Module Communications Network: Diagnosis Jaguar XKR I рестайлинг

Inspection and Verification

1. Verify the customer concern.
2. Confirm which, if any, warning lights and/or messages were displayed on the instrument cluster. NOTE: If any warning lights and/or messages were displayed when the fault occurred, refer to «Driver Information Chart»(ref-311038-S21767481822009032300000) for DTCs associated with the display, then to the DTC index table for possible sources and actions. Some warnings will appear to clear when the ignition is cycled. This is often because the warning has flagged as a result of one of the vehicle's on-board diagnostic routines having run to detect the fault. If the same routine is not run when the ignition is switched ON , the warning will not reflag until the routine does run. See the DTC summaries for drive cycle routines.
3. Visually inspect for obvious signs of mechanical or electrical damage. Visual Inspection Chart Electrical General Fuses (see table) Wiring harness Correct engagement of electrical connectors Loose or corroded connections Controller Area Network (CAN) Instrument Cluster (IC) Engine control module (ECM) Dynamic Stability Control Module (DSCCM) Transmission Control Module (TCM) Adaptive Speed Control Module (ASCCM) Linear Switch Module J-Gate illumination Module Standard Corporate Protocol (SCP) Instrument Cluster (IC) Body Processor Module (BPM) Security and Locking Control Module (SLCM) Passenger Door Control Module (PDCM) Driver Door Control Module (DDCM) Passenger Head Restraint Control Module (PHRCM) Passenger Seat Control Module (PSCM) Driver Seat Control Module (DSCM) Driver Head Restraint Control Module (DHRCM) International Standards Organization (ISO) Restraints Control Module (RCM) Parking Aid Control Module (PACM) Adaptive Damping Control Module (ADCM) Engine Control Module (ECM) Left-hand High Intensity Discharge Headlamp Assembly (HID) Right-hand High Intensity Discharge Headlamp Assembly (HID) Key Transponder Module (KTM) Air Conditioning Control Module (A/CCM) Body Processor Module (BPM) Active Security Sounder (ROW only) Fuse Identification Chart Fuse Rating Circuit Location 10 10 Amp Engine Control Module EMS fuse box, passenger side within bulkhead extension 04 5 Amp Main Instrument Cluster Facia fuse box, passenger side 06 5 Amp Key Transponder Module Facia fuse box, passenger side 07 15 Amp Body Processor Module Facia fuse box, passenger side 08 10 Amp Driver's Headrest Control Module Facia fuse box, passenger side 10 10 Amp Airbag Control Module Facia fuse box, passenger side 13 5 Amp Diagnostic Connector (battery) Facia fuse box, passenger side 14 10 Amp Main Instrument Cluster Facia fuse box, passenger side 15 25 Amp Driver's Door Control Module Facia fuse box, passenger side 16 5 Amp Linear Switch Module Facia fuse box, passenger side 18 10 Amp Engine Control Module Facia fuse box, passenger side 01 20 Amp Passenger Seat Control Module Facia fuse box, driver's side 06 10 Amp Air Conditioning Control Module Facia fuse box, driver's side 07 20 Amp Body Processor Module Facia fuse box, driver's side 08 10 Amp Passenger Headrest Control Module Facia fuse box, driver's side 15 25 Amp Passenger Door Control Module Facia fuse box, driver's side 17 15 Amp Body Processor Module Facia fuse box, driver's side 01 10 Amp Transmission Control Module Engine Compartment fuse box, Left-hand side 03 5 Amp Security Sounder/HID modules Engine Compartment fuse box, Left-hand side 04 5 Amp Dynamic Stability Control Module Engine Compartment fuse box, Left-hand side 06 20 Amp Right-hand HID Engine Compartment fuse box, Left-hand side 08 20 Amp Left-hand HID Engine Compartment fuse box, Left-hand side 09 10 Amp Security Sounder Engine Compartment fuse box, Left-hand side 19 10 Amp Right-hand HID Engine Compartment fuse box, Left-hand side 21 10 Amp Left-hand HID Engine Compartment fuse box, Left-hand side 22 5 Amp Adaptive Speed Control Module Engine Compartment fuse box, Left-hand side 02 20 Amp Adaptive Speed Control Module Luggage compartment fuse box 03 5 Amp Diagnostic Connector (ignition) Luggage compartment fuse box 04 5 Amp Adaptive Damping Control Module Luggage compartment fuse box 06 5 Amp Security and Locking Control Module Luggage compartment fuse box 10 10 Amp Security and Locking Control Module Luggage compartment fuse box 13 5 Amp Reverse Aid, Navigation, DVD unit, TV, VICS (Japan) Luggage compartment fuse box 16 5 Amp Navigation, TV and VICS (Japan) Luggage compartment fuse box

1. Where the Jaguar approved diagnostic system is available, complete the S93 report before clearing any or all fault codes from the vehicle. NOTE: If a DTC cannot be cleared, then there is a permanent fault present that flags again as soon as it is cleared. (The exception to this is P1260, which will only clear following an ignition OFF , wait one minute, ignition ON cycle after rectification.)
2. If the cause is not visually evident and the Jaguar approved diagnostic system is not available, use a scan tool to retrieve the fault codes before proceeding to the Diagnostic Trouble Code (DTC) Index Chart, or the Symptom Chart if no DTCs are set.
3. Using the Jaguar approved diagnostic system where available, and a scan tool where not, check the freeze frame data for information on the conditions applicable when the fault was flagged. The format of this will vary, depending on the tool used, but can provide information useful to the technician in diagnosing the fault. CAUTION: Diagnosis by substitution from a donor vehicle is Not acceptable. Each vehicle is configured to it's own VID block, and substitution of control modules may not only not confirm a fault, but may cause faults in the vehicle being tested and/or the donor vehicle. CAUTION: Electronic modules are sensitive to static electrical charges. If exposed to these charges, damage may result. CAUTION: When probing connectors to take measurements in the course of the pinpoint tests, use the adaptor kit, part number 3548-1358-00. NOTE: When performing electrical voltage or resistance tests, always use a digital multimeter (DMM) accurate to 3 decimal places, and with an up-to-date calibration certificate. When testing resistance, always take the resistance of the DMM leads into account. NOTE: Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.
4. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step
5. If the cause is not visually evident, verify the symptom and refer to «Diagnostic Trouble Code (DTC) index»(ref-311038-S11748755612009032300000) .

Diagnostic Trouble Code (DTC) index

Power Supply/Ground test index

Pinpoint Test A: CHECK THE CONTROLLER AREA NETWORK FOR OPEN CIRCUIT

Pinpoint Test B: CHECK THE CONTROLLER AREA NETWORK FOR SHORT CIRCUIT

Pinpoint Test C: CHECK THE SCP NETWORK CIRCUIT

Pinpoint Test : CHECK THE ISO NETWORK CIRCUIT

Pinpoint Test E: DTC P1637; CHECK THE DSCCM SUPPLIES AND GROUNDS

Pinpoint Test F: DTC P1643; CHECK THE TCM SUPPLIES AND GROUNDS

Pinpoint Test G: DTC P1696; CHECK THE ASCCM SUPPLIES AND GROUNDS

Pinpoint Test H: DTC P1699; CHECK THE A/CCM SUPPLIES AND GROUNDS

Pinpoint Test I: DTC P1774; CHECK THE LINEAR SWITCH MODULE SUPPLIES AND GROUNDS

Pinpoint Test J: DTC U1041 (CATS); VEHICLE SPEED SIGNAL FROM IC TO ADCM INVALID

Pinpoint Test K: DTC U1041 (BPM); VEHICLE SPEED SCP MESSAGE INVALID

Pinpoint Test L: DTC U1041 DDCM; VEHICLE SPEED SCP MESSAGE INVALID

Pinpoint Test M: DTC U1041 (SLCM); VEHICLE SPEED SCP MESSAGE INVALID

Pinpoint Test N: DTC U1135 (DDCM, DSCM, PDCM, PSCM, SLCM); IGNITION STATUS (IGNITION SWITCH POSITION) NOT OBTAINED

Pinpoint Test O: DTC U1236 (A/CCM); CONTROL PANEL TO A/CCM SERIAL COMMUNICATION CIRCUIT FAULT

Pinpoint Test P: DTC U1909 (DSCCM) LOCAL CAN NETWORK (STEERING ANGLE, SENSOR, YAW RATE, AND LATERAL ACCELERATION SENSOR) COMMUNICATIONS FAULT

Pinpoint Test Q: DTC U2012 (BPM); KEY TRANSPONDER MODULE MESSAGE CORRUPT

Pinpoint Test R: BPM POWER SUPPLY OR GROUND FAULT

Pinpoint Test S: SLCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test T: PDCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test U: DDCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test V: PHRCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test W: PSCM POWER SUPPLY FAULT

Pinpoint Test X: DSCM POWER SUPPLY FAULT

Pinpoint Test Y: DHRCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test Z: MAJOR IC POWER SUPPLY OR GROUND FAULT

Pinpoint Test AA: RCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test AB: PACM POWER SUPPLY OR GROUND FAULT

Pinpoint Test AC: ADCM POWER SUPPLY OR GROUND FAULT

Pinpoint Test AD: LEFT-HAND HID HEADLAMP POWER SUPPLY OR GROUND FAULT

Pinpoint Test AE: RIGHT-HAND HID HEADLAMP POWER SUPPLY OR GROUND FAULT

Pinpoint Test AF: KTM POWER SUPPLY OR GROUND FAULT

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Open the driver's door, or both doors if necessary, to allow the side windows to drop. Ensure that the doors remain open until after the battery has been disconnected.
2. Disconnect the battery ground cable. Remove the battery cover.
3. Open the bonnet and fit body paintwork protection sheets.
4. Remove the positive supply power cable. Remove the fuse-box from the mounting panel. Reposition the cover from the positive cable. Remove the nut which secures the positive cable to the fuse-box. Disconnect the positive power cable.
5. Remove the fuse-box from the mounting panel. Release the securing latch, upwards. Reposition the fuse-box, inwards. Remove the fuse-box from the mounting panel. Releases the securing tangs and remove the cover from the fuse-box.
6. Remove the fuse-box. Identify and disconnect the harness multi-plugs from the fuse-box. Remove the fuse-box from the vehicle.
7. Remove the fuses and relays. Note the position of each relay and remove them. Identify each fuse and remove them. The value and position of each fuse is illustrated on the lid of the luggage compartment fuse-box - for all fuse-boxes on the vehicle.
