Audio System - Optima Hev: Other Kia Optima III рестайлинг

Entertainment Systems 25 illustrations ~710 words

Speaker

ItemPA30AUVO 2.0
Internal Amplifier
Input power (W or V)FrontMAX 40W
RearMAX 40W
MidrangeMAX 40W
Impedance (ohms)Front4±0.6
Rear
Midrange
Number of speaker6

Scheme 75

Scheme 75: Component Location
Scheme 75: Component Location

Scheme 76

Scheme 76: Components
Scheme 76: Components
Pin No.Connector A (18pin)Connector B (24pin)
1Rear left speaker (+)
2Front left speaker (+)
3Front right speaker (+)
4Rear right speaker (+)Steering remocon
5
6USB D (+)
7USB/iPod VDD
8Illumination (+)AUX right input
9DetentAUX ground
10Rear left speaker (-)MIC (+) (Bluetooth)
11Front left speaker (-)ACC
12Front right speaker (-)Battery (+)
13Rear right speaker (-)
14
15
16Speed
17Illumination (-)Remote ground
18Remote antennaUSB D (-)
19IPod/USB ground
20AUX Detect
21AUX left input
22MIC - (Bluetooth)
23
24Power ground

CONNECTOR PIN INFORMATION

Scheme 77

Scheme 77
Scheme 77
Pin No.Connector A (18pin)Connector B (24pin)USB connector (4pin)
1Rear left speaker (+)CAN highUSB/iPod ground
2Front left speaker (+)(TMu audio(+))USB D (-)/iPod Rx
3Front right speaker (+)(Temp.)USB D (+)/iPod Tx
4Rear right speaker (+)Steering wheel remoconUSB/iPod 5V
5
6Camera video input
7Camera battery(+)
8Illumination (+)AUX right input
9AUX ground
10Rear left speaker (-)MIC (+) (Bluetooth)
11Front left speaker (-)ACC
12Front right speaker (-)Battery (+)
13Rear right speaker (-)CAN low
14(TMu audio(-))
15AV tail
16Door unlockSpeed
17Illumination (-)Remocon ground
18Remote antennaCamera video ground
19Camera Req.
20AUX Detect
21AUX left input
22MIC - (Bluetooth)
23Camera power ground
24Power ground

CONNECTOR PIN INFORMATION (INTERNAL AMPLIFIER)

Scheme 78

Scheme 78
Scheme 78

Front Speaker

  1. Remove the front door trim panel and speaker connector. (Refer to the " «FRONT DOOR»(ref-675084-S18044142972014120400000) ")
  2. Remove the front speaker (A) after loosening 4 screws.

Scheme 79

Scheme 79
Scheme 79

Rear Speaker

  1. Remove the rear door trim panel and speaker connector. (Refer to the " «REAR DOOR»(ref-675084-S18251141812014120400000) ")
  2. Remove the rear speaker (A) after removing 4 screws.

Scheme 80

Scheme 80
Scheme 80

Scheme 81

Scheme 81: Crash Pad Midrange Speaker
Scheme 81: Crash Pad Midrange Speaker

Scheme 82

Scheme 82
Scheme 82
  1. Remove the main crash pad. (Refer to the " «CRASH PAD»(ref-675054-S40070926382014120400000) ")
  2. Disconnect the midrange speaker connector (A).
  3. Remove the crash pad side speaker grill (A).
  4. Remove the midrange speaker (A) after loosening the mounting screws.

Scheme 83

Scheme 83
Scheme 83

Subwoofer Speaker

  1. Remove the rear seat forward. (Refer to the " «REAR SEAT»(ref-675053-S22975831562014120400000) ")
  2. Remove the rear package tray. (Refer to the " «PACKAGE TRAY TRIM REPLACEMENT»(ref-675054-S21607188722014120400000) ")
  3. Disconnect the subwoofer speaker connector (A).
  4. Remove the subwoofer speaker (B) after removing 4 bolts.

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85: Center speaker
Scheme 85: Center speaker
  1. Remove the center speaker grill (A). NOTE: Apply the protective tapes to the speaker grill and its related parts.
  2. Remove the center speaker (A) after loosening the mounting screws.

Scheme 86

Scheme 86
Scheme 86
  1. Install the front speaker.
  2. Install the front door trim.
  1. Install the rear speaker.
  2. Install the rear door trim.

Crash pad midrange speaker

  1. Install the midrange speaker.
  2. Install the speaker grille.
  1. Install the subwoofer speaker after connecting the connector.
  2. Install the rear package tray and rear seat assembly.

External Amp

  1. Install the external amplifier after connecting the connector.
  2. Install the trunk right luggage side trim.

Note. Make sure the speaker and related connectors are plugged in properly.

Center speaker

  1. Install the center speaker.
  2. Install the center speaker grill.

Scheme 87

Scheme 87: Glass Antenna Test
Scheme 87: Glass Antenna Test
  1. Wrap aluminum foil (A) around the tip of the tester probe (B) as shown.
  2. Touch one tester probe to the glass antenna terminal (A) and move the other tester probe along the antenna wires to check that continuity exists.

Scheme 88

Scheme 88
Scheme 88

Glass Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch.

Scheme 89

Scheme 89: Glass Antenna Repair
Scheme 89: Glass Antenna Repair

Scheme 90

Scheme 90
Scheme 90
  1. Lightly rub the area around the broken section (A) with fine steel wool, and then clean it with alcohol.
  2. Carefully mask above and below the broken portion of the glass antenna wire (B) with cellophane tape (C).
  3. Using a small brush, apply a heavy coat of silver conductive paint (A) extending about 1/8" on both sides of the break. Allow 30 minutes to dry. NOTE: Thoroughly mix the paint before use.
  4. Check for continuity in the repaired wire.
  5. Apply a second coat of paint in the same way. Let it dry three hours before removing the tape.

Scheme 91

Scheme 91: Glass Antenna Circuit Inspection
Scheme 91: Glass Antenna Circuit Inspection

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93
  1. Remove the right side rear quarter trim. Then disconnect the antenna feeder cable (A) from the glass antenna amp.
  2. Turn the radio ON. Measure the voltage between the harness side feeder cable (A) and body ground (B). OK : approximately 12V (ACC+)
  3. Check for FM wire resistance between terminals of No. 1 and 3 FM antenna grid terminal AM antenna grid terminal Body ground. Standard value: 80~120Kohms Short: Approx. 0ohms Open: infinity ohms
  4. Check for AM wire resistance between terminals of No. 2 and 3. Standard value: 120~170Kohms Short: Approx. 0ohms Open: infinity ohms
  5. Check the grid lines for continuity.
  6. When a poor radio reception is not repaired through the above inspection methods, replace the amp. If the radio reception is still poor, check the radio cable for short and radio head unit for failure.

Scheme 94

Scheme 94: Antenna Cable
Scheme 94: Antenna Cable

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97
  1. Remove the antenna jack (A) from the audio unit and antenna.
  2. Check for continuity between the center poles of antenna cable.
  3. Check for continuity between the outer poles of antenna cable. There should be continuity.
  4. If there is no continuity, replace the antenna cable.
  5. Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
  6. If there is continuity, replace the antenna cable.

Scheme 98

Scheme 98: Removal
Scheme 98: Removal

Scheme 99

Scheme 99
Scheme 99
  1. Disconnect the battery (-) terminal.
  2. Remove the rear roof trim. (Refer to - " «ROOF TRIM»(ref-675054-S41611538432014120400000) ")
  3. Disconnect the connector (A) from the roof antenna.
  4. Remove the roof antenna (A) after removing a nut.
