Automatic Transaxle Control System - 2.4L: Other Kia Sportage III

Automatic Trans 12 illustrations ~345 words

TCM Learning

When shift shock is occurred or parts related with the transaxle are replaced, TCM learning should be performed. In the following case, TCM learning is required.

  1. Transaxle assembly replacement
  2. TCM replacement
  3. TCM upgrading

Scheme 67

Scheme 67
Scheme 67
  1. TCM learning condition ATF temperature: 60-115°C (140-239°F)
  2. TCM learning procedure Stop learning Repeat the below shift pattern four times or more with stepping on the brake. Driving learning
  1. Drive the vehicle through all gears at D range. Drive from stop to 1st to 2nd to 3rd to 4th to 5th to 6th with keeping fixed throttle open.
  2. Down shift from 6th to 5th, 5th to 4th, 4th to 3rd, 3rd to 2nd, 2nd to 1st.
  3. Repeat the above driving pattern four times or more.

Up-shift throttle open: 15-30%

Scheme 68

Scheme 68: Circuit Diagram
Scheme 68: Circuit Diagram

Scheme 69

Scheme 69: Vehicle Components
Scheme 69: Vehicle Components

Scheme 70

Scheme 70: Transaxle Components
Scheme 70: Transaxle Components

Functions

  1. Monitors the vehicle's operating conditions to determine the optimal gear setting.
  2. Performs a gear change if the current gear setting differs from the identified optimal gear setting.
  3. Determines the need for damper clutch (D/C) activation and engages the clutch accordingly.
  4. Calculates the optimal line pressure level by constantly monitoring the torque level and adjusts the pressure accordingly.
  5. Diagnoses the automatic transaxle for faults and failures.

Scheme 71

Scheme 71: TCM Connector And Terminal Function
Scheme 71: TCM Connector And Terminal Function

Connector (CHG-A)

PinDescription
1
2
3Line pressure control solenoid valve (LINE_VFS)
4Torque converter control solenoid valve (T/CON_VFS)
535R clutch control solenoid valve (35R/C_VFS)
6Input speed sensor power
7Output speed sensor power
8Input speed sensor signal
9Output speed sensor signal
10
11
12
13
14
15
16
17Underdrive brake control solenoid valve (UD/B_VFS)
1826 brake control solenoid valve (26/B_VFS)
19Shift lock solenoid
20Overdrive clutch control solenoid valve (OD/C_VFS)
21
22Rear lamp relay
23
24Start relay
25Inhibitor switch signal "S2"
26Inhibitor switch signal "S3"
27Inhibitor switch signal "S4"
28
29
30
31
32ON/OFF solenoid valve B (SS-B)
33ON/OFF solenoid valve A (SS-A)
34Ground (Power 1)
35Ground (Power 2)
36Sports mode down switch
37Sports mode up switch
38Sports mode Select switch
39
40Inhibitor switch signal "S1"
41
42
43
44
45
46
47Solenoid supply power 1
48Solenoid supply power 2
49TCM Input power 1 (For solenoid)
50TCM Input power 2 (For solenoid)
51Reserved
52Reserved
53Oil temperature sensor (-)
54Oil temperature sensor (+)
55
56
57
58
59
60

TCM CONNECTOR PINS REFERENCE CHART (CHG-A)

Connector (CHG-K)

PinDescriptionPinDescription
1Power ground31Power ground
2Battery power (B+)32Battery power (B+)
3Power ground33CAN communication line (HIGH)
4Battery power (B+)34CAN communication line (Low)

TCM CONNECTOR PINS REFERENCE CHART (CHG-K)

PinDescriptionConditionInput/output value
TypeLevel
1
2
3Line pressure control solenoid valve (LINE_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
4Torque converter control solenoid valve (T/CON_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
535R clutch control solenoid valve (35R/C_VFS)Output0V/Battery voltage level
9V < Battery voltage level < 16V
6Input speed sensor powerONPower0V/7.5V
OFF
7Output speed sensor powerONPower0V/7.5V
OFF
8Input speed sensor signalHighInput0.7V/1.4V
Low
9Output speed sensor signalHighInput0.7V/1.4V
Low
10
11
12
13
14
15
16
17Underdrive brake control solenoid valveOutput0V/Battery voltage level
(UD/B_VFS)9V < Battery voltage level < 16V
Power supply: V_SOL2
1826 brake control solenoid valveOutput0V/Battery voltage level
(26/B_VFS)9V < Battery voltage level < 16V
Power supply: V_SOL2
19Shift lock solenoidHighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
20Overdrive clutch control solenoid valveOutput0V/Battery voltage level
(OD/C_VFS)9V < Battery voltage level < 16V
Power supply: V_SOL1
21
22Rear lamp relayR ONOutput0V/Battery voltage level
Other9V < Battery voltage level < 16V
23
24Start relayHighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
25Inhibitor switch signal "S2"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
26Inhibitor switch signal "S3"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
27Inhibitor switch signal "S4"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
28
29
30
31
32ON/OFF solenoid valve B (SS-B)HighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
33ON/OFF solenoid valve A (SS-A)HighOutput0V/Battery voltage level
Low9V < Battery voltage level < 16V
34Ground (Power 1)Ground0V
35Ground (Power 2)Ground0V
36Sports mode down switchDown ONInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
37Sports mode up switchUp ONInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
38Sports mode select switchSport modeInput0V/Battery voltage level
Other9V < Battery voltage level < 16V
39
40Inhibitor switch signal "S1"HighInput0V/Battery voltage level
Low9V < Battery voltage level < 16V
41
42
43
44
45
46
47Solenoid supply power 1ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
48Solenoid supply power 2ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
49TCM Input power 1PowerBattery voltage level
(For solenoid)9V < Battery voltage level < 16V
50TCM Input power 2PowerBattery voltage level
(For solenoid)9V < Battery voltage level < 16V
51
52
53Oil temperature sensor (-)Ground0V
54Oil temperature sensor (+)ONInput0V/3.3V
OFF
55
56
57
58
59
60

TCM CONNECTOR PINS REFERENCE CHART (CHG-A)

PinDescriptionConditionTypeLevel
1Power groundGround0V
2Battery power (B+)ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
3Power groundGround0V
4Battery power (B+)ONPower0V/Battery voltage level
OFF9V < Battery voltage level < 16V
5Power groundGround0V
6Battery power (B+)PowerBattery voltage level
9V < Battery voltage level < 16V

TCM CONNECTOR PINS REFERENCE CHART (CHG-K)

Scheme 72

Scheme 72: Circuit Diagram
Scheme 72: Circuit Diagram

Scheme 73

Scheme 73
Scheme 73

Signal Code Table

PP-RRR-NNN-DD
S11000111
S20001100
S31100000
S41111110

SIGNAL CODE CHART

Scheme 74

Scheme 74: Circuit Diagram
Scheme 74: Circuit Diagram

Scheme 75

Scheme 75: Removal
Scheme 75: Removal

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78
  1. Place the shift lever into the "N" position.
  2. Remove the air duct (A).
  3. Remove the air cleaner assembly. Disconnect the breather hose (A) and brake booster intensifier hose. Disconnect the air intake hose and then remove the air cleaner assembly (B).
  4. Remove the battery and the battery tray. Refer to «BATTERY»(ref-584470-S38443519172013110400000) .
  5. Disconnect the inhibitor switch connector (A).
  6. Remove the shift cable mounting nut (B).
  7. Remove the manual control lever (A) and the washer (B) after removing a nut (C).
  8. Remove the inhibitor assembly (A) after removing the bolts (2 ea).

More articles — Automatic Transaxle Control System - 2.4L
