3.0l Diesel - Intermittent DTC, PCM Verification Test, Pcm/ecm/tcm Programming & Pre-Diagnostic Troubleshooting Procedure Jeep Grand Cherokee WK2

Testing & Diagnostics 1 illustration ~4383 words

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

DIAGNOSTIC TEST

  1. INTERMITTENT DTC WARNING: When the engine is operating, do not stand in direct line with the fan. Do not put your hands near the pulleys, belts, or fan. Do not wear loose clothing. Failure to follow these instructions can result in possible serious or fatal injury. The conditions necessary to set this DTC are not present at this time. Review the scan tool environmental data. If possible, try to duplicate the conditions under which the DTC set. If applicable, actuate the component with the scan tool. Monitor the scan tool data relative to this circuit and wiggle test the wiring and connectors. Look for the data to change, the actuation to be interrupted, or for the DTC to reset during the wiggle test. Perform any Technical Service Bulletins (TSBs) that may apply. Turn the ignition off. Visually inspect the related wire harness. Disconnect all the related harness connectors. Look for any chafed, pierced, pinched, partially broken wires and broken, bent, pushed out, or corroded terminals. Perform a voltage drop test on the related circuits between the suspected component and the PCM. Inspect and clean all Powertrain Control Module (PCM), engine, and chassis grounds that are related to the most current DTC. If numerous trouble codes were set, use a schematic and inspect any common ground or supply circuits. For intermittent Misfire DTCs check for restrictions in the intake and exhaust system, proper installation of sensors, vacuum leaks, and binding components that are run by the accessory drive belt. Use the scan tool to perform a System Test if one applies to the component. A co-pilot, data recorder, and/or lab scope should be used to help diagnose intermittent conditions. Were any problems found during the above inspections? Yes Perform the necessary repairs. Perform the «PCM VERIFICATION TEST»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . No Test Complete.

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. SELECT THE PROPER VERIFICATION TEST Select the verification test for the repair that has been completed: For a Speed Control repair Go To 2 . For a Charging System repair Go To 3 . For a No Start repair Go To 4 . For DTC and all other repairs Go To 5 .
  2. SPEED CONTROL VERIFICATION TEST Inspect the vehicle to make sure that all engine components are properly installed and connected. Reassemble and reconnect components as necessary. With the scan tool, erase all DTCs. Road test the vehicle at a speed above 60 km/h (35 MPH). Turn the speed control ON/OFF switch on. Depress and release the SET switch. If the speed control does not engage, the repair is not complete, continue with step 12. Quickly depress and release the RESUME/ACCEL switch. If the vehicle speed does not increase by 3 km/h (2 MPH), the repair is not complete, continue with step 12. Using caution, depress and release the brake pedal. If the speed control does not disengage, the repair is not complete, continue with step 12. With the vehicle speed at least 60 km/h (35 MPH), depress the RESUME/ACCEL switch. If the speed control does not resume at the previously set speed, the repair is not complete, continue with step 12. Hold down the COAST switch. If the vehicle does not decelerate, the repair is not complete, continue with step 12. While still holding down the COAST switch, make sure the vehicle speed is at least 60 km/h (35 MPH) and release the COAST switch. If the vehicle does not adjust and set a new vehicle speed, the repair is not complete, continue with step 12. With the speed control engaged, depress the ON/OFF switch. If the speed control does not disengage, the repair is not complete, continue with step 12. If the vehicle did not successfully perform all of the previous steps, perform any Technical Service Bulletins (TSBs) that may relate to this condition, if necessary, return to the DTC List. If the vehicle successfully performed all of the previous steps, the speed control system is now functioning as designed. The repair is now complete. Are any DTCs or symptoms remaining? Yes Repair is not complete, perform the appropriate diagnostic procedure. No Repair is complete.
  3. CHARGING SYSTEM VERIFICATION TEST Inspect the vehicle to make sure that all engine components are properly installed and connected. Reassemble and reconnect components as necessary. With the scan tool, erase all DTCs. Start the engine. Raise the engine speed to 2000 RPM for at least 30 seconds. Allow the engine to idle. Turn the ignition off for 20 seconds. Turn the ignition on. With the scan tool, read PCM DTCs. If this DTC has set again, or another DTC has set, perform any Technical Service Bulletins (TSBs) that may relate to this condition. Return to the DTC List if necessary. If the charging system is functioning correctly and there are no DTCs, the repair is now complete. Are any DTCs or symptoms remaining? Yes Repair is not complete, perform the appropriate diagnostic procedure. No Repair is complete.
  4. NO START VERIFICATION TEST NOTE: IMPORTANT! If the Wireless Control Module/Wireless Ignition Node has been replaced, make sure the programming procedure for the module has been performed in accordance with the service information. NOTE: If the Powertrain Control Module (PCM) has been replaced, Go to «SECTION 2 - ADDITIONAL PCM/ECM / TCM REPLACEMENT PROCEDURES»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__section-2-additional-pcmecm) of the PCM/PCM REPROGRAMMING, and perform the necessary routines. . Inspect the vehicle to make sure that all engine components are properly installed and connected. Reassemble and reconnect components as necessary. Inspect the engine oil for contamination. If it is contaminated, change the oil and filter. With the scan tool, erase all DTCs. Turn the ignition off for at least 10 seconds. Attempt to start the engine. If the engine is unable to start, perform any Technical Service Bulletins (TSBs) that may relate to this condition. Return to the DTC List if necessary. If the engine starts and continues to run, the repair is now complete. Are any DTCs or symptoms remaining? Yes Repair is not complete, perform the appropriate diagnostic procedure. No Repair is complete.
  5. DTC/ROAD TEST VERIFICATION TEST Inspect the vehicle to make sure that all engine components are properly installed and connected. Reassemble and reconnect components as necessary. If this verification procedure is being performed after a non-DTC test, perform steps 3 and 4. If not, proceed to step 5. Check to see if the initial symptom still exists. If there are no trouble codes and the symptom no longer exists, the repair was successful and testing is now complete. If the initial or another symptom exists, the repair is not complete. Check all pertinent Technical Service Bulletins (TSBs) and return to the DTC List if necessary. For previously read DTCs that have not been dealt with, return to the DTC List and follow the diagnostic path for that DTC; otherwise, continue to step 6. If the Powertrain Control Module (PCM) has been replaced, Go to «SECTION 2 - ADDITIONAL PCM/ECM / TCM REPLACEMENT PROCEDURES»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__section-2-additional-pcmecm) of the PCM/PCM REPROGRAMMING, and perform the necessary routines. . Then continue to step 7. If equipped with a Transfer Case Position Switch, perform step 8, otherwise, continue with step 9. With the ignition switch on, place the Transfer Case Shift Lever in each gear position, stopping for 15 seconds in each position. With the scan tool, erase all diagnostic trouble codes (DTCs). Road test the vehicle. Drive the vehicle under various driving conditions. Attempt to duplicate the conditions in the Freeze Frame Data under which the DTC was set if possible. If this test is for an A/C Relay Control Circuit, drive the vehicle for at least five minutes with the A/C on. At some point, stop the vehicle and turn the engine off for at least 10 seconds, then restart the engine and continue driving. Upon completion of the road test, check for DTCs with the scan tool. If the repaired DTC has returned, the repair is not complete. Check for any related Technical Service Bulletins (TSBs) and return to the DTC List. If there are no DTCs, the repair was successful and is now complete. Are any DTCs or symptoms remaining? Yes Repair is not complete, perform the appropriate diagnostic procedure. No Repair is complete.

PCM/ECM / TCM FLASH PROGRAMING

This procedure will need to be done when one or more of the following situations are true

  1. A vehicle's Powertrain Control Module/Engine Control Module (PCM/ECM) has been replaced.
  2. A diagnostic trouble code (DTC) is set P1602 - PCM/ECM Not Programmed.
  3. An updated calibration or software release is available for either the PCM/ECM or TCM ECUs.

This procedure assumes that the wiTECH™ Vehicle Connection Interface (VCI) pod, StarSCAN® and StarMOBILE® devices are configured to your dealership's network with either a wired or wireless connection. The wiTECH™ VCI pod, StarSCAN® and StarMOBILE® must also be running at the latest operating system and software release level. For more help on how to network your StarSCAN® or StarMOBILE® reference the StarSCAN® / StarMOBILE® Quick Start Networking Guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the Download Center. For the wiTECH™ VCI pod use the "HELP" tab in the wiTECH™ Diagnostic Application.

TABLE OF CONTENTS

  1. Refer to «SECTION 1 - PCM/ECM / TCM FLASH PROCEDURE»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__section-1-pcmecm-tcm) .
  2. Refer to «REQUIRED TOOLS / EQUIPMENT»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__required-tools-equipment)
  3. Refer to «TECH TIPS AND INFORMATION»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__tech-tips-and-information)
  4. Refer to «PARTS REQUIRED»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__parts-required) .

SECTION 1 - PCM/ECM / TCM FLASH PROCEDURE

If using StarSCAN® or StarMOBILE® Desktop Client. Go to REPAIR PROCEDURE - USING STARSCAN® OR STARMOBILE® DESKTOP CLIENT .

If using wiTECH™ Diagnostic Application. Go to REPAIR PROCEDURE - WITECH™ DIAGNOSTIC APPLICATION .

REPAIR PROCEDURE - USING STARSCAN® OR STARMOBILE® DESKTOP CLIENT

Note. If this flash process is interrupted or aborted, the flash should be restarted.

  1. Open the hood of the vehicle and install a battery charger. Verify that the charging rate provides a continuous charge of 13.2 - 13.5 Volts.
  2. Connect the StarSCAN® or StarMOBILE® to the vehicle data link connector located under the steering column and turn the ignition key to the "RUN" position.
  3. Power on the StarSCAN® or StarMOBILE®. If the StarMOBILE® is being used, launch the StarMOBILE® Desktop Client and connect to the appropriate StarMOBILE® device.
  4. Retrieve the old ECU part number. From the tool's Home screen, Select "ECU View" Select "PCM/ECM" Select "More Options" Select "ECU Flash" Record the part number at the top of the Flash PCM/ECM screen for later reference.
  5. Program the ECU as follows: Using the StarSCAN® / StarMOBILE® at the Home screen, select "ECU View" Select "PCM/ECM" Select "More Options" Select "ECU Flash" Select "Browse for New File" and follow the on screen instructions Highlight the appropriate calibration based on the part number recorded in Step 4 e , or by using Year/Model/Engine and appropriate emissions selection for the vehicle being worked on Select "Download to Client/Scantool" Once the download is complete, select "Close" and then "Back" Highlight the listed calibration, select "Update Controller" and follow the on screen instructions When the PCM/ECM update is complete, select "OK" Verify that the part number at the top of the Flash PCM/ECM screen has updated to the new part number NOTE: If this flash process is interrupted or aborted, the flash should be restarted.
  6. Continue to complete the process if the ECU has been replaced.
  7. Type the necessary information on the "Authorized Modification Label" (p/n 04275086AB) and attach near the VECI label (See Section 3 for details). Refer to «SECTION 3 - AUTHORIZED MODIFCATION LABEL»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__section-3-authorized-modifcation-label) .

REPAIR PROCEDURE - WITECH™ DIAGNOSTIC APPLICATION

Note. If this flash process is interrupted or aborted, the flash should be restarted.

  1. Open the hood of the vehicle and install a battery charger. Verify that the charging rate provides a continuous charge of 13.2 - 13.5 Volts.
  2. Connect the wiTECH™ Vehicle Connection Interface (VCI) pod to the vehicle data link connector located under the steering column and turn the ignition key to the "RUN" position.
  3. Launch the wiTECH™ Diagnostic Application and connect to the appropriate wiTECH™ device.
  4. From the wiTECH™ Diagnostic Application Home screen, Select "HELP" Select "HELP CONTENTS" Follow the "HELP TOPIC" for flashing an ECU.

SECTION 2 - ADDITIONAL PCM/ECM / TCM REPLACEMENT PROCEDURES

Note. Find the PCM/ECM /TCM Type for the vehicle, read and write down the steps, and then go to the step by step instructions for additional information on how to perform these procedures. Refer to STEP-BY-STEP INSTRUCTIONS .

If a 2.0L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. ECU Replacement With Value Transfer - if the ECU to be replaced is still responsive NOTE: If the PCM/ECM data transfer is able to be completed, it may not be necessary to perform routines 7 - 9.
  3. ECU Replacement Without Value Transfer - if the ECU to be replaced is NOT responsive
  4. Verify PCM/ECM VIN
  5. Injector Quantity Adjustment
  6. Program Variant Code
  7. Service Diesel Particulate Filter Regeneration
  8. Reset Zero Fuel
  9. Reset of Lambda Values

If a PT Cruiser, 2.2L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. Injector Quantity Adjustment - Only on 06 PT AND up
  3. IMA Rapid Calibration Test - Only on 06 PT AND up

If a 3.0L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. ECU Replacement With Value Transfer - if the ECU to be replaced is still responsive NOTE: If the PCM/ECM data transfer is able to be completed, it may not be necessary to perform routines 7 - 12.
  3. ECU Replacement Without Value Transfer - if the ECU to be replaced is NOT responsive
  4. Injector Quantity Adjustment
  5. Program Variant Code
  6. Verify PCM/ECM VIN
  7. Diesel Particulate Filter (Used) Learning
  8. Reset of Lambda Values
  9. Reset Zero Fuel
  10. NOx Catalyst (New) Initialization
  11. IMA Rapid Calibration Test
  12. Fuel Mean Value Adaptation Initialization
  13. Exhaust Throttle Plate Adaptive Learn Position

If a 2.8L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. ECU Replacement With Value Transfer - if the ECU to be replaced is still responsive NOTE: If the PCM/ECM data transfer is able to be completed, it may not be necessary to perform routines 6 - 8.
  3. ECU Replacement Without Value Transfer - if the ECU to be replaced is NOT responsive
  4. Injector Quantity Adjustment
  5. Program Variant Code
  6. Fuel Mean Value Adaptation Initialization
  7. IMA Rapid Calibration Test
  8. Set Oil Dilution Mass Value

If a PM/MK, 2.2L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. Engine ECU Replacement NOTE: If the PCM/ECM data transfer is able to be completed, it may not be necessary to perform routines 5 - 10.
  3. Injector Quantity Adjustment
  4. Program Variant Code
  5. Swirl Control Learn
  6. Throttle Valve Learn
  7. VGT Learn
  8. MAF Sensor Replace
  9. O2 Sensor Replace
  10. Used DPF initialize

If a 5.9L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. Check PCM/ECM VIN - if NOT WCM equipped

If a 6.7L Controller was replaced, navigate to "Misc. Functions" and perform all applicable routines

Note. The available routines may vary depending on model and year of vehicle.

  1. PCM/ECM Replaced - Located within the Security Module
  2. Injector Quantity Adjustment
  3. Enable / Disable Vehicle Features - need to enable features
  4. Set max vehicle speed
  5. Set max cruise speed
  6. Idle shutdown timer
  7. PTO RPM adjustment
  8. Set PTO Max vehicle speed NOTE: The numbers can be retrieved from the old PCM/ECM using the scan tool if the PCM/ECM is still functional or they may be retrieved from the Fuel Injectors themselves. The numbers are stamped on the intake manifold side of the injectors.
  9. Reset Regenerative Filter Timers

TCM Replacement

If an Aisin TCM was replaced, perform the following additional steps and/or routines

If an EATX TCM was replaced, perform the following additional steps and/or routines

If an NGC3 TCM ONLY was replaced, perform the following additional steps and/or routines

If an NGC4 TCM ONLY was replaced, perform the following additional steps and/or routines

  1. Quicklearn, refer to «STEP-BY-STEP INSTRUCTIONS»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__step-by-step-instructions) .

If an EGS TCM was replaced, perform the following additional steps and/or routines

  1. Initialize EGS, refer to «STEP-BY-STEP INSTRUCTIONS»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure__step-by-step-instructions) .

STEP-BY-STEP INSTRUCTIONS

PCM/ECM Replaced

The vehicle pin (Personal Identification Number) will be required to complete the routine. This information may be obtained in three ways

  1. The original selling invoice
  2. DealerCONNECT > Parts > Key Codes
  3. Contacting the District Manager.

From the "Home" screen, select "ECU View"

  1. Select the applicable Security Module
  2. Select "Misc. Functions"
  3. Select "PCM/ECM Replaced" and follow the on screen instructions.
  4. When complete, select "Finish"

Check PCM VIN

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Check PCM/ECM VIN" and follow the on screen instructions.
  4. When complete, select "Finish"

Diesel Particulate Filter (Used) Learning

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Diesel Particulate Filter (Used) Learning" and follow the on screen instructions.
  4. When complete, select "Finish"

ECU Replacement with Value Transfer

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "ECU Replacement with Value Transfer" and follow the on screen instructions.
  4. When complete, select "Finish"

ECU Replacement without Value Transfer

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "ECU Replacement without Value Transfer" and follow the on screen instructions.
  4. When complete, select "Finish"

Enable / Disable Vehicle Features

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Enable / Disable Vehicle Features" and follow the on screen instructions.
  4. When complete, select "Finish"

Exhaust Throttle Plate Adaptive Learn Position

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Exhaust Throttle Plate Adaptive Learn Position" and follow the on screen instructions.
  4. When complete, select "Finish"

Fuel Mean Value Adaptation Initialization

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Fuel Mean Value Adaptation Initialization" and follow the on screen instructions.
  4. When complete, select "Finish"

IMA Rapid Calibration

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "IMA Rapid Calibration Test" and follow the on screen instructions.
  4. When complete, select "Finish"

Initialize EGS

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Initialize EGS" and follow the on screen instructions.
  4. When complete, select "Finish"

Injector Quantity Adjustment

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Injector Quantity Adjustment" and follow the on screen instructions.
  4. When complete, select "Finish"

Mobile DeSoot - NO Minimum Required Soot Load

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Mobile DeSoot - NO Minimum Required Soot Load" and follow the on screen instructions.
  4. When complete, select "Finish"

NOx Catalyst (New) Initialization

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "NOx Catalyst (New) Initialization" and follow the on screen instructions.
  4. When complete, select "Finish"

Program Variant Code

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Program Variant Code" and follow the on screen instructions.
  4. When complete, select "Finish"

Quicklearn

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Quicklearn" and follow the on screen instructions.
  4. When complete, select "Finish"

Reset Regenerative Filter Timers

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Reset Regenerative Filter Times" and follow the on screen instructions.
  4. When complete, select "Finish"

Set Oil Dilution Mass Value

From the "Home" screen, select "ECU View"

  1. Select "PCM/ECM"
  2. Select "Misc. Functions"
  3. Select "Set Oil Dilution Mass Value" and follow the on screen instructions.
  4. When complete, select "Finish"

SECTION 3 - AUTHORIZED MODIFCATION LABEL

Note. The following step is required by law when reprogramming a PCM/ECM and/or TCM.

Type the necessary information on the "Authorized Modification Label" and attach near the VECI label.

Scheme 725

Scheme 725: SECTION 3 - AUTHORIZED MODIFCATION LABEL
Scheme 725: SECTION 3 - AUTHORIZED MODIFCATION LABEL
  1. Powertrain Control / Transmission Control Module Part Numbers (Insert P/Ns) Used
  2. Change Authority: TSB XX--XX
  3. Dealer Code: XXXXX
  4. Date: XX-XX-XX

REQUIRED TOOLS / EQUIPMENT

StarSCAN®StarMOBILE®WiTECH™
Battery ChargerBattery ChargerBattery Charger
StarSCAN® Tool KitStarMOBILE® Tool KitWiTECH™ Tool Kit
StarSCAN® Vehicle CableStarMOBILE® Vehicle CableWiTECH™ Vehicle Cable
TechCONNECT PC or equivalentTechCONNECT PC or equivalent
WiTECH™ Diagnostic Application

TECH TIPS AND INFORMATION

CAUTIONExtreme care must be taken when programming a calibration into a generic PCM. Do not randomly select a calibration. Once a calibration is selected and programmed, the controller cannot be reprogrammed to a different calibration. The module can only be reprogrammed to a more recent version of that calibration.
  1. The wiTECH™ Diagnostic Application is the preferred method for flashing any Chrysler vehicle ECU. For more information, training tutorials are available under the "HELP" tab in the wiTECH™ Diagnostic Application or at www.dcctools.com, under the 'Training Aids' link.
  2. To use the StarMOBILE® in Pass-Through Mode requires that your StarMOBILE® is connected to the dealership's network via a wired or wireless connection. For more information on how to use the StarMOBILE in Pass-Through Mode see the StarMOBILE® training tutorials available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Training Aids' link or at www.dcctools.com, under the 'Training Aids' link.
  3. If the flash process is interrupted or aborted, the flash should be restarted.
  4. Due to the PCM/ECM / TCM programming procedure, a DTC may be set in other ECUs within the vehicle. Some DTCs may cause the MIL to illuminate. From the "Home" screen select "System View". Then select "All DTCs". Press "Clear All Stored DTCs" if there are any DTCs shown on the list.
  5. Do not allow the battery charger to time out or the charging rate to climb above 13.5 Volts during the flash process.
  6. The StarSCAN® and StarMOBILE® diagnostic tools fully support Internet connectivity and must be configured for your dealership's network. For help on setting up your StarSCAN® / StarMOBILE® for the dealership's network, refer to the StarSCAN® / StarMOBILE® Quick Start Networking Guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the download center.
  7. The operating software in the StarSCAN® and StarMOBILE® must be programmed with the latest software release level. The software level is visible in the blue header at the top of the StarSCAN® and StarMOBILE® Desktop Client screens. For instructions on how to update your scan tool, refer to the StarSCAN® / StarMOBILE® Software Update guide available on 'DealerCONNECT > Service > StarSCAN® and StarMOBILE® Tools > Online Documentation' or at www.dcctools.com, under the download center.

PARTS REQUIRED

QtyPart NumberDESCRIPTION
104275086ABLabel, Authorized Modification

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

  1. NO RESPONSE NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Does the scan tool display a Vehicle Network problem or NO RESPONSE condition? Yes Perform the appropriate No Response diagnostic procedure. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/communication-devices/#communication-non-dtc-based-diagnostics) . No Go To 2 .
  2. NO START Does the vehicle have a NO START condition? Yes Check the vehicle for any DTCs, including Vehicle Theft Security related DTCs, which may cause a no-start condition. If no DTCs are present that relate to a no-start condition, for procedures related to Fuel and Starting systems. Refer to «DIAGNOSIS AND TESTING»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#driveability-diesel-non-dtc-based-diagnostics) . No Go To 3 .
  3. VEHICLE REPAIR HISTORY AND TSB(s) Check the vehicle repair history for repairs that may relate to the current condition. Inspect the vehicle for aftermarket accessories that may have been installed incorrectly. Check for any Technical Service Bulletins (TSBs) related to the condition or DTCs. If a TSB applies, follow the procedure outlined in the TSB. Select the appropriate response for the condition that applies: Performing a TSB procedure repaired the condition. Test Complete. Perform the «PCM VERIFICATION TEST»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . A DTC is present, no TSB applies, or the TSB didn't repair the condition. Go To 4 . No DTCs or conditions are present. Perform the «INTERMITTENT DTC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) diagnostic procedure. .
  4. VEHICLE INSPECTION Based on the diagnostic condition that applies, review the following list and perform any tests that relate to the condition: If multiple DTCs are set in the PCM, review the wiring schematics for problems in any shared supply or ground circuits. Perform the «CHECKING THE PCM POWER AND GROUND CIRCUITS»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#driveability-diesel-non-dtc-based-diagnostics) and perform the diagnostic procedure. Inspect the air intake system and turbocharger related tubes for damage, restrictions, or poor connections. Inspect the exhaust system and related tubes for damage, restrictions, or poor connections. Remove and inspect the Air Filter for soiling or excessive dirt and debris which may cause an air flow restriction. If the PCM detects and stores a DTC, the PCM also stores the environmental conditions under which the DTC was set. Before erasing stored DTCs, record these conditions. Attempting to duplicate these conditions may assist when checking for an active DTC. Using the scan tool, Clear the stored DTCs. Attempt to duplicate the environmental conditions under which the DTC was set. Review the DTC When Monitored and Set Conditions. If possible, try to duplicate the vehicle conditions under which the DTC conditions will be monitored. Operate the vehicle under those conditions. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors between the component and the module. If the DTCs are fuel or air handling system related, check the fuel level and quality. Were any repairs made that corrected the DTC or condition? Yes Test complete. Perform the «PCM VERIFICATION TEST»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . No Refer to «DIAGNOSTIC CODE INDEX»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-diagnostic-code-index) article and perform the appropriate diagnostic procedure. If DTC or condition is intermittent, refer to «INTERMITTENT DTC»(/jeep/grand-cherokee/wk2-2010-2013/remont/testing-diagnostics/#30l-diesel-intermittent-dtc-pcm-verification-test-pcmecmtcm-programming-pre-diagnostic-troubleshooting-procedure) . .

More articles — Engine Performance
