual system outputs DTCs for the following system. When DTCs other than those in Diagnostic Trouble Code Chart for the audio and visual system are output, refer to Diagnostic Trouble Code Chart for the relevant system. System Proceed to Rear View Monitor System Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665841-S38330710212014102400000)
2. CLEAR DTC (CLEAR USING TECHSTREAM) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Trouble Codes. Body Electrical > Navigation System > Clear DTCs Clear the DTCs.
3. START DIAGNOSTIC MODE HINT: Illustrations may differ from the actual vehicle screen depending on the device settings and options. Therefore, some detailed areas may not be shown exactly the same as on the actual vehicle screen. If the system cannot enter diagnostic mode, inspect all AVC-LAN communication components and repair or replace the malfunctioning parts. Refer to «AVC-LAN Circuit [04/2013 - ]»(ref-665838-S24729835862014102400000) Start diagnostic mode at least 15 seconds after turning the engine switch on (IG). Otherwise, some items cannot be checked. Turn the engine switch on (IG). While pressing and holding the "MENU" switch, operate the light control switch: Off --> Tail --> Off --> Tail --> Off --> Tail --> Off. Diagnostic mode starts and the "Service Menu" screen will be displayed. Service inspection starts automatically and the result will be displayed.
4. FAILURE DIAGNOSIS The "Failure Diagnosis" screen will be displayed by selecting "Failure Diagnosis" on the "Service Menu" screen.
5. SYSTEM CHECK The "System Check Mode" screen will be displayed by selecting "System Check" on the "Failure Diagnosis" screen.
6. CHECK DTC (CHECK USING SYSTEM CHECK MODE SCREEN) HINT: When "NCON" is displayed for all devices connected through the AVC-LAN, or when all device names are not displayed, check if there is a short circuit in the AVC-LAN or devices connected to the AVC-LAN. Repair or replace parts as necessary. Refer to «AVC-LAN Circuit [04/2013 - ]»(ref-665838-S24729835862014102400000) System check mode screen description SCREEN DESCRIPTION Display Content *a: Device name list No. 1 Device Name List No. 1 displays some of the devices that make up the audio and visual system. The names of the components from Device Name List No. 1 are shown in the following table. *b: Check result Result codes for all devices are displayed. *c: Memory clear Present and history DTCs and registered connected device names are cleared. Select "Memory CLR" for 3 seconds. *d: Recheck A system check will be performed again after the memory is cleared. "Recheck" will dim during a system check. *e: Device name list No. 2 Device Name List No. 2 displays some of the devices that make up the audio and visual system. The names of the components from Device Name List No. 2 are shown in the following table. *A: DEVICE NAME LIST NO. 1 DESCRIPTION Name Component Connection Method DA Radio receiver assembly - DISP Multi-display assembly Communication line for AVC-LAN R-TOUCH Remote operation board Communication line for AVC-LAN DSP-AMP Stereo component amplifier assembly Communication line for AVC-LAN *B: CHECK RESULT DESCRIPTION Result Meaning Action OK The device does not respond with a DTC. - DETAIL The device responds with a DTC. Look up the DTC in "Unit Check Mode". NCON The device was previously present, but does not respond in diagnostic mode. - Check power supply wire harness of the device. - Check the AVC-LAN of the device. NRES The device responds in diagnostic mode, but gives no DTC information. - Check power supply wire harness of the device. - Check the AVC-LAN of the device. *E: DEVICE NAME LIST NO. 2 DESCRIPTION Name Component Connection Method AUX/VTR No. 1 stereo jack adapter assembly Vehicle wire harness IF-BOX_USB No. 1 stereo jack adapter assembly Communication line for USB Unit check mode screen description SCREEN DESCRIPTION Display Content *a: Device name Target device *b: History DTC Diagnostic memory results and stored DTCs are displayed. *c: Current DTC DTCs output in the service check are displayed. *d: DTC DTC (Diagnostic Trouble Code) *e: Diagnosis clear switch Selecting "Code CLR" for 3 seconds clears the diagnostic memory data of the target device (both diagnostic system check result and the displayed data are cleared). HINT: This screen is updated once per second. A maximum of 6 DTCs can be displayed for history and present DTCs. Read the system check result. If the check result is "DETAIL", select the displayed check result to view the results on the "Unit Check Mode" screen and record them. NOTE: A maximum of 6 DTCs can be displayed for history and present DTCs on the "Unit Check Mode" screen. Therefore, when 6 DTCs are displayed, troubleshoot those DTCs first and then check the "Unit Check Mode" screen again to see if any other DTCs are displayed. HINT: When all results are "OK", no DTCs are present. When proceeding to view the results of another device, press the "Back" switch to return to the "System Check Mode" screen. Repeat the step above to view the results of other devices. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665837-S25208393442014102400000) NOTE: The audio and visual system outputs DTCs for the following system. When DTCs other than those in Diagnostic Trouble Code Chart for the audio and visual system are output, refer to Diagnostic Trouble Code Chart for the relevant system. System Proceed to Rear View Monitor System Refer to «DIAGNOSTIC TROUBLE CODE CHART [04/2013 - ]»(ref-665841-S38330710212014102400000)
7. DTC CLEAR/RECHECK (CLEAR USING SYSTEM CHECK MODE SCREEN) Clear DTCs Select "Memory CLR" for 3 seconds. Confirm that the check results are cleared. HINT: To clear the DTCs for a specific device, clear the DTCs using the "Unit Check Mode" screen. When clearing DTCs using the "Unit Check Mode" screen, select "Code CLR" for 3 seconds. Recheck Press the "Recheck" switch. Confirm that all diagnostic codes are "OK" when the check results are displayed. If a result other than "OK" is displayed, perform troubleshooting again. HINT: When the DTCs are cleared using the "Unit Check Mode" screen, select "Back" to return to the "System Check Mode" screen and perform this operation.
8. FINISH DIAGNOSTIC MODE Turn the engine switch off.

FREEZE FRAME DATA [04/2013 - ]

1. CHECK FREEZE FRAME DATA Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Navigation System / Trouble Codes. Body Electrical > Navigation System > Trouble Codes Select a DTC to display its freeze frame data.
2. LIST OF FREEZE FRAME DATA Refer to Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [04/2013 - ]»(ref-665837-S17208311062014102400000)
