Location of J1962 socket
The J1962 socket is located on the fascia, adjacent to the 'A' pillar on the driver side.
Scheme 17
Scheme 17: Module Location
| Item Number | Description |
|---|
| 1 | Passive anti-theft system (PATS) module |
| 2 | Head restraint control module |
| 3 | Speed control module - vehicles with adaptive speed control |
| 4 | Anti-lock brake system (ABS) module |
| 5 | Ballast and headlamp leveling module |
| 6 | Engine control module (ECM) |
| 7 | Driver door module (DDM) |
Scheme 18
Scheme 18: Module Location
| Item Number | Description |
|---|
| 1 | Multifunction electronic control module |
| 2 | Instrument cluster |
| 3 | Climate control module |
| 4 | Anti-theft alarm and double locking module |
| 5 | Parking aid module |
| 6 | Adaptive damping module |
| 7 | Driver seat module (DSM) |
| 8 | Restraints control module (RCM) |
| 9 | Transmission control switch and selector lever indicator assembly |
| 10 | Passenger door module (PDM) |
