Module Communications Network: Removal & Installation Jaguar XKR I рестайлинг

Installation

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034-S21423005392009032300000) .

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Remove the cover from the fuse-box. Release the securing tangs of the cover. Remove the cover from the fuse-box housing.
4. Remove the positive supply power cable. Reposition the cover from the positive cable. Remove the nut which secures the positive cable to the fuse-box. Disconnect the positive power cable.
5. Remove the fuse-box from the mounting panel. Release the securing latch, upwards. Reposition the fuse-box, inwards. Remove the fuse-box from the mounting panel.
6. Remove the fuse-box. Identify and disconnect the harness multi-plugs from the fuse-box. Remove the fuse-box from the vehicle.
7. Remove the fuses and relays. Note the position of each relay and remove them. Identify each fuse and remove them. The value and position of each fuse is illustrated on the lid of the luggage compartment fuse-box - for all fuse-boxes on the vehicle.

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034) .

Scheme 10

Scheme 11

Scheme 12

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Remove the cover from the fuse-box.
4. Remove the glovebox assembly, for access to the connectors. Refer to «INSTRUMENT PANEL AND CONSOLE»(ref-311041) .
5. From behind the fuse-box (in the glovebox area) disconnect the harness multi-plug.
6. Remove the positive supply power cable. Remove the nut which secures the positive cable to the fuse-box. Disconnect the positive power cable.
7. Remove the fuse-box. Remove the two nuts which secure the fuse-box to the fascia. Remove the fuse-box from the vehicle.
8. Remove the fuses and relay. Remove the relay. Identify each fuse and remove them. The value and position of each fuse is illustrated on the lid of the luggage compartment fuse-box - for all fuse-boxes on the vehicle.

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034) .

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Remove the cover from the fuse-box.
4. Remove the underscuttle assembly, for access to the connectors. Refer to «Instrument Panel and Console»(ref-311041) .
5. From behind the fuse-box (in the underscuttle area) disconnect the harness multi-plug.
6. Remove the positive supply power cable. Remove the nut which secures the positive cable to the fuse-box. Disconnect the positive power cable.
7. Remove the fuse-box. Remove the two nuts which secure the fuse-box to the fascia. Remove the fuse-box from the vehicle.
8. Remove the fuses and relay. Remove the relay. Identify each fuse and remove them. The value and position of each fuse is illustrated on the lid of the luggage compartment fuse-box - for all fuse-boxes on the vehicle.

1. Installation is the reverse of removal.
2. Perform the Battery Reconnection Procedure described in «BATTERY, MOUNTING AND CABLES»(ref-311034) .
