Multifunction Electronic Modules: Removal & Installation Jaguar XKR I рестайлинг

Installation

1. To install, reverse the removal procedure.

Scheme 27

Scheme 28

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Remove the trim pad from the door; refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-311064) .
4. Remove the door speaker from the door. Remove the four bolts which secure the speaker.
5. Disconnect and remove the speaker. Support the speaker, disconnect the multi-plug and remove the speaker.
6. Disconnect the door module. Remove the three screws which secure the module to the door. Reposition the module outwards through the speaker aperture.
7. Disconnect the harness from the module. Disconnect the two multi-plugs. Remove the module.
8. If necessary remove the foam gasket from the module; note that a new gasket must be fitted when installing a new module.

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034) .

Removal

1. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.
2. Detach the driver seat module (DSM) and mounting bracket.
3. Remove the DSM and mounting bracket. Disconnect the electrical connectors.
4. Remove the DSM

1. To install, reverse the removal procedure. Tighten to 7 Nm.
2. Tighten to 4 Nm.
3. Carry out the battery reconnection procedure. Refer to «Battery, Mounting and Cables»(ref-311034) article.

1. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.
2. Remove the passenger side register duct.
3. Remove the glove compartment shelf.
4. Disconnect the multifunction electronic module electrical connector.
5. Remove the multifunction electronic module. Remove the three nuts which secure the module to the instrument panel. Remove the multifunction electronic module.

1. To install, reverse the removal procedure.
2. Connect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Remove the trim pad from the door; refer to «INTERIOR TRIM AND ORNAMENTATION»(ref-311064) .
4. Remove the door speaker from the door. Remove the four bolts which secure the speaker.
5. Disconnect and remove the speaker. Support the speaker, disconnect the multi-plug and remove the speaker.
6. Disconnect the door module. Remove the three screws which secure the module to the door. Reposition the module outwards through the speaker aperture.
7. Disconnect the harness from the module. Disconnect the two multi-plugs. Remove the module.
8. If necessary remove the foam gasket from the module; note that a new gasket must be fitted when installing a new module.

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034) .

1. Disconnect the battery ground cable. Refer to «Battery, Mounting and Cables»(ref-311034) article.
2. Detach the passenger seat module (PSM) and mounting bracket.
3. Remove the PSM and mounting bracket. Disconnect the electrical connectors.
4. Remove the PSM.

1. To install, reverse the removal procedure. Tighten to 7 Nm.
2. Tighten to 4 Nm.
