Audio System - Optima: Other Kia Optima III рестайлинг

Entertainment Systems 26 illustrations ~720 words

Speaker

ItemPA30AUVO 2.0UVO 2.0
Internal AmplifierExternal Amplifier
Input power (W or V)FrontMAX 40WMAX 50W
RearMAX 40WMAX 50W
MidrangeMAX 40WMAX 50W
CenterMAX 50W
Sub wooferMAX 50W
Impedance (ohms)Front4.0 ± 0.62.0 ± 0.3
Rear4.0 ± 0.6
Midrange4.0 ± 0.6
Center
Sub woofer
Number of speaker68

ITEM SPECIFICATION CHART

Scheme 193

Scheme 193: Component Location
Scheme 193: Component Location

Scheme 194

Scheme 194: Components
Scheme 194: Components
Pin No.Connector A (18pin)Connector B (24pin)
1Rear left speaker (+)
2Front left speaker (+)
3Front right speaker (+)
4Rear right speaker (+)Steering remocon
5
6USB D (+)
7USB/iPod VDD
8Illumination (+)AUX right input
9DetentAUX ground
10Rear left speaker (-)MIC (+) (Bluetooth)
11Front left speaker (-)ACC
12Front right speaker (-)Battery (+)
13Rear right speaker (-)
14
15
16Speed
17Illumination (-)Remote ground
18Remote antennaUSB D (-)
19IPod/USB ground
20AUX Detect
21AUX left input
22MIC - (Bluetooth)
23
24Power ground

CONNECTOR PIN INFORMATION

Scheme 195

Scheme 195
Scheme 195
Pin No.Connector A (18pin)Connector B (24pin)USB connector (4pin)
1Rear left speaker (+)CAN highUSB/iPod ground
2Front left speaker (+)USB D (+)
3Front right speaker (+)(Temp.)USB D (-)
4Rear right speaker (+)(Rear remocon)USB/iPod 5V
5Camera video input
6Camera battery (+)
7USB/iPod VDD
8Illumination (+)AUX right input
9AUX ground
10Rear left speaker (-)MIC (+) (Bluetooth)
11Front left speaker (-)ACC
12Front right speaker (-)Battery (+)
13Rear right speaker (-)CAN low
14
15AV tail
16Door unlockSpeed
17Illumination (-)Camera video ground
18Remote antennaReverse
19IPod/USB ground
20AUX Detect
21AUX left input
22MIC - (Bluetooth)
23Camera power ground
24Power ground

CONNECTOR PIN INFORMATION (INTERNAL AMPLIFIER)

Scheme 196

Scheme 196
Scheme 196
Pin No.Connector A (18pin)Connector B (24pin)USB connector (4pin)
1CAN highUSB/iPod ground
2USB D (+)
3USB D (-)
4Steering remoconUSB/iPod 5V
5S/PDIF ground
6S/PDIF negative (-)Camera video input
7Camera battery (+)
8Illumination (+)AUX right input
9AUX ground
10)MIC (+) (Bluetooth)
11ACC
12Battery (+)
13CAN low
14
15S/PDIF positive (+)AV tail
16Door unlockSpeed
17Illumination (-)Remocon ground
18Remote antennaCamera video ground
19Reverse
20AUX Detect
21AUX left input
22MIC - (Bluetooth)
23Camera power ground
24Power ground

CONNECTOR PIN INFORMATION (EXTERNAL AMPLIFIER)

Scheme 197

Scheme 197
Scheme 197
Pin No.Connector A (26pin)Connector B (16pin)Connector C (12pin)
1Battery (+)Front right midrange speaker (+)Rear rigth door speaker (+)
2Battery (+)Front left midrange speaker (+)Rear left door speaker (+)
3Battery (+)Front right midrange speaker (+)
4Front left midrange speaker (+)
5M CAN highFront right door speaker (+)
6M CAN lowRear left door speaker (+)
7ACCFront center speaker (+)Rear right door speaker (-)
8Rear left door speaker (-)
9Front right midrange speaker (-)Front right midrange speaker (-)
10Front left midrange speaker (-)Front left midrange speaker (-)
11Navigation (+)Front right door speaker (-)
12Subwoofer 2 (+)Rear left door speaker (-)
13Subwoofer 1 (+)
14Ground
15GroundFront left midrange speaker (-)
16Ground
17
18SPDIF (+)
19SPDIF (-)
20SPDIF ground
21
22
23
24Navigation (-)
25Subwoofer 2 (-)
26Subwoofer 1 (-)

Connector Pin Information

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199

Front Speaker

  1. Install the front speaker.
  2. Install the front door trim.

Rear Speaker

  1. Install the rear speaker.
  2. Install the rear door trim.

Crash Pad Midrange Speaker

  1. Install the midrange speaker.
  2. Install the speaker grille.

Subwoofer Speaker

  1. Install the subwoofer speaker after connecting the connector.
  2. Install the rear package tray and rear seat assembly.

External Amp

  1. Install the external amplifier after connecting the connector.
  2. Install the trunk right luggage side trim. NOTE: Make sure the speaker and related connectors are plugged in properly.

Center Speaker

  1. Install the center speaker.
  2. Install the center speaker grill.

Scheme 200

Scheme 200: Glass Antenna Test
Scheme 200: Glass Antenna Test

Scheme 201

Scheme 201
Scheme 201
  1. Wrap aluminum foil (A) around the tip of the tester probe (B) as illustrated.
  2. Touch one tester probe to the glass antenna terminal (A) and move the other tester probe along the antenna wires to check that continuity exists.

Glass Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch.

Scheme 202

Scheme 202: Glass Antenna Repair
Scheme 202: Glass Antenna Repair

Scheme 203

Scheme 203
Scheme 203
  1. Lightly rub the area around the broken section (A) with fine steel wool, and then clean it with alcohol.
  2. Carefully mask above and below the broken portion of the glass antenna wire (B) with cellophane tape (C).
  3. Using a small brush, apply a heavy coat of silver conductive paint (A) extending about 1/8" on both sides of the break. Allow 30 minutes to dry. NOTE: Thoroughly mix the paint before use.
  4. Check for continuity in the repaired wire.
  5. Apply a second coat of paint in the same way. Let it dry three hours before removing the tape.

Scheme 204

Scheme 204: Glass Antenna Circuit Inspection
Scheme 204: Glass Antenna Circuit Inspection

Scheme 205

Scheme 205
Scheme 205

Scheme 206

Scheme 206
Scheme 206
  1. Remove the right side rear quarter trim. Then disconnect the antenna feeder cable (A) from the glass antenna amp.
  2. Turn the radio ON. Measure the voltage between the harness side feeder cable (A) and body ground (B). OK : approximately 12V (ACC+)
  3. Check for FM wire resistance between terminals of No. 1 and 3 FM antenna grid terminal AM antenna grid terminal Body ground. Standard value : 80~120Kohms Short : Approx. 0ohms Open : infinity ohms
  4. Check for AM wire resistance between terminals of No. 2 and 3. Standard value : 120~170Kohms Short : Approx. 0ohms Open : infinity ohms
  5. Check the grid lines for continuity.
  6. When a poor radio reception is not repaired through the above inspection methods, replace the amp. If the radio reception is still poor, check the radio cable for short and radio head unit for failure.

Scheme 207

Scheme 207: Antenna Cable
Scheme 207: Antenna Cable

Scheme 208

Scheme 208
Scheme 208

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210
  1. Remove the antenna jack (A) from the audio unit and antenna.
  2. Check for continuity between the center poles of antenna cable.
  3. Check for continuity between the outer poles of antenna cable. There should be continuity.
  4. If there is no continuity, replace the antenna cable.
  5. Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
  6. If there is continuity, replace the antenna cable.

Scheme 211

Scheme 211: Components
Scheme 211: Components
1. Audio & Drive mode switch3. Voice recognition switch
2. Trip & Cruise control switch4. Drive mode switch

Scheme 212

Scheme 212: Circuit Diagram
Scheme 212: Circuit Diagram

Scheme 213

Scheme 213
Scheme 213

Scheme 214

Scheme 214
Scheme 214

Scheme 215

Scheme 215: Inspection
Scheme 215: Inspection

Scheme 216

Scheme 216
Scheme 216

Scheme 217

Scheme 217
Scheme 217

Scheme 218

Scheme 218
Scheme 218
  1. Check the audio remote control switch (A) for resistance between connector terminals in each switch position. [Audio / Bluetooth] [Trip / Cruise] [Voice recognition] [ECO/ Trip/ Drive mode] CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Seek up 2-7 430ohms Seek down 2-7 1.11kohms Mode 2-7 2.11 kohms Mute 2-7 3.11 kohms Volume up 2-7 4.61 kohms Volume down 2-7 6.81 kohms Call off 2-7 18.91 kohms Call on 2-7 40.91 kohms [Trip] CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Trip 3-7 330ohms Trip up 3-7 550ohms Trip down 3-7 880ohms Select 3-7 1.44 kohms [Voice recognition] CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Voice Audio connector 2 & Voice recognition connector 3 10.71 kohms IMPORTANT: Information When checking voice recognition switch resistance, audio control switch and voice recognition switch should be connected. [ECO/ Trip/ Drive mode] CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Trip 2-4 330 ohms Trip up 2-4 550 ohms Trip down 2-4 880 ohms Select 2-4 1.44 kohms ECO 2-4 2.44 kohms Drive mode 2-4 5.54 kohms
