Cellular Communication System (Service Information): Overview Lexus GS IV

Entertainment Systems 9 illustrations ~811 words

Scheme 252

Scheme 252: ILLUSTRATION
Scheme 252: ILLUSTRATION

Scheme 253

Scheme 253: ILLUSTRATION
Scheme 253: ILLUSTRATION

Scheme 254

Scheme 254: ILLUSTRATION
Scheme 254: ILLUSTRATION

Scheme 255

Scheme 255: REMOVAL [03/2012 - ]
Scheme 255: REMOVAL [03/2012 - ]

Scheme 256

Scheme 256
Scheme 256

Scheme 257

Scheme 257
Scheme 257
  1. PRECAUTION NOTE: After turning the power switch off, waiting time may be required before disconnecting the cable from the auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the auxiliary battery terminal notice before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-600412-S33693534232014022400000) . When replacing the multi-media module receiver assembly or DCM (telematics transceiver), perform the vehicle contract setting. Refer to «DCM ACTIVATION [03/2012 - ]»(ref-600445-S29232479322014022400000) . The safety connect device uses the DCM (telematics transceiver) to provide access to the network service. The DCM (telematics transceiver) has a DCM ID (described on the label attached to the DCM (telematics transceiver)).
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-600591-S42295782952014022400000)
  3. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-600591-S42295782952014022400000)
  4. DISCONNECT CABLE FROM AUXILIARY BATTERY NEGATIVE TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) auxiliary battery terminal to disable the SRS system. NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - ]»(ref-600412-S41156157812014022400000) .
  5. REMOVE CENTER INSTRUMENT CLUSTER FINISH PANEL . Refer to «REMOVAL [03/2012 - ] - Step 1»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. REMOVE INSTRUMENT PANEL FINISH PANEL END RH . Refer to «REMOVAL [03/2012 - ] - Step 3»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  7. REMOVE FRONT DOOR SCUFF PLATE RH . Refer to «REMOVAL [03/2012 - ] - Step 10»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  8. REMOVE FRONT DOOR OPENING TRIM COVER RH . Refer to «REMOVAL [03/2012 - ] - Step 12»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  9. REMOVE INSTRUMENT SIDE PANEL RH . Refer to «REMOVAL [03/2012 - ] - Step 24»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  10. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 25»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  11. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «REMOVAL [03/2012 - ] - Step 26»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  12. REMOVE DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Remove the 3 bolts and DCM (telematics transceiver) with bracket. Disconnect all the connectors.
  13. REMOVE NO. 1 TELEPHONE BRACKET Remove the bolt and No. 1 telephone bracket.
  14. REMOVE TELEPHONE BRACKET Remove the 2 bolts and telephone bracket.

Scheme 258

Scheme 258: INSTALLATION [03/2012 - ]
Scheme 258: INSTALLATION [03/2012 - ]
  1. INSTALL TELEPHONE BRACKET Install the telephone bracket with the 2 bolts. Torque: 3.2 N*m (33 kgf*cm, 28 in.*lbf)
  2. INSTALL NO. 1 TELEPHONE BRACKET Install the No. 1 telephone bracket with the bolt. Torque: 3.2 N*m (33 kgf*cm, 28 in.*lbf)
  3. INSTALL DCM (TELEMATICS TRANSCEIVER) WITH BRACKET Connect all the connectors. Install the DCM (telematics transceiver) with the 3 bolts. HINT: Tighten the bolts in the order shown in the illustration.
  4. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 17»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  5. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY . Refer to «INSTALLATION [03/2012 - ] - Step 18»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. INSTALL INSTRUMENT SIDE PANEL RH . Refer to «INSTALLATION [03/2012 - ] - Step 19»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  7. INSTALL FRONT DOOR OPENING TRIM COVER RH . Refer to «INSTALLATION [03/2012 - ] - Step 32»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  8. INSTALL FRONT DOOR SCUFF PLATE RH . Refer to «INSTALLATION [03/2012 - ] - Step 34»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  9. INSTALL INSTRUMENT PANEL FINISH PANEL END RH . Refer to «INSTALLATION [03/2012 - ] - Step 7»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  10. INSTALL CENTER INSTRUMENT CLUSTER FINISH PANEL . Refer to «INSTALLATION [03/2012 - ] - Step 8»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  11. CONNECT CABLE TO AUXILIARY BATTERY NEGATIVE TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - ]»(ref-600412-S41156157812014022400000) .
  12. INSTALL LUGGAGE COMPARTMENT TRIM COVER LH . Refer to «INSTALLATION [03/2012 - ] - Step 24»(ref-600591-S24662608162014022400000)
  13. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION [03/2012 - ] - Step 26»(ref-600591-S24662608162014022400000)
  14. CHECK SRS WARNING LIGHT Refer to «DIAGNOSIS SYSTEM [03/2012 - ]»(ref-600414-S16656841442014022400000)
  15. DCM ACTIVATION When replacing the multi-media module receiver assembly or DCM (telematics transceiver), perform the vehicle contract setting. Refer to «DCM ACTIVATION [03/2012 - ]»(ref-600445-S29232479322014022400000) .

Scheme 259

Scheme 259: ILLUSTRATION
Scheme 259: ILLUSTRATION

Scheme 260

Scheme 260: REMOVAL [03/2012 - ]
Scheme 260: REMOVAL [03/2012 - ]
  1. PRECAUTION NOTE: After turning the power switch off, waiting time may be required before disconnecting the cable from the auxiliary battery terminal. Therefore, make sure to read the disconnecting the cable from the auxiliary battery terminal notice before proceeding with work. Refer to «PRECAUTION [03/2012 - ]»(ref-600412-S33693534232014022400000) .
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL [03/2012 - ] - Step 1»(ref-600591-S42295782952014022400000)
  3. REMOVE LUGGAGE COMPARTMENT TRIM COVER LH . Refer to «REMOVAL [03/2012 - ] - Step 2»(ref-600591-S42295782952014022400000)
  4. DISCONNECT CABLE TO AUXILIARY BATTERY NEGATIVE TERMINAL NOTE: When disconnecting the cable, some systems need to be initialized after the cable is reconnected. Refer to «INITIALIZATION [03/2012 - ]»(ref-600412-S41156157812014022400000) .
  5. REMOVE FRONT ROOF TOP GARNISH . Refer to «REMOVAL [03/2012 - ] - Step 27»(/lexus/gs/iv-2011-2015/remont/exteriorinterior-trim/#interior-panels-trim-service-information)
  6. REMOVE MAP LIGHT ASSEMBLY Using a moulding remover B, detach the 4 clips and 2 guides. Disconnect the 2 connectors and remove the map light assembly.
