Hands Free System - Optima: Removal & Installation Kia Optima III рестайлинг

Removal

[Upper Steering Wheel Remote Control Switch]

Scheme 220

Scheme 221

Scheme 222

Scheme 223

1. Disconnect the negative (-) battery terminal.
2. Remove the driver airbag module. Refer to DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING .
3. Remove the steering wheel. Refer to STEERING COLUMN & SHAFT .
4. Loosen the mounting screws from the rear steering wheel cover.
5. Remove the steering wheel remote control switch connector (A) after loosening the mounting screws.

[Lower Steering Wheel Remote Control Switch]

1. Disconnect the negative (-) battery terminal.
2. Remove the driver airbag module. (Refer to the RT group)
3. Remove the steering wheel. (Refer to «HEATED STEERING WHEEL»(ref-677629-S31876737952014121100000)
4. Loosen the mounting screws from the front steering wheel cover.
5. Remover the upper left steering wheel cover (A) after loosening the mounting screws.
6. Remove the upper steering wheel remote control switch (A) after disconnecting the connector.
7. Remove the steering wheel cover (A) after loosening the mounting screws from the front steering wheel cover
8. Remove the front steering wheel cover (B) after disconnecting the connector (A).
9. Remove the lower steering wheel remote control switch (B) after disconnecting the connector (A).

Scheme 224

Scheme 225

Scheme 226

1. Disconnect the negative (-) battery terminal.
2. Remove the roof trim. Refer to «ROOF TRIM REPLACEMENT»(ref-675198-S35193998972014120400000) .
3. Remove the handsfree mic (A) after disconnecting the connector from roof top. CAUTION: Be careful not to damage the roof trim when removing the hands free mic. Do not reuse the mic unit if the fixing hook (A) is damaged.
4. Check the continuity of Mic between terminals.
