| Item | Specification | ||
|---|---|---|---|
| Model | RADIO/CD/MP3/SDARS (PA30AS) | UVO2/ Bristiol audio | |
| Internal Amplifier | |||
| Power supply | DC 14.4 V Negative ground | ||
| Output max power | 43W 4 : 14.4V | ||
| Load impedance (ohms) | 4 ohms x 4 | 4 ohms | |
| Antenna | 80 pF 75 ohms | ||
| Tuning type | PLL synthesized type | ||
| Dark current | Max.1.0mA (Head unit only) | Max. 3.0mA (Head unit only) | |
| Frequency range/Channel space | FM | 87.5 ~ 107.9 MHz/ 200 KHz | |
| AM | 530 ~ 1, 710 KHz/ 10 KHz | ||
Description
The multimedia jack on the console upper cover is for customers who like to listen to external portable music players like the MP3, iPod and etc., through the vehicle's sound system when it is linked to this jack. The customer has this added option. In case of distortions from media connected to the AUX source, the audio unit may not be defective but the output level of the used media does not match the specification of the AUX input.
Scheme 27
Scheme 28
- Remove the shift lever knob. (Refer to the " «CONSOLE»(ref-675054-S24429339762014120400000) ")
- Remove the console upper cover (A).
- Disconnect the connector from the console upper cover.
- Remove the multimedia jack (B) from the console under cover after releasing the fixed hooks (A).
