Night View System (Diagnostic Codes & Symptom Tests): Overview Lexus GS IV

Entertainment Systems 10 illustrations ~787 words

DESCRIPTION

This DTC is stored when an internal malfunction occurs in the No. 1 night view ECU.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B280AECU internal malfunctionNo. 1 night view ECU

The main body ECU monitors the low beam illumination state. If a low beam malfunction is detected, the main body ECU sends a malfunction signal to the No. 1 night view ECU via CAN communication and a DTC is stored.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2815The No. 1 night view ECU receives a low beam illumination malfunction signal via CAN communication during the low beam illumination command state.Lighting system CAN communication system No. 1 night view ECU

Scheme 295

Scheme 295: WIRING DIAGRAM

The No. 1 night view ECU monitors the status of the left and right near-infrared ray emitters. When an operation malfunction signal for a near-infrared ray emitter is detected, a DTC is stored.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2816The No. 1 night view ECU detects an operation malfunction signal for the near-infrared ray emitter on the right side.Harness or connector Headlight assembly RH No. 1 night view ECU
B2817The No. 1 night view ECU detects an operation malfunction signal for the near-infrared ray emitter on the left side.Harness or connector Headlight assembly LH No. 1 night view ECU

Scheme 296

Scheme 296: WIRING DIAGRAM

If the power switch is turned on (IG) after replacing the No. 1 night view ECU or night view camera without performing night view camera adjustment, a DTC is stored. When night view camera adjustment is completed successfully, the DTC is cleared automatically.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B281AThe power switch is turned on (IG) without performing night view camera adjustment.Night view camera adjustment No. 1 night view ECU

The No. 1 night view ECU monitors the power supplied to the night view camera. This DTC is stored if a power supply malfunction is detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B281BWhen the night view system is operating, the voltage at the CCD+ terminal of the No. 1 night view ECU is not between 5.7 and 6.5 V for 1 second or more.Harness or connector Night view camera assembly No. 1 night view ECU

Scheme 297

Scheme 297: WIRING DIAGRAM

The No. 1 night view ECU monitors the synchronization signal of the night view camera. This DTC is stored when a synchronization signal malfunction is detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B281CThere is an NTSC signal synchronization problem.Harness or connector Night view camera assembly No. 1 night view ECU

Scheme 298

Scheme 298: WIRING DIAGRAM

The No. 1 night view ECU receives headlight dimmer switch signals from the main body ECU via CAN communication.

This DTC is stored when an abnormal combination of headlight dimmer switch signals are detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2821The No. 1 night view ECU detects an abnormal combination of headlight dimmer switch signals.CAN communication system Lighting system No. 1 night view ECU

Scheme 299

Scheme 299: WIRING DIAGRAM

The No. 1 night view ECU communicates with the driving support ECU via CAN communication. This DTC is stored when a malfunction in the communication with the driving support ECU is detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2824The driving support ECU cannot receive CAN communication signals normally.CAN communication system No. 1 night view ECU

Scheme 300

Scheme 300: WIRING DIAGRAM

The No. 1 night view ECU receives automatic light control signals from the main body ECU via CAN communication. This DTC is stored when an automatic light control signal malfunction is detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2825The No. 1 night view ECU continuously receives abnormal automatic light control information for 3 seconds.CAN communication system Lighting system No. 1 night view ECU

Scheme 301

Scheme 301: WIRING DIAGRAM

If the power switch is turned on (IG) after replacing the No. 1 night view ECU without performing night view camera adjustment, or the No. 1 night view ECU determines that there is a mismatch in the destination or headlight type information, a DTC is stored. When night view camera adjustment is completed successfully, the DTC is cleared automatically.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2827The No. 1 night view ECU detects a malfunction in the initial settings when the power switch is turned on (IG).Night view camera adjustment No. 1 night view ECU

The No. 1 night view ECU communicates with the driving support ECU via CAN communication. This DTC is stored when a malfunction in the communication with the driving support ECU is detected.

HINT

While DTCs are stored, the night view system does not operate and a warning message is displayed on the accessory meter assembly.

DTC CodeDTC Detection ConditionTrouble Area
U1104There is a malfunction in the communication with the driving support ECU.CAN communication system

Scheme 302

Scheme 302: WIRING DIAGRAM

When the No. 1 night view ECU receives the switch signal from the night view switch, the ECU outputs a night view display request signal to the multi-media module receiver assembly.

Scheme 303

Scheme 303: WIRING DIAGRAM

The No. 1 night view ECU receives the front image signal from the night view camera. Using the digital (GVIF) signal line, the image data is sent to the accessory meter assembly and the area in front of the vehicle is displayed for the driver (night view screen).

Scheme 304

Scheme 304: WIRING DIAGRAM

The night view system includes the night view camera and near-infrared ray emitters. When these parts are damaged or dirty, when they do not operate properly, or when the beam axis of a near-infrared ray emitter is not properly adjusted, these symptoms may appear.
