Automatic Transaxle Control System - 2.0L: Specifications Kia Sportage III

Automatic Trans 16 illustrations ~192 words

Specifications

Type: Negative Thermal Coefficient Type

Temp.((°C) °F)Resistance (kohms)
(-40) -4048.1
(-20) -4.015.6
(0) 32.05.88
(20) 68.02.51
(40) 104.01.11
(60) 140.00.61
(80) 176.00.32
(100) 212.00.18
(120) 248.00.10
(140) 284.00.06
(150) 3020.05

TEMPERATURE RESISTANCE REFERENCE CHART

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131: Circuit Diagram
Scheme 131: Circuit Diagram

Type: Hall effect sensor

Operation condition (°C (°F))((-)40~150)) -40~302
Air gap (mm) in.(0.95~1.55) 0.950~1.55
Output voltage (V)High1.18~1.68
Low0.59~0.84

OPERATION CONDITION CHART

Scheme 132

Scheme 132: Circuit Diagram
Scheme 132: Circuit Diagram

Scheme 133

Scheme 133: Signal Waveform
Scheme 133: Signal Waveform

Scheme 134

Scheme 134
Scheme 134

Type: Hall effect sensor

Operation condition (°C (°F))((-)40~150)) -40~302
Air gap (mm) in.(0.55~1) 0.0217~0.0394
Output voltageHigh1.18~1.68
Low0.59~0.84

OPERATION CONDITION CHART

Scheme 135

Scheme 135: Circuit Diagram
Scheme 135: Circuit Diagram

Scheme 136

Scheme 136: Signal Waveform
Scheme 136: Signal Waveform

Scheme 137

Scheme 137
Scheme 137

Direct control VFS (T/CON)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 138

Scheme 138: Circuit Diagram
Scheme 138: Circuit Diagram

Direct control VFS (26/B)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)9.81~500.14 (0.1~5.1, 1.42~72.54)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 139

Scheme 139: Circuit Diagram
Scheme 139: Circuit Diagram

Direct control VFS (LINE Pressure)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 140

Scheme 140: Circuit Diagram
Scheme 140: Circuit Diagram

Direct control VFS (35R/C)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 141

Scheme 141: Circuit Diagram
Scheme 141: Circuit Diagram

Direct control VFS (35R/C)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 142

Scheme 142: Circuit Diagram
Scheme 142: Circuit Diagram

Direct control VFS (35R/C)

Control type: Normal low type

Control Pressure kPa (kgf/cm 2 , psi)500.14~9.81 (5.1~0.1, 72.54~1.42)
Current value (mA)50~850
Internal resistance (ohms)5.1

CONTROL PRESSURE REFERENCE CHART

Scheme 143

Scheme 143: Circuit Diagram
Scheme 143: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

CONTROL PRESSURE REFERENCE CHART

Scheme 144

Scheme 144: Circuit Diagram
Scheme 144: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kPa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10~11

CONTROL PRESSURE REFERENCE CHART

Scheme 145

Scheme 145: Circuit Diagram
Scheme 145: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typePin to Pin

CONNECTOR PIN REFERENCE CHART
