Automatic Transaxle Control System - 2.4L: Specifications Kia Sportage III

Automatic Trans 16 illustrations ~198 words

Specifications

  1. Type: Negative Thermal Coefficient Type
Temp.((°C) °F)Resistance (kohms)
(-40)-4048.1
(-20)-4.015.6
(0)32.05.88
(20)68.02.51
(40)104.01.11
(60)140.00.61
(80)176.00.32
(100)212.00.18
(120)248.00.10
(140)284.00.06
(150)3020.05

TEMPERATURE AND RESISTANCE SPECIFICATIONS

Scheme 1

Scheme 1

Scheme 2

Scheme 2: Circuit Diagram
  1. Type: Hall effect sensor
Operation condition (°C (°F))((-)40-150)) -40-302
Air gap (mm) in.(0.95-1.65) 0.037-0.065
Output voltage (V)High1.18-1.68
Low0.59-0.84

INPUT SPEED SENSOR SPECIFICATIONS

Scheme 3

Scheme 3: Circuit Diagram

Scheme 4

Scheme 4: Signal Waveform

Scheme 5

Scheme 5
  1. Type: Hall effect sensor
Operation condition (°C (°F))((-)40-150)) -40-302
Air gap (mm) in.(0.25-0.7) 0.01-0.027
Output voltageHigh1.18-1.68
Low0.59-0.84

OUTPUT SPEED SENSOR SPECIFICATIONS

Scheme 6

Scheme 6: Circuit Diagram

Scheme 7

Scheme 7: Signal Waveform

Scheme 8

Scheme 8

Direct control VFS (T/CON)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)9.81-500.14 (0.1-5.1, 1.42-72.54)
Current value (mA)50-850
Internal resistance (ohms)5.1

TORQUE CONVERTER CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 9

Scheme 9: Circuit Diagram

Direct control VFS (26/B)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)9.81-500.14 (0.1-5.1, 1.42-72.54)
Current value (mA)50-850
Internal resistance (ohms)5.1

BRAKE CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 10

Scheme 10: Circuit Diagram

Direct control VFS (LINE Pressure)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14-9.81 (5.1-0.1, 72.54-1.42)
Current value (mA)50-850
Internal resistance (ohms)5.1

LINE PRESSURE CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 11

Scheme 11: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14-9.81 (5.1-0.1, 72.54-1.42)
Current value (mA)50-850
Internal resistance (ohms)5.1

CLUTCH CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 12

Scheme 12: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14-9.81 (5.1-0.1, 72.54-1.42)
Current value (mA)50-850
Internal resistance (ohms)5.1

UNDERDRIVE BRAKE CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 13

Scheme 13: Circuit Diagram

Direct control VFS (35R/C)

  1. Control type: Normal low type
Control Pressure kPa (kgf/cm 2 , psi)500.14-9.81 (5.1-0.1, 72.54-1.42)
Current value (mA)50-850
Internal resistance (ohms)5.1

OVERDRIVE CLUTCH CONTROL SOLENOID VALVE SPECIFICATIONS

Scheme 14

Scheme 14: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10-11

SS-A SOLENOID VALVE SPECIFICATIONS

Scheme 15

Scheme 15: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

  1. Control type: Normal low type
Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10-11

SS-B SOLENOID VALVE SPECIFICATIONS

Scheme 16

Scheme 16: Circuit Diagram
  1. Type: Combination of output signals from 4 terminals
Power supply (V)12
Output typePin to Pin

INHIBITOR SWITCH SPECIFICATIONS
