Cellular Communication System (Service Information): Overview Lexus IS III

Entertainment Systems 4 illustrations

Scheme 156

Scheme 156: ILLUSTRATION
Scheme 156: ILLUSTRATION
*1DCM (TELEMATICS TRANSCEIVER) ASSEMBLY*2DCM (TELEMATICS TRANSCEIVER) WITH BRACKET
*3NO. 1 DCM (TELEMATICS TRANSCEIVER) BRACKET*4NO. 2 DCM (TELEMATICS TRANSCEIVER) BRACKET

Scheme 157

Scheme 157: PROCEDURE
Scheme 157: PROCEDURE

Scheme 158

Scheme 158
Scheme 158

Scheme 159

Scheme 159
Scheme 159
  1. REMOVE COMBINATION METER ASSEMBLY Refer to «REMOVAL [04/2013 - ]»(ref-665740-S00868839382014102400000)
  2. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Disconnect the 4 connectors. Disengage the clamp. Remove the 2 nuts and DCM (telematics transceiver) with bracket.
  3. REMOVE NO. 1 DCM (TELEMATICS TRANSCEIVER) BRACKET Remove the 2 screws and No. 1 DCM (telematics transceiver) bracket.
  4. REMOVE NO. 2 DCM (TELEMATICS TRANSCEIVER) BRACKET Remove the 2 screws and No. 2 DCM (telematics transceiver) bracket.
  5. REMOVE DCM (TELEMATICS TRANSCEIVER) ASSEMBLY
