Automatic Transaxle Control System - 2.0L: Other Kia Sportage III

TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed. In the following case, TCM learning is required.

1. Transaxle assembly replacement
2. TCM replacement
3. TCM upgrading

Scheme 188

1. TCM learning condition ATF temperature: 40~100°C (104~212°F)
2. TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning

1. Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open.
2. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st.
3. Repeat the above driving pattern four times or more.

Up-shift throttle open: 15~25%

Scheme 189

Scheme 190

Scheme 191

Functions

1. Monitors the vehicle's operating conditions to determine the optimal gear setting.
2. Performs a gear change if the current gear setting differs from the identified optimal gear setting.
3. Determines the need for damper clutch (D/C) activation and engages the clutch accordingly.
4. Calculates the optimal line pressure level by constantly monitoring the torque level and adjusts the pressure accordingly.
5. Diagnoses the automatic transaxle for faults and failures.

Scheme 192

Scheme 193

TCM Terminal Function

Connector (CHG-AG)

CONNECTOR TERMINALS REFERENCE CHART

Connector (CHG-AG)

CONNECTOR TERMINALS REFERENCE CHART

Scheme 194

Scheme 195

Signal Code Table

SIGNAL CODE REFERENCE CHART

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

1. Place the shift lever into the "N" position.
2. Remove the air duct (A).
3. Remove the air cleaner assembly. Refer to " «INTAKE MANIFOLD»(ref-584559-S04578570072013110400000) ". Disconnect the breather hose (A) and brake booster intensifier hose. Disconnect the air intake hose and then remove the air cleaner assembly (B).
4. Remove the battery and the battery tray. Refer to «BATTERY»(ref-584563-S16022409312013110400000) .
5. Disconnect the inhibitor switch connector (A).
6. Remove the shift cable mounting nut (B).
7. Remove the manual control lever (A) and the washer (B) after removing a nut (C).
8. Remove the inhibitor switch (A) after removing the bolts (2 ea).

Scheme 201

Scheme 202

Scheme 203

1. Check that the shift lever is placed in the "N" position
2. Install the inhibitor switch (A). NOTE: Lightly tighten the inhibitor switch mounting bolts so that necessary adjustments can be made.
3. Install the manual control lever (A) and the washer (B). NOTE: Lightly tighten the manual control lever nut (C) so that necessary adjustments can be made.
4. Align the hole (D) in the manual control lever with the "N" position hole (E) of the inhibitor switch and then insert the SST inhibitor switch guide pin (09480-A3800).
5. Tighten the nut and bolts with the specified torque.
6. Remove the SST (09480-A3800) from the hole.
7. Connect the inhibitor switch connector (A).
8. Install the shift cable by tightening nut (B). NOTE: Lightly tighten the shift cable mounting nut (B) so that necessary adjustments can be made.
9. Push the shift cable to the arrow "F" to eliminate free play and then tighten the nut (A) with the specified torque. Tightening torque: 9.8 ~ 14.7 N.m (1.0 ~ 1.5 Kgf.m, 7.2 ~ 10.9 lb-ft)
10. Install the battery and the battery tray. Refer to «BATTERY»(ref-584563-S16022409312013110400000) .
11. Install the air cleaner assembly. Connect the breather hose (A) and brake booster intensifier hose. Connect the air intake hose and then remove the air cleaner assembly (B).
12. Install the air duct (A).

Scheme 204

Scheme 205

Scheme 206

1. Remove the center console assembly. Refer to " «INTERIOR (CONSOLE)»(ref-584487-S06307377062013110400000) ".
2. Disconnect sports mode connector (A).
3. Take off the clip (A) and then remove the shift cable (B).
4. Remove the shift lever assembly (D) by removing the bolts (C-4 ea). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
5. Installation is the reverse of removal.

Note. Make sure vehicle does not roll before setting room side shift lever and T/M side manual control lever to "N" position.

Scheme 207

Scheme 208

Scheme 209

1. Remove the center console assembly. Refer to " «INTERIOR (CONSOLE)»(ref-584487-S06307377062013110400000) "
2. Take off the clip (A) and then remove the control cable (B).
3. Remove the control cable assembly in the vehicle after removing the nuts (B) and the retainer (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8~8.7 lb-ft)
4. Remove the nut (C).
5. Remove the cable (B) from the bracket (A) at transaxle assembly side Refer to " «AUTOMATIC TRANSAXLE»(ref-584556-S23282799422013110400000) ".
6. Remove the control cable inside of cab.
